Air conditioner

Installation manual

AC✴✴✴MXAD✴H

• Thank you for purchasing this Samsung air conditioner.

• Before operating this unit, please read this manual carefully and retain it for future

reference.

DB68-07433A-01_IM_CAC Universal SELA Outdoor_VN_EN_.indd 1DB68-07433A-01_IM_CAC Universal SELA Outdoor_VN_EN_.indd 1 2024-01-08 오후 4:07:332024-01-08 오후 4:07:33

English

Contents

Safety Information 3

General information 3

Installing the unit 4

Power supply line, fuse or circuit breaker 4

Installation Procedure 5

Step 1 Choosing the installation location 5

Step 2 Fixing the outdoor unit in place 8

Step 3 Connecting the power cables, communication cable, and controllers 9

Step 4 Optional: Extending the power cable 14

Step 5 Connecting the refrigerant pipe 16

Step 6 Optional: Cutting and flaring the pipes 17

Step 7 Installing oil traps 18

Step 8 Connecting up and removing air in the circuit 18

Step 9 Adding refrigerant (R-410A) 19

Step 10 Performing the gas leak test 22

Step 11 Connecting the drain hose to the outdoor unit 23

Step 12 Insulating the refrigerant pipes 23

Step 13 Checking the earthing 24

Step 14 Performing final check and trial operation 25

Extra procedures 28

Pumping down refrigerant 28

Relocating the indoor and outdoor units 28

Using the stop valve 29

Appendix 30

Troubleshooting 30

Correct Disposal of This Product

(Waste Electrical & Electronic Equipment)

(Applicable in countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.

charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. To

prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these

items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government

office, for details of where and how they can take these items for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract. This

product and its electronic accessories should not be mixed with other commercial wastes for disposal.

DB68-07433A-01_IM_CAC Universal SELA Outdoor_VN_EN_.indd 2DB68-07433A-01_IM_CAC Universal SELA Outdoor_VN_EN_.indd 2 2024-01-08 오후 4:07:332024-01-08 오후 4:07:33

English

Safety Information

WARNING

• Hazards or unsafe practices that may result in severe

personal injury or death.

CAUTION

• Hazards or unsafe practices that may result in minor

personal injury or property damage.

Carefully follow the precautions listed below because

they are essential to guarantee the safety of the

equipment.

WARNING

• Always disconnect the air conditioner from the power

supply before servicing it or accessing its internal

components.

• Verify that installation and testing operations are

performed by qualified personnel.

• Verify that the air conditioner is not installed in an

easily accessible area.

General information

WARNING

• Carefully read the content of this manual before

installing the air conditioner and store the manual in

a safe place in order to be able to use it as reference

after installation.

• For maximum safety, installers should always

carefully read the following warnings.

• Store the operation and installation manual in a safe

location and remember to hand it over to the new

owner if the air conditioner is sold or transferred.

• This manual explains how to install an indoor unit

with a split system with two SAMSUNG units. The use

of other types of units with different control systems

may damage the units and invalidate the warranty.

The manufacturer shall not be responsible for

damages arising from the use of non compliant units.

• The manufacturer shall not be responsible for damage

originating from unauthorized changes or the

improper connection of electric and requirements set

forth in the “Operating limits” table, included in the

manual, shall immediately invalidate the warranty.

• The air conditioner should be used only for the

applications for which it has been designed: the

indoor unit is not suitable to be installed in areas

used for laundry.

• Do not use the units if damaged. If problems occur,

switch the unit off and disconnect it from the power

supply.

• In order to prevent electric shocks, fires or injuries,

always stop the unit, disable the protection switch

and contact SAMSUNG’s technical support if the unit

produces smoke, if the power cable is hot or damaged

or if the unit is very noisy.

• Always remember to inspect the unit, electric

connections, refrigerant tubes and protections

regularly. These operations should be performed by

qualified personnel only.

• The unit contains moving parts, which should always

be kept out of the reach of children.

• Do not attempt to repair, move, alter or reinstall the

unit. If performed by unauthorized personnel, these

operations may cause electric shocks or fires.

• Do not place containers with liquids or other objects

on the unit.

• All the materials used for the manufacture and

packaging of the air conditioner are recyclable.

• The packing material and exhaust batteries of the

remote controller(optional) must be disposed of in

accordance with current laws.

• The air conditioner contains a refrigerant that has

to be disposed of as special waste. At the end of its

life cycle, the air conditioner must be disposed of in

authorized centres or returned to the retailer so that

it can be disposed of correctly and safely.

Safety Information
