Side 1/28

Portable Room Air Conditioner
Operation & Installation Manual
REFRIGERANT
R290
MODEL
RPC34MCWF

Rinnai 2 Portable Room AC OIM
For continued safety of this appliance it must
be installed and maintained in accordance with
the manufacturer’s instructions.
Before proceeding with the operation of your
new Rinnai Portable Room Air Conditioner,
please read this manual thoroughly and gain a
full understanding of the requirements,
features and operation of your new appliance.
REFRIGERANT
R290

Rinnai 3 Portable Room AC OIM
TABLE OF CONTENTS
Safety & Important Information 4
Specications 10
Introduction 10 �������������������������������������������������������������������������������������������������������������������������������������������������������
Specications ��������������������������������������������������������������������������������������������������������������������������������������������������� 10
AirConditionerBasics 11
Appliance Components ������������������������������������������������������������������������������������������������������������������������������������ 11
Operation 12
Control Panel 12 ����������������������������������������������������������������������������������������������������������������������������������������������������
Basic Operation ������������������������������������������������������������������������������������������������������������������������������������������������ 12
Basic Operation Control Panel ������������������������������������������������������������������������������������������������������������������������� 12
Auto 12 ��������������������������������������������������������������������������������������������������������������������������������������������������������������
Cool 13 ��������������������������������������������������������������������������������������������������������������������������������������������������������������
Dry 13 ����������������������������������������������������������������������������������������������������������������������������������������������������������������
FAN 13 ��������������������������������������������������������������������������������������������������������������������������������������������������������������
Other Operation �������������������������������������������������������������������������������������������������������������������������������������������� 13
Filter Reset ��������������������������������������������������������������������������������������������������������������������������������������������������� 13
Sleep 13 ������������������������������������������������������������������������������������������������������������������������������������������������������������
Timer 14 ������������������������������������������������������������������������������������������������������������������������������������������������������������
Swing ������������������������������������������������������������������������������������������������������������������������������������������������������������ 14
Wi-Fi Operation 14 ������������������������������������������������������������������������������������������������������������������������������������������������
RemoteControl 15
Care&Maintenance 17
General Maintenance 17 ���������������������������������������������������������������������������������������������������������������������������������������
Cleaning the Air Filter 17 ���������������������������������������������������������������������������������������������������������������������������������������
Save a Service Call 18 ������������������������������������������������������������������������������������������������������������������������������������������
When to Call for Service 18 �����������������������������������������������������������������������������������������������������������������������������������
Installation 19
Location 19 ������������������������������������������������������������������������������������������������������������������������������������������������������������
Duct Assembly �������������������������������������������������������������������������������������������������������������������������������������������������� 19
Exhaust Ducting Options ���������������������������������������������������������������������������������������������������������������������������������� 20
Window Installations ������������������������������������������������������������������������������������������������������������������������������������� 20
Semi-Permanent Wall Installation ���������������������������������������������������������������������������������������������������������������� 21
Condensate Drainage �������������������������������������������������������������������������������������������������������������������������������������� 21
Internal Condensate Tank ���������������������������������������������������������������������������������������������������������������������������� 21
Fixed Condensate Drainage Hose ��������������������������������������������������������������������������������������������������������������� 21
Warranty 22
Contacts 28

Rinnai 4 Portable Room AC OIM
WARNING
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
Always complywiththefollowing precautions toavoiddangerous situations andtoensure
optimumperformance.
Failure to carefully read and follow all instructions in this manual can result in equipment
malfunction,propertydamage,personalinjuryand/ordeath.
DANGER: Indicatesanimminentlyhazardous situationwhich,ifnotavoided,willresult in
personalinjuryordeath.
WARNINGS:Indicatesapotentiallyhazardoussituationwhich,ifnotavoided,couldresultin
personalinjuryordeath.
CAUTIONS: Indicates apotentiallyhazardoussituationwhich,ifnotavoided,couldresult
inminorormoderateinjuryordamagetotheappliance.Itmayalsobeusedtoalertagainst
unsafepractices.
