Side 1/32

Instructies voor het gebruik en installeren

Dampkap

Instructions for use and installation

Cooker Hood

Istruzioni per l’uso e l’installazione

Cappa

Mode d’emploi et installazione

Hotte de Cuisine

Bedienungsanleitung und Einrichtung

Dunstabzugshaube

Latitude Centrale

Instructions Manual

INDEX

RECOMMENDATIONS AND SUGGESTIONS .....................................................................................................................2

CHARACTERISTICS.............................................................................................................................................................3

INSTALLATION......................................................................................................................................................................4

USE........................................................................................................................................................................................8

MAINTENANCE.....................................................................................................................................................................9

EMPFEHLUNGEN UND HINWEISE ...................................................................................................................................32

CHARAKTERISTIKEN.........................................................................................................................................................33

MONTAGE...........................................................................................................................................................................34

BEDIENUNG........................................................................................................................................................................38

WARTUNG...........................................................................................................................................................................39

Libretto di Istruzioni

INDICE

CONSIGLI E SUGGERIMENTI............................................................................................................................................12

CARATTERISTICHE............................................................................................................................................................13

INSTALLAZIONE.................................................................................................................................................................14

USO......................................................................................................................................................................................18

MANUTENZIONE ................................................................................................................................................................19

Manuel d’Instructions

SOMMAIRE

CONSEILS ET SUGGESTIONS..........................................................................................................................................22

CARACTERISTIQUES.........................................................................................................................................................23

INSTALLATION....................................................................................................................................................................24

UTILISATION.......................................................................................................................................................................28

ENTRETIEN.........................................................................................................................................................................29

Gebruiksaanwijzing

INHOUDSOPGAVE

ADVIEZEN EN SUGGESTIES.............................................................................................................................................42

EIGENSCHAPPEN...............................................................................................................................................................43

INSTALLATIE.......................................................................................................................................................................44

GEBRUIK.............................................................................................................................................................................48

ONDERHOUD......................................................................................................................................................................49

'3

Bedienungsanleitung

INHALTSVERZEICHNIS

• This appliance complies with European regulations on low voltages Directive 2006/95/CE on electrical safety, and with the

following European regulations: Directive 2004/108/CE on electromagnetic compatibility and Directive 93/68 on EC marking.

When this crossed-out wheeled bin symbol

is attached to a product it means the product is covered by the European

directive 2002/96/EC.Your product is designed and manufactured with high quality materials and components, which can be

recycled and reused.Please inform yourself about the local separate collection system for electrical and electronic product.

Please act according to your local rules and do not dispose of your old products with your normal household waste. The correct

disposal of your old product will help prevent potential negative consequences for the environment and human health.

RECOMMENDATIONS AND SUGGESTIONS

The Instructions for Use apply to several versions of this appliance. Accordingly,

you may find descriptions of individual features that do not apply to your specific

appliance.

INSTALLATION

• The manufacturer will not be held liable for any damages resulting from incorrect or

improper installation.

• The minimum safety distance between the cooker top and the extractor hood is 650

mm.

• Check that the mains voltage corresponds to that indicated on the rating plate fixed

to the inside of the hood.

• For Class I appliances, check that the domestic power supply guarantees adequate

earthing.

Connect the extractor to the exhaust flue through a pipe of minimum diameter 120

mm. The route of the flue must be as short as possible.

• Do not connect the extractor hood to exhaust ducts carrying combustion fumes

(boilers, fireplaces, etc.).

• If the extractor is used in conjunction with non-electrical appliances (e.g. gas burn-

ing appliances), a sufficient degree of aeration must be guaranteed in the room in

order to prevent the backflow of exhaust gas. The kitchen must have an opening

communicating directly with the open air in order to guarantee the entry of clean air.

USE

• The extractor hood has been designed exclusively for domestic use to eliminate

kitchen smells.

• Never use the hood for purposes other than for which it has been designed.

• Never leave high naked flames under the hood when it is in operation.

• Adjust the flame intensity to direct it onto the bottom of the pan only; making sure

that it does not engulf the sides.

• Deep fat fryers must be continuously monitored during use: overheated oil can burst

into flames.

• Do not flambé under the range hood; risk of fire

• This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction concerning use of the appli-

ance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

MAINTENANCE

• Switch off or unplug the appliance from the mains supply before carrying out any

maintenance work.

• Clean and/or replace the Filters after the specified time period.

• Clean the hood using a damp cloth and a neutral liquid detergent.

650 mm min.

Produkspesifikasjoner

Merke:	Roblin
Kategori:	eksoshette
Modell:	Latitude 1500 Centrale
Innebygd skjerm:	Nei
Bredde:	1498 mm
Dybde:	728 mm
Høyde:	- mm
Støynivå:	65 dB
Motor inkludert:	Ja
Antall motorer:	1
Støynivå (lav hastighet):	34 dB
Type fettfilter:	Rustfritt stål
Høyde (min):	780 mm
Antall filtre:	6 stykker
Produktfarge:	Rustfritt stål
Fjernkontroll medfølger:	Ja
Modell/Type:	Øy
Antall pærer:	4 ampuller
Kroppsmateriale:	Rustfritt stål
Avtagbart filter:	Ja
Type utvinning:	Ducted/Resirkulerende
Motoreffekt:	231 W
Høyde (max):	980 mm
Maksimal utvinningskraft:	988 m³/t
Intensiv hastighet:	Ja
Antall hastighetsnivåer:	8
Lyspæretype:	Fluorescent
Lampestyrke:	9 W
Støynivå (høy hastighet):	62 dB
Trykk (T):	605
Diameter på avtrekkstilkobling:	150 mm
Filterrengjøringsindikator:	Ja
Støynivå (medium hastighet):	45 dB
