RME M-16 AD Bruksanvisning
RME
lyd / video konverterer
M-16 AD
Les nedenfor 📖 manual på norsk for RME M-16 AD (57 sider) i kategorien lyd / video konverterer. Denne guiden var nyttig for 2 personer og ble vurdert med 4.7 stjerner i gjennomsnitt av 1.5 brukere
Side 1/57
User’s Guide
M-32 AD
M-16 AD
The Professional’s Converter Solution
Professional 32/16-Channel A/D Converter
Fully Symmetrical Circuit Design
Analog Limiter
32/16-Channel Analog to MADI / ADAT Interface
24 Bit / 192 kHz Digital Audio
MIDI Remote Control
24 Bit Interface
TotalRemote
™
MADI I/O
ADAT
™
I/O
SteadyClock
™
SyncCheck
™
AES-10
2
User’s Guide M-32 AD © RME
Important Safety Instructions..................................4
General
1 Introduction ...............................................................6
2 Package Contents.....................................................6
3 Brief Description and Characteristics.....................6
4 First Usage – Quick Start
4.1 Controls - Connectors - Displays............................7
4.2 Quick Start ..............................................................9
5 Accessories.............................................................10
6 Warranty...................................................................11
7 Appendix..................................................................11
Usage and Operation
8 Front Panel Controls
8.1 Analog Input.........................................................14
8.2 MADI Out .............................................................14
8.3 MADI Input ...........................................................14
8.4 MADI Output ........................................................14
8.5 Limiter...................................................................15
8.6 Clock Section .......................................................15
8.7 Meter ....................................................................17
8.8 Remote.................................................................17
8.9 Lock Keys.............................................................17
9 Remote Control
9.1 MIDI..........................................................................18
9.2 MIDI over MADI........................................................18
9.3 Remote Control Software.........................................19
Inputs and Outputs
10 Analog Inputs ..........................................................22
11 Digital Inputs / Outputs
11.1 ADAT Optical .......................................................23
11.2 MADI Input ...........................................................23
11.3 MADI Output ........................................................24
12 Word Clock
12.1 Wordclock Input and Output ................................25
12.2 Technical Description and Background ...............26
12.3 Cables and Termination.......................................27
14 MIDI...........................................................................27
Produkspesifikasjoner
| Merke: | RME |
| Kategori: | lyd / video konverterer |
| Modell: | M-16 AD |