WARNING
The appliance is tted with an Australian exible cord and plug intended for connection to an Australian
10 Amp socket outlet. It is not suitable for connection in other countries or alternative power supplies.
Ensure that the voltage and frequency of the power supply correspond to the ratings on the dataplate of
the appliance.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Young children should be supervised to ensure they do not play with the appliance.
DO NOT allow children or persons with reduced physical, sensory or mental capabilities to sleep directly
in front of this appliance.
DO NOT allow children to ‘post articles’ into the louvres of the appliance.
DO NOT use power boards or double adaptors with this appliance.
DO NOT coil or bundle the electric cord to reduce it’s length as overheating of the cord may occur which
could result in a re hazard.
The exible cord and plug must not be modied. If the cord or plug are damaged, they must be replaced
by Rinnai or a Rinnai appointed service agent.
DO NOT cover or place articles on or against any parts of this appliance, to avoid overheating.
DO NOT sit on this appliance
DO NOT use this appliance in the immediate surroundings of a bath, a shower or a swimming pool.
DO NOT move this appliance whilst it is turned on.
DO NOT unplug the appliance by pulling on the exible cord.
DO NOT handle any parts of this appliance, including the plug and exible cord, with wet or damp hands.
DO NOT immerse the appliance, exible cord and plug in water or any other liquid.
DO NOT place containers of any liquid or wax on top of this appliance.
Turn o the appliance and unplug from the power socket outlet when not in use.
DO NOT use in areas where ammable liquids are stored.
This appliance is suitable for indoor use only.
Never dismantle the appliance. Tampering with electrical connections and components is highly
dangerous and may cause appliance malfunction, property damage, personal injury and/or death.
SAFETY & IMPORTANT INFORMATION

Rinnai 5 Portable Room AC OIM
WARNING
WARNINGINFORMATIONREGARDINGAPPLIANCESWITHR290REFRIGERANTGAS
Thoroughly read all of the warnings.
This appliance contains up to 210g of R290 refrigerant gas.
This appliance uses R290 refrigerant, which is class 3 ammability and must be handled by a refrigeration
mechanic with appropriate Australian refrigerant handling licence.
The appliance must be installed, used and stored in a ventilated area that is greater than 11 m 2.
When cleaning the appliance, do not use any tools other than those recommended by the manufacturing
company.
DO NOT use means to accelerate the defrosting process or to clean, other than those recommended
by the manufacturer.
The appliance must be placed in an area without any continuous sources of ignition (for example: open
ames, gas or electrical appliances in operation).
DO NOT DO NOTpuncture and burn.
Refrigerant gases can be odourless.
If the appliance is installed, operated or stored in a non-ventilated area, the room must be designed to
prevent the accumulation of refrigerant leaks resulting in a risk of re or explosion due to ignition of the
refrigerant caused by electric heaters, stoves, or other sources of ignition.
Compliance with national gas regulations shall be observed. Keep ventilation openings clear of
obstruction.
A warning that the appliance shall be stored in a well-ventilated area where the room size corresponds
to the room area as specied for operation.
Any person who is involved with working on or breaking into a refrigerant circuit should hold a current
valid certicate from an industry-accredited assessment authority, which authorises their competence to
handle refrigerants safely in accordance with an industry recognised assessment specication.
Servicing shall only be performed as recommended by the equipment manufacturer. Maintenance and
repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the
person competent in the use of ammable refrigerants.
The appliance MUST be stored in such a way as to prevent mechanical failure.
Repairs must be performed based on the recommendations from the manufacturing company.
Maintenance and repairs that require the assistance of other qualied personnel must be performed
under the supervision of an individual specied in the use of ammable refrigerants.
IMPORTANT
MANDATORY INSPECTION PRIOR TO INSTALLATION
Immediately report any damage or discrepancies to the Supplier of the appliance. This appliance was
inspected and tested at the time of manufacture and packaging, and released for transportation without
known damage. Upon receipt, inspect the exterior for evidence of rough handling in shipment. Ensure
that the appliance is labelled correctly for the gas and electrical supply, and/or other services it is intended
to be connected to.
