Samsung S27CM500EU Bruksanvisning

Samsung skjerm S27CM500EU

Les nedenfor 📖 manual på norsk for Samsung S27CM500EU (35 sider) i kategorien skjerm. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/35

The colour and the appearance may differ depending on the product, and the specifications are subject to change without prior

notice to improve the performance.

The contents of this manual are subject to change without notice to improve quality.

An administration fee may be charged in the following situations:

(a) An engineer is called out at your request, but it is found that the product has no defect (i.e., where the user manual has

not been read).

(b) You bring the unit to a repair centre, but it is found that the product has no defect (i.e., where the user manual has not

been read).

You will be informed of the administration fee amount before a technician visits.

Samsung owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung is prohibited.

Trademarks other than that of Samsung are owned by their respective owners.

User Manual

S27CM50* S32CM50* S27CM70* S32CM70* S27CM80*

S32CM80* S27C90*

Contents

Precautions and Notes

Read After Installing the product

28 Picture sizes and input signals

Supported Resolutions for UHD Input Signals

29 If Input Signal Plus is set to Off

29 If Input Signal Plus is set to On

Read Before Connecting a Computer (Supported Resolutions)

30 VESA DMT

31 VESA CVT

Supported Resolutions for Video Signals

32 CTA-861

32 List of graphic cards supporting HDR10

Specifications

General

Appendix

Responsibility for the Pay Service (Cost to Customers)

35 Not a product defect

35 A Product damage caused by customer’s fault

35 Others

Before Using the Product

Safety Precautions

3 Electricity and Safety

4 Installation

4 Operation

Cleaning

Correct posture to use the product

Preparations

Installation

7 Attaching the Stand

10 Connecting the camera to the product

11 Precautions for moving the product

13 Checking the space around the product

14 Adjusting the Product Tilt and Height

16 Rotating the Product

18 Anti-theft Lock

19 Wall Mount Kit Specifications (VESA)

Control Panel

Connections

Ports

25 Connection Using a Thunderbolt™ 4 Cable or USB Type-C

Cable

26 Connecting the Product to a PC as a USB HUB

Tidying Up the Connected Cables

- 3 -

Before Using the Product

Safety Precautions

Warning

A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are not followed.

CAUTION

RISK OF ELECTRIC SHOCK. DO NOT OPEN.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). THERE ARE NO USER SERVICEABLE

PARTS INSIDE. REFER ALL SERVICING TO QUALIFIED PERSONNEL.

This symbol indicates that high voltage is

present inside. It is dangerous to make any

kind of contact with any internal part of this

product.

AC voltage: Rated voltage marked with this

symbol is AC voltage.

This symbol indicates that this product has

included important literature concerning

operation and maintenance.

DC voltage: Rated voltage marked with this

symbol is DC voltage.

Class II product: This symbol indicates that a

safety connection to electrical earth (ground)

is not required. If this symbol is not present

on a product with a mains lead, the product

MUST have a reliable connection to protective

earth (ground).

Caution. Consult instructions for use: This

symbol instructs the user to consult the user

manual for further safety related information.

Electricity and Safety

Warning

● Do not use a damaged power cord or plug, or a loose power socket.

● Do not use multiple products with a single power socket.

● Do not touch the power plug with wet hands.

● Insert the power plug all the way in so it is not loose.

● Connect the power plug to a grounded power socket (type 1 insulated devices only).

● Do not bend or pull the power cord with force. Be careful not to leave the power cord under a heavy object.

● Do not place the power cord or product near heat sources.

● Clean any dust around the pins of the power plug or the power socket with a dry cloth.

Caution

● Do not disconnect the power cord while the product is being used.

● Only use the power cord provided with your product by Samsung. Do not use the power cord with other products.

● Keep the power socket where the power cord is connected unobstructed.

– The power cord must be disconnected to cut off power to the product when an issue occurs.

● Hold the plug when disconnecting the power cord from the power socket.

Produkspesifikasjoner

Merke:	Samsung
Kategori:	skjerm
Modell:	S27CM500EU
Farge:	Sort
Bluetooth:	Ja
Berøringsskjerm:	Nei
Wi-Fi:	Ja
Wi-Fi-standarder:	Wi-Fi 5 (802.11ac)
Bluetooth-versjon:	5.2
Synsvinkel, horisontal:	178 °
Skjermform:	Flat
Pakkevekt:	6100 g
Antall HDMI-porter:	2
Innebygde høyttalere:	Ja
Strømforbruk (maks.):	50 W
HDCP:	Ja
Maksimal oppdateringshastighet:	60 Hz
HDMI:	Ja
HDMI-versjon:	1.4
Skjermteknologi:	LED
Innebygd kamera:	Nei
Energiforbruk (HDR) per 1000 timer:	32 kWh
Energieffektivitetsklasse (SDR):	E
Energiforbruk (SDR) per 1000 timer:	21 kWh
Energieffektivitetsklasse (HDR):	G
Vekt (med stativ):	4800 g
AMD FreeSync:	Nei
NVIDIA G-SYNC:	Nei
Antall USB Type-A nedstrømsporter:	2
Spillmodus:	Ja
Innebygd USB-hub:	Ja
Flimmerfri teknologi:	Ja
HDCP-versjon:	2.2
Kontrastforhold:	3000:1
AC-inngangsspenning:	100 - 240 V
Skjermoppløsning:	1920 x 1080 piksler
Strømforbruk (standby):	0.5 W
Anynet + (HDMI-CEC):	Ja
TV Plus:	Ja
Høydejustering:	Nei
Produktfarge:	Sort
Type strømforsyning:	Innvendig lys
HD-type:	Full HD
Vippevinkelområde:	-2 - 22 °
Bredde (uten stativ):	615.5 mm
Høyde (uten stativ):	367.9 mm
Vekt (uten stativ):	3600 g
Bredde (med stativ):	615.5 mm
Dybde (med stativ):	193.5 mm
Høyde (med stativ):	455.4 mm
Pakkedybde:	428 mm
Pakkehøyde:	126 mm
Pakkebredde:	738 mm
Skjermdiagonal:	27 "
Naturlig sideforhold:	16:9
Operativsystemprogramvare 04:	Tizen
Kabler inkludert:	AC, HDMI
Pakketype:	Boks
Strømforbruk (vanlig bruk):	21 W
Driftstemperatur (T-T):	10 - 40 °C
Fjernkontroll medfølger:	Ja
VESA-montering:	Ja
Dybde (uten stativ):	41.8 mm
Paneltype:	VA
Synsvinkel, vertikal:	178 °
SmartThings-appstøtte:	Ja
Diagonal skjermstørrelse:	68 cm
HDR-teknologi (High Dynamic Range):	High Dynamic Range 10 (HDR10)
Støttede Windows operativsystemer:	Windows 10
Relativ luftfuktighet under drift (H-H):	10 - 80
Oppdateringsresponstid:	4 ms
Panelmonterbart grensesnitt:	100 x 100 mm
Markedsplassering:	Smart
Skjermlysstyrke (typisk):	250 cd/m²
Display antall farger:	1 milliarder farger
Vippjustering:	Ja
Europeisk produktregister for energimerking (EPREL-kode):	1450071
Bildestørrelse, horisontal:	597.888 mm
Bildestørrelse, vertikal:	336.312 mm
Plugg inn og spill:	Ja
HDR (High Dynamic Range) støttes:	Ja
Strømkabelens lengde:	1.5 m
Trykkvisning:	Ja
Wireless Dex-støtte:	Ja
Skjerm-lysstyrke (min):	200 cd/m²
Kompatibel med Office 365:	Ja
Samsung Eye sparetilstand:	Ja
