Side 1/34

Sept 2021

QSG1_A

Reolink PoE NVR

User Manual

contents

1. NVR Introduction

.............................................................................................................................

Device Overview

..........................................................................................................................

Light Status

...................................................................................................................................

2. Setup and Installation

...................................................................................................................

Set up the NVR

.............................................................................................................................

3. Use Your System

............................................................................................................................

Live View

.......................................................................................................................................

4. Surveillance

.....................................................................................................................................

Set up Motion Detection

.........................................................................................................

Set up Motion Recording

........................................................................................................

Set up Continuous Recording

...............................................................................................

Set up Motion Alerts

.................................................................................................................

Set up FTP

...................................................................................................................................

5. Replay and Download Recordings

.........................................................................................

Replay Recordings

....................................................................................................................

Download Recordings

............................................................................................................

Back up Recordings

.................................................................................................................

6. Storage

..............................................................................................................................................

7. Network and Connection

...........................................................................................................

8. System Management

.................................................................................................................

General

.........................................................................................................................................

Time and Language

.................................................................................................................

Account Center

.........................................................................................................................

Maintenance

..............................................................................................................................

Info

.................................................................................................................................................

9. FAQs and Troubleshooting

......................................................................................................

FAQs

..............................................................................................................................................

Troubleshooting

........................................................................................................................

Note:

1.This user manual is for the Reolink PoE NVR and NVR security system that

work with the monitor.

2.This user manual takes an NVR model that supports most features as an

example. Your own NVR model may not support certain features mentioned

here. Please refer to the specifications of your NVR model.

Reolink PoE NVR

User Manual

1. NVR Introduction

Device Overview

RLN8-410/RLN16-410

Reolink has 16-channe PoE NVR RLN16-410 and 8-channel PoE NVR RLN8-410. Add

cameras to the PoE NVR, you are able to customize your own security systems.

Reolink PoE IP security camera systems feature plug and play, 12MP,4K Ultra HD,

or 5MP/4MP, which are easy to set up and simple to use, for DIY enthusiasts and

beginners. Features of our NVR video system also include excellent night vision,

24/7 continuous recording, local & remote access, and more.

RLN8-410

Power Switch

eSATA

RJ45

Power lnput

Audio Out

USB Port

HDMI Port

VGA Port

Network

Produkspesifikasjoner

Merke:	Reolink
Kategori:	Overvåkingskamera
Modell:	RLK16-800D8
Farge:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Videokomprimeringsformater:	H.264, H.265
Strømkildetype:	DC
Synsvinkel, horisontal:	87 °
Antall kameraer:	8
LED-type:	IR
Antall USB 2.0-porter:	2
Antall HDMI-porter:	1
Innebygd mikrofon:	Ja
Total lagringskapasitet:	3000 GB
Støttede nettverksprotokoller:	HTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP
Kameraoppløsning:	3840 x 2160 piksler
Antall kanaler:	16 kanaler
Antall eSATA-porter:	1
Varmefunksjon:	Nei
Kameragrensesnitt:	RJ-45
Kameravekt:	385 g
Sensortype:	CMOS
Skjermdiagonal:	- "
Antall VGA (D-Sub)-porter:	1
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	17
Driftstemperatur (T-T):	-10 - 55 °C
Innebygd kortleser:	Nei
CCD-sensorstørrelse:	1/2.8 "
tilbakestillingsknapp:	Ja
DC utgangsstrøm:	2.5 A
Synsvinkel, vertikal:	47 °
Megapiksel:	8 MP
DC-inngangskontakt:	Ja
Internasjonal beskyttelses (IP)-kode:	IP66
Minimumsbelysning:	0 lx
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	Fast Ethernet, Gigabit Ethernet
Relativ luftfuktighet under drift (H-H):	10 - 90
Støttede plasseringer/plasseringer som kan benyttes:	Inne/Ute
Strøm over Ethernet (PoE):	Ja
DC-ut, volt:	48
Effektiv distanse for nattsyn:	30 m
Maksimal blenderåpning:	2
Maks. HDD-kapasitet:	12000 GB
Linie-utgang (RCA):	1
Lagringsmedia:	Harddisk
Antall støttede HDDer:	2
Antall lysende LED:	18
Kamera inkludert:	Ja
Overvåkningskameraets formfaktor:	Kuppel
Opptaker inkludert:	Ja
Støttede avspillingsoppløsninger:	3840x2160, 1920x1080, 1440x900, 1280x1024, 1280x800, 1280x720, 1024x768
Kamera, bredde:	105 mm
Camera heihgt:	93 mm
Kamera, dybde:	105 mm
Opptakerens bredde:	330 mm
Opptakerens dybde:	285 mm
Opptakerens høyde:	45 mm
Opptakerens vekt:	1800 g