For safety and warranty purposes, appliances that may be damaged or incorrect MUST NOT be installed
or operated under any circumstances. Installation of damaged or incorrect appliances may contravene
local government regulations. Rinnai disclaims any liability or responsibility whatsoever in relation to the
installation or operation of damaged or incorrect appliances.
NOTE
A NOTE ON ILLUSTRATIONS
The illustrations used in this manual are for explanatory purposes only and the shape of your indoor unit
may vary slightly from that which is shown in this manual.
SAFETY & IMPORTANT INFORMATION

Rinnai 7 Portable Room AC OIM
6) No ignition sources
No person carrying out work in relation to a refrigeration system which involves exposing any pipe work that
contains or has contained ammable refrigerant shall use any sources of ignition in such a manner that it may lead
to the risk of re or explosion. All possible ignition sources, including cigarette smoking, should be kept suciently
far away from the site of installation, repairing, removing and disposal, during which ammable refrigerant can
possibly be released to the surrounding space. Prior to work taking place, the area around the equipment is to be
surveyed to make sure that there are no ammable hazards or ignition risks. No Smoking signs shall be displayed.
7) Ventilated area
Ensure that the area is in the open or that it is adequately ventilated before breaking into the system or conducting
any hot work. A degree of ventilation shall continue during the period that the work is carried out. The ventilation
should safely disperse any released refrigerant and preferably expel it externally into the atmosphere.
8) Checks to the refrigeration equipment
Where electrical components are being changed, they shall be t for the purpose and to the correct specication.
At all times the manufacturer’s maintenance and service guidelines shall be followed. If in doubt consult the
manufacturer’s technical department for assistance. The following checks shall be applied to installations using
ammable refrigerants:
The charge size is in accordance with the room size within which the refrigerant containing parts are installed;
The ventilation machinery and outlets are operating adequately and are not obstructed;
If an indirect refrigerating circuit is being used, the secondary circuit shall be checked for the presence of refrigerant;
Marking to the equipment continues to be visible and legible. Markings and signs that are illegible shall be corrected;
Refrigeration pipe or components are installed in a position where they are unlikely to be exposed to any substance
which may corrode refrigerant containing components, unless the components are constructed of materials which
are inherently resistant to being corroded or are suitably protected against being so corroded.
9) Checks to electrical devices
Repair and maintenance to electrical components shall include initial safety checks and component inspection
procedures. If a fault exists that could compromise safety, then no electrical supply shall be connected to the
circuit until it is satisfactorily dealt with. If the fault cannot be corrected immediately but it is necessary to continue
operation, an adequate temporary solution shall be used. This shall be reported to the owner of the equipment so
all parties are advised.
Initial safety checks shall include:
That capacitors are discharged: this shall be done in a safe manner to avoid possibility of sparking;
That there no live electrical components and wiring are exposed while charging, recovering or purging the system;
That there is continuity of earth bonding.
7. Repairstosealedcomponents
1) During repairs to sealed components, all electrical supplies shall be disconnected from the equipment
being worked upon prior to any removal of sealed covers, etc. If it is absolutely necessary to have an
electrical supply to equipment during servicing, then a permanently operating form of leak detection shall
be located at the most critical point to warn of a potentially hazardous situation.
2) Particular attention shall be paid to the following to ensure that by working on electrical components, the
casing is not altered in such a way that the level of protection is aected. This shall include damage to
cables, excessive number of connections, terminals not made to original specication, damage to seals,
incorrect tting of glands, etc. Ensure that apparatus is mounted securely. Ensure that seals or sealing
materials have not degraded such that they no longer serve the purpose of preventing the ingress of
ammable atmospheres. Replacement parts shall be in accordance with the manufacturer’s specications.
NOTE: The use of silicon sealant may inhibit the eectiveness of some types of leak detection equipment.
Intrinsically safe components do not have to be isolated prior to working on them.
SAFETY & IMPORTANT INFORMATION

Rinnai 8 Portable Room AC OIM
8. Repairtointrinsicallysafecomponents
Do not apply any permanent inductive or capacitance loads to the circuit without ensuring that this will not exceed
the permissible voltage and current permitted for the equipment in use. Intrinsically safe components are the only
types that can be worked on while live in the presence of a ammable atmosphere. The test apparatus shall be at
the correct rating. Replace components only with parts specied by the manufacturer. Other parts may result in the
ignition of refrigerant in the atmosphere from a leak.
