Sangean PT-10 Bruksanvisning

Sangean radioer PT-10

Les nedenfor 📖 manual på norsk for Sangean PT-10 (11 sider) i kategorien radioer. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/11

-10

ersion 1

CARE AND SAFETY

________________________________________________

This device is designed for the playback of audio signals.

Any other use is expressly prohibited.

Protect the device from moisture (water drops or splashes).

When deciding where to place the device, please note that furniture surfaces are covered

by various types of varnish and plastic, most of which contain chemical additives. These

additives can corrode the device supports, leaving residues on the furniture surfaces which

can be difficult or impossible to remove.

Do not use any cleaning agent, as this may damage the casing. Clean the device with a

clean, moist leather cloth. Never open the device casing. Warranty claims are excluded for

damage resulting from improper handling.

The type plate is located on the bottom of the device.

Attention

Continuous use of earphones at high volume can damage the user’s hearing.

Environmental note

As little material as possible was used in the packaging of your device. It can be divided

into two separate materials: cardboard (box) and polyethylene (bag). Please observe the

local regulations for disposing of the packing material.

49m

75m

41m

31m

25m

22m

19m

16m

13m

kHz

MHz

5.95 6.00 6.10 6.20

3.90 3.95 4.00

7.10 7.25 7.30 7.40 7.50

9.50 9.60 9.70 9.80 9.90

11.65 11.80 11.85 11.95 12.05

13.60 13.65 13.70 13.75 13.80

15.15 15.25 15.30 15.45 15.55 15.60

17.50 17.60 17.70 17.85 17.90

21.40 21.55 21.65 21.75 21.85

145 165 185 200 220 240 260 280

520 600 800 1000 1200 1400 1600

88 92 96 100 104 108

! SERVICE !

02 Yacht Boy 10, GB 19.08.2003 13:45 Uhr Seite 14

ENGLISH

OVERVIEW

____________________________________________

Controls

Front

•

LED. Lights up when a stereo station is recei-

ved and when earphones are connected

SW 1 ... 9 Tuning scale for SW,

LW MW FM LW, MW and FM wavebands

Right side of device

ON/OFF Switches the device on and off

VOLUME

| Adjusts the volume

TUNING Control dial for tuning to radio stations

Left side of device

STEREO MONO Switches between stereo and mono reception

in earphone mode

0Socket for earphones (3.5 mm stereo jack)

49m

75m

41m

31m

25m

22m

19m

16m

13m

kHz

MHz
