This tank accessory is for use with RYOBI P2807, P2808, and
P28010 handheld electrostatic sprayers ONLY.
WARNING!
To reduce the risk of injury, user must read and understand the
operator’s manual for their electrostatic sprayer and this in-
struction sheet. Always wear eye protection with side shields
marked to comply with ANSI Z87.1, as well as any other safety
equipment required due to the solution being sprayed. Ensure
compatibility and fit before using this accessory. Do not use
this accessory if a part is damaged or missing.
WARNING!
Follow the chemical manufacturer’s safety instructions and
guidelines listed on the SDS sheet and/or product labeling
for use, cleaning, and storage. Clean thoroughly after each
use, following the instruc tions in the operator’s manual for
your electrostatic sprayer. Chemicals should be stored out
of the reach of children. Failure to do so may result in serious
personal injury.
CONNECTING THE TANK
See Figure 1.
Push the male barb on the hose onto the female quick con-
nect on the tank.
Pull on the hose to be certain it is properly secured.
ATTACHING/DETACHING THE QUICK CONNECT
HOSE
See Figure 2.
To attach hose:
Pull back the quick-connect collar.
Push the hose into place onto the male barb on the back of
the sprayer.
Push the collar forward so that the hose is secured properly.
Check to see that the hose is secure.
To disconnect hose:
Pull back and hold the quick-connect collar.
Remove the hose by pulling it from the quick-connect collar.
NOTE: Be careful when disconnecting the hose from the tank
because the liquid in the hose will drain from that end. Drain
remaining liquid back into container.
The electrostatic sprayer is now ready to use following the
instructions in your electrostatic sprayer operator’s manual.
TECHTRONIC INDUSTRIES
POWER EQUIPMENT
P.O. Box 1288, Anderson, SC 29622 USA
1-800-525-2579 www.ryobitools.com
ELECTROSTATIC SPRAYER
TANK ACCESSORY
ACES10 - 3 GALLON TANK
998000378
9-14-20 (REV:01)
A
B
Fig. 1
A - Quick connect hose (tuyau à raccord rapide, manguera de conexión rápida)
B - Hose barb (raccord cannelé du tuyau, conector de manguera)
A
B
Fig. 2
A - Hose barb (raccord cannelé du tuyau, conector de manguera)
B - Quick connect hose (tuyau à raccord rapide, manguera de conexión rápida)