9. Cabling
Check that cabling will not be subject to wear, corrosion, excessive pressure, vibration, sharp edges or any other
adverse environmental eects. The check shall also take into account the eects of aging or continual vibration
from sources such as compressors or fans.
10. Detectionofammablerefrigerants
Under no circumstances shall potential sources of ignition be used in the searching for or detection of refrigerant
leaks. A halide torch (or any other detector using a naked ame) shall not be used.
11. Leakdetectionmethods
The following leak detection methods are deemed acceptable for systems containing ammable refrigerants.
Electronic leak detectors shall be used to detect ammable refrigerants, but the sensitivity may not be adequate,
or may need re-calibration. (Detection equipment shall be calibrated in a refrigerant-free area.) Ensure that the
detector is not a potential source of ignition and is suitable for the refrigerant used. Leak detection equipment
shall be set at a percentage of the LFL of the refrigerant and shall be calibrated to the refrigerant employed and
the appropriate percentage of gas (25 % maximum) is conrmed. Leak detection uids are suitable for use with
most refrigerants but the use of detergents containing chlorine shall be avoided as the chlorine may react with
the refrigerant and corrode the copper pipe-work. If a leak is suspected, all naked ames shall be removed/
extinguished.
If a leakage of refrigerant is found which requires brazing, all of the refrigerant shall be recovered from the system,
or isolated (by means of shut o valves) in a part of the system remote from the leak. Oxygen free nitrogen (OFN)
shall then be purged through the system both before and during the brazing process.
12. Removalandevacuation
When breaking into the refrigerant circuit to make repairs or for any other purpose conventional procedures shall
be used. However, it is important that best practice is followed since ammability is a consideration. The following
procedure shall be adhered to:
Remove refrigerant; Purge the circuit with inert gas; Evacuate; Purge again with inert gas; Open the circuit by
cutting or brazing.
The refrigerant charge shall be recovered into the correct recovery cylinders. The system shall be ushed with
OFN to render the unit safe. This process may need to be repeated several times. Compressed air or oxygen
shall not be used for this task. Flushing shall be achieved by breaking the vacuum in the system with OFN and
continuing to ll until the working pressure is achieved, then venting to atmosphere, and nally pulling down to a
vacuum. This process shall be repeated until no refrigerant is within the system.
When the nal OFN charge is used, the system shall be vented down to atmospheric pressure to enable work to
take place. This operation is absolutely vital if brazing operations on the pipe-work are to take place. Ensure that
the outlet for the vacuum pump is not close to any ignition sources and there is ventilation available.
13. Chargingprocedures
In addition to conventional charging procedures, the following requirements shall be followed. Ensure that
contamination of dierent refrigerants does not occur when using charging equipment. Hoses or lines shall be as
short as possible to minimise the amount of refrigerant contained in them.
Cylinders shall be kept upright.
Ensure that the refrigeration system is earthed prior to charging the system with refrigerant.
Label the system when charging is complete (if not already).
Extreme care shall be taken not to overll the refrigeration system. Prior to recharging the system it shall be
pressure tested with OFN. The system shall be leak tested on completion of charging but prior to commissioning.
A follow up leak test shall be carried out prior to leaving the site.
SAFETY & IMPORTANT INFORMATION

Rinnai 9 Portable Room AC OIM
14. Decommissioning
Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and
all its detail. It is recommended good practice that all refrigerants are recovered safely.
Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior
to re-use of reclaimed refrigerant. It is essential that electrical power is available before the task is commenced.
a) Become familiar with the equipment and its operation.
b) Isolate system electrically.
c) Before attempting the procedure ensure that: Mechanical handling equipment is available, if required, for
handling refrigerant cylinders; All personal protective equipment is available and being used correctly;
The recovery process is supervised at all times by a competent person; Recovery equipment and cylinders
conform to the appropriate standards.
d) Pump down refrigerant system, if possible.
e) If a vacuum is not possible, make a manifold so that refrigerant can be removed from various parts of the
system.
f) Make sure that cylinder is situated on the scales before recovery takes place.
g) Start the recovery machine and operate in accordance with manufacturer’s instructions.
h) Do not overll cylinders. (No more than 80% volume liquid charge).
i) Do not exceed the maximum working pressure of the cylinder, even temporarily.
j) When the cylinders have been lled correctly and the process completed, make sure that the cylinders and
the equipment are removed from site promptly and all isolation valves on the equipment are closed o.
k) Recovered refrigerant shall not be charged into another refrigeration system unless it has been cleaned and
checked.
