Side 1/2
PACKAGE CONTENTS
• 2-outlet in-wall surge protector
• White decora-style wall plate
• Screws: 2 long and 2 short
• Quick Setup Guide
FEATURES
• Replaces a standard duplex outlet
• Status LED lets you know your devices are
protected
• Tamper-resistant outlets for added safety
• Provides two standard 125V power outlets
• 1,080 joules of surge protection
• Works in nearly all installations
• Compatible with your existing decora wall plate
We recommend that you use a professional electrician to
install the in-wall surge protector.
INSTALLING THE SURGE PROTECTOR
Warning: DISCONNECT POWER. Failure to do so can
result in severe injury or death.
1 Make sure that you disconnect power to the circuit
by removing the fuse from the circuit or turning
OFF the circuit breaker.
2 Remove the wall plate and mounting screws
that cover the old outlet.
3 Carefully remove the existing outlet from the
wall box.
4 Disconnect the wiring from the old outlet.
5 Connect the wires to the surge protector:
• Black lead attaches to the hot wire
• White lead attaches to the neutral wire
• Green lead attaches to the ground wire
You can attach the wires by:
A Inserting straight wires into the holes.
OR
A Wrapping the wires 3/4 of the way around
the terminal screws, making sure that the
wires do not overlap.
B Tighten every screw and make sure that no
bare copper wire is exposed.
SAFETY
Warnings:
• RISK OF ELECTRIC SHOCK — Use only in dry locations
and only indoors.
• All cables should be routed away from the outlet
openings.
• DO NOT use with any aquarium equipment.
• DO NOT install in an outlet that is not grounded.
Notes to the installer:
• This device must be installed in accordance with
National and Local electrical codes.
• To prevent severe shock or electrocution, always turn
power OFF at the service panel before working with
wiring.
• This device should be used with copper or copper-clad
wire. DO NOT use with aluminum wire.
• DO NOT plug this device into a shallow wall box. The
wall box must be deep enough to house the surge
protector. If the box is too shallow, the surge protector.
will not t securely into the wall.
Before using your new product, please read these instructions to prevent any damage.
PROTECTED/
PROTECTED/
FAULT
FAULT
TR
TR
AC outlets
(2)
Indicator
LED
Ground
(green)
Neutral
(white)
Hot
(black)
Front
QUICK SETUP GUIDE
RF-HTS120W22 | 2-outlet In-wall Surge Protector
Back
RF-HTS120W22_22-0836 _QSG_V1_EN_Final.ai 1 10/5/2022 9:23:07 AM
