Salicru SLC 3000 TWIN PRO 2 Bruksanvisning

Salicru uforstyrret strømtilførsel (UPS) SLC 3000 TWIN PRO 2

Les nedenfor 📖 manual på norsk for Salicru SLC 3000 TWIN PRO 2 (28 sider) i kategorien uforstyrret strømtilførsel (UPS). Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/28

SLC TWIN PRO2

0,7.. 3 kVA

USER'S MANUAL

UNINTERRUPTIBLE POWER SUPPLY (UPS)

SLC TWIN PRO2

0.7.. 3 kVA

General index

1. INTRODUCTION.

1.1. ACKNOWLEDGEMENT LETTER.

2. INFORMATION FOR SAFETY.

2.1. USING THIS MANUAL.

2.1.1. Conventions and used symbols.

3. QUALITY AND STANDARD GUARANTEE.

3.1. DECLARATION OF THE MANAGEMENT.

3.2. STANDARD.

3.3. ENVIRONMENT.

4. PRESENTATION.

4.1. VIEWS.

4.1.1. Views of the equipment.

4.1.2. Frontal UPS panel.

4.1.3. Rear panel IEC.

4.1.4. Rear panel schuko.

4.1.5. Frontal battery panel.

4.1.6. Rear battery panel.

4.2. DEFINITION OF THE PRODUCT.

4.2.1. Nomenclature.

4.3. OPERATING PRINCIPLE.

4.3.1. Main features.

4.4. OPTIONS.

4.4.1. Isolation transformer.

4.4.2. External maintenance manual bypass.

4.4.3. Integration in IT networks by means of the SNMP adaptor.

4.4.4. MODBUS protocol.

5. INSTALLATION.

5.1. RECEPTION OF THE EQUIPMENT.

5.1.1. Inspection.

5.1.2. Unpacking.

5.1.3. Content checking.

5.1.4. Storage.

5.1.5. Transport to location.

5.1.6. Preliminary considerations, before connecting the equipment.

5.2. CONNECTION.

5.2.1. Connection of input.

5.2.2. Connection to output.

5.2.3. Connection of external batteries [extended back up times] -B1- or

models without batteries -B0-.

5.2.4. Terminals for EPO (Emergency Power Off).

5.2.5. Communication ports.

5.2.5.1. USB interface.

5.2.5.2. Smart slot.

5.2.6. Software.

5.2.7. Considerations before starting up.

6. OPERATING.

6.1. UPS COMMISSIONING AND SHUTDOWN.

6.1.1. Preliminary controls.

6.1.2. Start up the UPS, with AC mains.

6.1.3. Start up the UPS, with no AC mains (Battery mode)

6.1.4. UPS shutdown with AC mains (on Inverter mode).

6.1.5. UPS shutdown with no AC mains [on Battery mode].

6.1.6. Battery test function.

6.1.7. Alarm silencer.

6.1.8. EPO (Emergency Power Output).

7. CONTROL PANEL WITH LCD.

7.1. CONTROL PANEL.

7.2. SETTING AND CONFIGURATION OF THE CONTROL PANEL.

7.2.1. Bypass mode -byPA-.

7.2.2. No output mode -STby-.

7.2.3. Line mode -LINE-.

7.2.4. Battery mode / Battery test mode -bATT / TEST-.

7.2.5. Economy mode -ECO-.

7.2.6. Converter mode -CUF-.

7.2.7. Fault code / Alarm code.

7.3. SETTINGS THROUGH THE LCD PANEL OF THE LCD PANEL.

8. MAINTENANCE, WARRANTY AND SERVICE.

8.1. BATTERY MAINTENANCE.

8.1.1. Notes for installing and replacing the batteries.

8.2. UPS TROUBLE SHOOTING GUIDE.

8.2.1. Troubleshooting guide. Warning indications.

8.3. WARRANTY CONDITIONS.

8.3.1. Warranty terms.

8.3.2. Out of scope of supply.

8.4. TECHNICAL SERVICE NETWORK.

9. ANNEXES.

9.1. GENERAL TECHNICAL SPECIFICATIONS.

9.2. GLOSSARY.

SLC TWIN PRO2 UNINTERRUPTIBLE POWER SUPPLY (UPS)USER'S MANUAL

Produkspesifikasjoner

Merke:	Salicru
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	SLC 3000 TWIN PRO 2
Vekt:	22700 g
Bredde:	190 mm
Dybde:	399 mm
Høyde:	327 mm
Støynivå:	49 dB
LED-indikatorer:	Batteribytte
USB-port:	Ja
Antall USB 2.0-porter:	1
Utgangseffekt:	2700 W
Sikkerhet:	EN 62040-1:2008+A1:2013
Utgangsspenning (maks.):	240 V
Batteriteknologi:	Blykalsium (Pb-Ca)
Batteritype:	AGM
UPS topologi:	Dobbeltkonvertering (Online)
Antall inngangsfaser:	1
Hørbare alarmmoduser:	Fault, Low battery alarm, Overload alarm, Battery replacement
Antall utgangsfaser:	1
Bølgeform:	Ren sinus
Batteriladetid:	4 timer
Effektivitet (ECO-modus):	98
Automatisk batteritest:	Ja
Inngangsspenning (maks.):	240 V
Produktfarge:	Sort
Skjermtype:	LCD
Driftstemperatur (T-T):	0 - 40 °C
Harmonisert system (HS)-kode:	85078000
Formfaktor:	Tower
Inngangsfrekvens:	50/60 Hz
Overspenningsvern:	Ja
Strømbeskyttelsesfunksjoner:	Over current, Short circuit, Under current, Under voltage
Driftshøyde:	0 - 5000 m
Relativ luftfuktighet under drift (H-H):	0 - 95
Form for nedkjøling:	Aktiv
Antall AC outlets:	4 AC-utganger
ECO-funksjon:	Ja
Hørbare alarmer:	Ja
AC-utgangstyper:	Type F
Output strømkapasitet (VA):	3 kVA
Inngangsspenning (min.):	220 V
Utgangsspenning (min.):	220 V
Nødstrøm av (EPO):	Ja
Utgangsspenning total harmonisk forvrengning (THD):	2
Inngangsstrømfaktor:	0.99
Nød Kraft Av kontakt (EPO) (Emergency Power Off):	Ja
Utgangsstrømfaktor:	0.9
Output spenningsforskrift:	1
Inngangseffekt (THD):	2
Effektivitet (online modus):	92
Output frekvensforskrift:	0.05 Hz
Antall utganger (F-type):	4
Off-modus-lading:	Ja
Overbelastingskapasitet (1 minutt):	130