15. Labelling
Equipment shall be labelled stating that it has been de-commissioned and emptied of refrigerant. The label shall
be dated and signed. Ensure that there are labels on the equipment stating the equipment contains ammable
refrigerant.
16. Recovery
When removing refrigerant from a system, either for servicing or decommissioning, it is recommended good
practice that all refrigerants are removed safely. When transferring refrigerant into cylinders, ensure that only
appropriate refrigerant recovery cylinders are employed. Ensure that the correct number of cylinders for holding
the total system charge is available. All cylinders to be used are designated for the recovered refrigerant and
labelled for that refrigerant (i.e. special cylinders for the recovery of refrigerant). Cylinders shall be complete
with pressure relief valve and associated shut-o valves in good working order. Empty recovery cylinders are
evacuated and, if possible, cooled before recovery occurs. The recovery equipment shall be in good working
order with a set of instructions concerning the equipment that is at hand and shall be suitable for the recovery of
ammable refrigerants.
In addition, a set of calibrated weighing scales shall be available and in good working order. Hoses shall be
complete with leak-free disconnect couplings and in good condition. Before using the recovery machine, check
that it is in satisfactory working order, has been properly maintained and that any associated electrical components
are sealed to prevent ignition in the event of a refrigerant release.
Consult manufacturer if in doubt. The recovered refrigerant shall be returned to the refrigerant supplier in the
correct recovery cylinder, and the relevant Waste Transfer Note arranged. Do not mix refrigerants in recovery units
and especially not in cylinders. If compressors or compressor oils are to be removed, ensure that they have been
evacuated to an acceptable level to make certain that ammable refrigerant does not remain within the lubricant.
The evacuation process shall be carried out prior to returning the compressor to the suppliers. Only electric heating
to the compressor body shall be employed to accelerate this process. When oil is drained from a system, it shall
be carried out safely.
SAFETY & IMPORTANT INFORMATION

Rinnai 10 Portable Room AC OIM
INTRODUCTION
This portable air conditioner can alter the room temperature and humidity. It has multiple functions of cooling
dehumidifying (drying) and fan ventilation and can be moved from room to room and transported from building to
building easily.
The air conditioner can maintain set room indoor air temperatures between 16°C and 32°C. The set room
temperature is displayed on the remote control and in the control panel on the unit. This does not mean that the air
conditioner will necessarily reduce the actual room temperature to the set room temperature.
• Do not place the air conditioner or plastic window slider in direct sunlight. Close all curtains in the room being
cooled.
• For maximum cooling (COOLING MODE), set the temperature at 18°C and the fan at HIGH. After
approximately 3 minutes, the compressor will turn on and cooled air will come out of the front air outlet.
Warm air will also come out of the rear outlet and into the exhaust hose.
• In COOLING MODE the air conditioner will not cool unless the set temperature is below the existing room
temperature.
• In COOLING MODE once the existing room temperature reaches the set temperature, the fan continues
operating and the compressor switches on and o to maintain the set temperature within the room.
• For maximum cooling output keep the exhaust hose as short and as straight as possible. Minimise bends
which can reduce the maximum cooling capacity of the air conditioner. Elevate the air conditioner if necessary.
• Make sure the air intake and outlet grills are unobstructed.
• Clean the lters at least once every two weeks.
