Saramonic SmartRig II Bruksanvisning

Saramonic Mikrofon SmartRig II

Les nedenfor 📖 manual på norsk for Saramonic SmartRig II (2 sider) i kategorien Mikrofon. Denne guiden var nyttig for 6 personer og ble vurdert med 4.7 stjerner i gjennomsnitt av 3.5 brukere

Last ned PDF

Side 1/2

User Manual

Product Structure

Specifications

Frequency Response

Noise

Maximum output level

Distortion

Phantom max current

Dimensions

Weight

20Hz to 20kHz (+/-1.5dB)

-98 dB full band, phantom power ON

2 Vrms

0.025% THD

13mA

L 88 x W 41 x H 42 mm

75g ( 2.57oz. )

SmartRig II

Audio Adapter

The SmartRig II from Saramonic is an easy solution

to connect professional microphones/guitars with

your iPhone, iPad, iPod touch and Android devices

PRODUCT INTRODUCTION

General Introductions

The SmartRig II from Saramonic is an easy solution to

connect professional microphones/guitars with your

iPhone, iPad, iPod touch and Android devices.

As a high-quality microphone preamp, SmartRig II allows

you to use professional stage microphones or high-end

studio microphones to create music with your iOS or

Android devices.

Simply plug the microphone into the standard XLR

connector of SmartRig II and connect it to your device with

the 3.5mm output cable.

The provided gain control thumbwheel makes it easy to set

precise levels. Processed sound can be monitored through

a 3.5mm headphone out.

Highlights

• Combo 1/4" (6.35mm) and XLR input

• Power/Phantom power provided by 9V battery

• +48V phantom power

• 3.5mm headphone output for monitoring

• +48V/OFF/ON switch

• Gain control

• Power/Phantom power provided by 9V battery

Produkspesifikasjoner

Merke:	Saramonic
Kategori:	Mikrofon
Modell:	SmartRig II
Bredde:	41 mm
Dybde:	88 mm
Høyde:	42 mm
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Volumkontroll:	Knapper
Mikrofonfrekvens:	20 - 20000 Hz
Mikrofonvekt:	75 g
Produktfarge:	Sort
Mikrofon, linje-inn-støpsel:	Ja
Enhetsgrensesnitt:	6.35 mm (1/4")
Modell/Type:	Gitarmikrofon
Av/på-bryter:	Ja
Antall medfølgende produkter:	1 stykker
Plugg inn og spill:	Ja
Mikrofonsensitivitet/mikrofonfølsomhet:	-98 dB
XLR utgang:	1
Mikrofon Total Harmonic Distortion (THD):	0.025
RF-effekt:	13 mW