SPECIFICATIONS
MODEL RPC34MCWF
Function Cooling Only
Control Remote and Wi-Fi via App
Power Supply 220V-240V~ / 50Hz
Maximum Input Power 1450W
Maximum Input Current 8A
Dimensions - Net (H x W x D) 710mm x 476mm x 385mm
Dimensions - Packing (H x W x D) 885mm x 545mm x 435mm
Weight 33kg
Nominal Cooling Capacity 3.4kW
Rated Input Current 5.8A
Rated Input Power 1280W
Refrigerant Type R290
Refrigerant Volume 210g
Noise Level 64.5dB(A)
SPECIFICATIONS

Rinnai 11 Portable Room AC OIM
APPLIANCE COMPONENTS
1. Control panel 10. Lower air intake (lter located behind grill)
2. Cool air outlet 11. Swivel casters (x4)
3. Receiver window 12. Drain tray outlet
4. Remote control 13. 1.7m exible 2 pin cord 220-240V 50Hz 10A
5. Exhaust outlet 14. Adjustable window slide kit
6. Carry handles 15. Window exhaust duct window adaptor.
7. Drain outlet 1 16. Exhaust duct (extends to 1.8M)
8. Drain outlet 2 (not used on this model) 17. Duct to appliance adaptor
9. Room air intake (lter located behind grill) 18. Condensate drain hose
4
9
5
7
8
11
12
13
10
Front
Back
15
17 16
18
14
162
3
AIR CONDITIONER BASICS

Rinnai 12 Portable Room AC OIM
CONTROL PANEL
1. ON/OFF Button 6. Sleep Mode Button
2. Filter Reset Button 7. Timer Button
3. Fan Speed Button 8. Swing Button
4. Temperature Button 9. Wi-Fi Button
5. Mode Selection Button
IMPORTANT
Before operating this appliance ensure that the location, installation and condensation
requirementshavebeenmet,refertoinstallationinstructionsstartingonpage19fordetails.
Forthebestcoolingresultsensurethattheltersareclean,referpage17fordetails.
Whentheapplianceispluggedandthepowerpointisturnedonasinglebeepwillbeheardand
thecoolairoutletlouvrewillcycleopenandclosedonce,thisisnormal.
BASIC OPERATION
There are four basic operational modes available, these are AUTO, COOL (chilled air operation), DRY (chilled and
dehumidied operation) and FAN (fan only operation).
BASIC OPERATION CONTROL PANEL
AUTO
1. Press the ON/OFF button (1).
2. Press the mode selection button (5) until the AUTO mode indicator is illuminated. Use temperature buttons (4)
to select the desired temperature (16°C to 32°C).When the room temperature is higher than set temperature,
Cool mode; When the room temperature is lower than set temperature, Fan mode.
3. Press the ON/OFF button (1) to stop operation.
NOTE
Inthismode,youcannotadjustthefanspeeds.
OPERATION

Rinnai 13 Portable Room AC OIM
COOL
1. Press the ON/OFF (1) button.
2. Press the mode selection (5) button until the COOL mode indicator is illuminated.
3. Use temperature buttons (4) to select the desired temperature (16°C to 32°C)
4. Use fan speed button (3) to select the desired fan speed (AUTO, LOW, MED or HIGH).
5. Press the ON/OFF button (1) to stop operation.
DRY
1. Press the ON/OFF (1) button.
2. Press the mode selection button (5) until the DRY mode indicator is illuminated.
3. Press the ON/OFF button (1).
FAN
1. Press the ON/OFF button (1).
2. Press the mode selection button (5) until the FAN mode indicator is illuminated.
3. Use fan speed buttons (3) to select the desired fan speed (LOW, MED or HIGH).
NOTE
AUTOfanspeedisnotavailableonFANmode.
4. Press the ON/OFF button (1).
NOTE
Themostrecentbasicoperationalsettingsarestoredintheappliancesmemory.
If the appliance is not disconnected from the mains power supply then these setting will be
availablethenexttimetheapplianceisturnedonviatheON/OFFbutton.
OTHER OPERATION
FILTER RESET
When lter reset indicator light on, it means the air lter should be cleaned.
After cleaning the air lter, press the Filter Reset button to reset the countdown timer, the indicator light o.
NOTE
Theltercleanreminderisforgeneralusepurpose;Ifperiodsofheavyuse,airltersshouldbe
checkedandcleanedeveryweek.
SLEEP
The SLEEP function allows the set temperature to increase
and decrease over an 8 hour period at pre-set time intervals
to maintain your comfort while saving energy after the 8 hours
has passed the appliance will resume normal operation.
NOTE
Sleep mode is not available in FAN only and
DRY mode
C°C = Set cooling temperature
1
Sleep mode 8 hours
0.5 8
1°C
Set temp
1°C
Sleep Mode
Finishes
Sleep Mode
Starts
0
OPERATION

Rinnai 14 Portable Room AC OIM
TIMER
With the appliance "OFF", press the "TIMER" button (7) once to active Delay On Timer.
Press - or + to set the desired time period.
Wait for approximately 5 seconds to lock in the setting.
With the appliance "ON", press the "TIMER" button (7) once to active Delay O Timer.
Press - or + to set the desired time period.
Wait for approximately 5 seconds to lock in the setting.
When a timer is set, pressing the "TIMER" button (7) will cancel any timer settings.
NOTE
Whenthetimerfunctionisinitiated,pressthe"timer"button(7)oncetoseetheremainingtime.
Pressthe"timer"button(7)onceagaintocancelthetimerfunction.
SWING
Press this button (8) to adjust the air ow direction.
NOTE
Onlyonemodeofoperationisavailableatanytime.
WI-FI OPERATION
Refer to the Wireless Operation Manual for App connectivity and operation.
A copy of the manual may be downloaded from the Rinnai Website:
https://www.rinnai.com.au/air-conditioning/portable-air-conditioners/ or by scanning this QR code:
OPERATION

Rinnai 15 Portable Room AC OIM
NOTE
BeforeproceedingwiththeoperationofyournewRinnaiPortableRoomAirConditionerRemote
Controller, please read these instructions thoroughly and gain a full understanding of the
requirementsfeaturesandoperationofyournewRemoteController.
PleasekeeptheOperationandInstallationManualforyournewPortableRoomAirConditioner
handysoitcanbereferredtoatanytimeinconjunctionwiththeseinstructions.
REMOTE CONTROL OVERVIEW
1. ON/OFF Button
2. Fan Speed Button
3. Swing Button
4. Timer Button
5. Sleep Button
6. Temperature UP/DOWN Buttons
7. Fan Only Button
8. Cool Button
9. Dry (Dehumidifying) Button
10. This button has no function on this model.
BASIC OPERATION REMOTE CONTROLLER
The Rinnai Remote Controller allows for convenient operation of the appliance within a 8 metre range.
NOTE
Aconrmationbeepsoundstoconrmthatasuccessfulcontrollerinputhasbeenreceivedby
theappliance.
BUTTON DESCRIPTIONS & OPERATION
1. "ON/OFF" Button
Press "ON/OFF" button to turn "ON" or "OFF" the Air Conditioner.
2. "SPEED" Button
Press "SPEED" to set the fan speed (LOW, MEDIUM or HIGH).
3. "+" and "-" Button to adjust temperature or time
(a) Press “+”and “-” to regulate the temperature (the unit is 1°C) and set the time (the unit is 1h).
The temperature ranges from 16° to 32°, and the time ranges from 1h to 24h.
4. "SWING" Button
Press "SWING" to turn "ON" or "OFF" the swing function.
5. "TIMER" Button
(a) When the air conditioner is turned "OFF", press "TIMER" to set a time to turn "ON" the Air Conditioner.
Press "+" or "-" to set the time, and press "TIMER" again to conrm it.
(b) When the air conditioner is turned "ON", press "TIMER" to set a time to turn "OFF" the Air Conditioner.
Press "+" or "-" to set the time, and press "TIMER" again to conrm it.
(c) After setting the time, press "TIMER" again to cancel the set time.
NOTE
After setting the time, press “TIMER” again to conrm it in 5 seconds. Without any operation
in 5 seconds, the air conditioner will conrm the time automatically. Pressing “TIMER” after
conrmingthetimethiswillcancelthesettime.
2 3
1
9
6
4
5
7
8
10
REMOTE CONTROL
Produkspesifikasjoner
Merke: | Rinnai |
Kategori: | Air condition |
Modell: | RPC34MCWF |
Trenger du hjelp?
Hvis du trenger hjelp med Rinnai RPC34MCWF still et spørsmål nedenfor, og andre brukere vil svare deg
Air condition Rinnai Manualer
31 Mars 2025
21 Desember 2024
21 Desember 2024
21 Desember 2024
21 Desember 2024
Air condition Manualer
- Air condition Thomson
- Air condition Amana
- Air condition Whirlpool
- Air condition Haier
- Air condition NewAir
- Air condition LG
- Air condition Bosch
- Air condition BEKO
- Air condition Hisense
- Air condition Koldfront
- Air condition Arcelik
- Air condition Danby
- Air condition Gree
- Air condition TCL
- Air condition Hotpoint
- Air condition Cecotec
- Air condition Samsung
- Air condition Noveen
- Air condition Delonghi
- Air condition Comfee
- Air condition Kogan
- Air condition SereneLife
- Air condition Create
- Air condition Furrion
- Air condition Midea
- Air condition Sauber
- Air condition Candy
- Air condition Carson
- Air condition Orbegozo
- Air condition Panasonic
- Air condition Olimpia Splendid
- Air condition Vox
- Air condition Westinghouse
- Air condition Sencor
- Air condition Electroline
- Air condition Fujitsu
- Air condition Orava
- Air condition Mistral
- Air condition Khind
- Air condition CyberPower
- Air condition Frigidaire
- Air condition Dimplex
- Air condition Bimar
- Air condition Whynter
- Air condition GE
- Air condition Hitachi
- Air condition Hyundai
- Air condition VänEE
- Air condition Ausclimate
- Air condition Infiniton
- Air condition Ufesa
- Air condition Lavorwash
- Air condition Omega Altise
- Air condition Daikin
- Air condition Be Cool
- Air condition Blaupunkt
- Air condition Einhell
- Air condition Avidsen
- Air condition Mitsubishi
- Air condition Friedrich
- Air condition Tristar
- Air condition Dometic
- Air condition Eldom
- Air condition Elba
- Air condition Philco
- Air condition REMKO
- Air condition Vivax
- Air condition Black And Decker
- Air condition Ozito
- Air condition Toshiba
- Air condition Wilfa
- Air condition Heinner
- Air condition SEEGER
- Air condition Meireles
- Air condition IFB
- Air condition Profilo
- Air condition Middle Atlantic
- Air condition Duracraft
- Air condition Home Electric
- Air condition Milectric
- Air condition LERAN
- Air condition Perfect Aire
- Air condition Argoclima
- Air condition Svan
- Air condition ARCTIC WIND
- Air condition Trisa
- Air condition Daizuki
- Air condition Mayer
- Air condition HTW
- Air condition Be Quiet!
- Air condition Emerson
- Air condition Broan
- Air condition BOSFOR
- Air condition KDK
- Air condition Aconatic
- Air condition AireMax
- Air condition Profile
- Air condition Keystone
- Air condition Honeywell
- Air condition Theben
- Air condition Carrier
- Air condition Ravanson
- Air condition Yamazen
- Air condition ActronAir
- Air condition Orima
- Air condition Woods
- Air condition Aspes
- Air condition Soler & Palau
- Air condition Bavaria
- Air condition Dantherm
- Air condition Sôlt
- Air condition Daitsu
- Air condition Fuave
- Air condition Proklima
- Air condition Universal Blue
- Air condition Symphony
- Air condition Kelvinator
- Air condition Premium
- Air condition Corona
- Air condition Krone
- Air condition Royal Sovereign
- Air condition Gutfels
- Air condition Duux
- Air condition GoldAir
- Air condition Heller
- Air condition Teco
- Air condition Magnavox
- Air condition SHE
- Air condition Cool-Space
- Air condition KuulAire
- Air condition BLUEPALM
- Air condition Essentiel B
- Air condition BISWIND
- Air condition Igenix
- Air condition Fuji Electric
- Air condition Sheffield
- Air condition General
- Air condition Hoffman
Nyeste Air condition Manualer
10 April 2025
10 April 2025
10 April 2025
10 April 2025
10 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
