Side 1/2
Si-52
Peristaltic pump
Sauermann
®
part #: SI52CE01UN23
This peristaltic pump is designed for all types of air conditioners up to 8 kW: wall
units, air conditioning cabinets, ceiling units and ducted units.
The Si-52 is controlled by its oat switch (3 levels: on, off, safety). The safety
contact automatically stops the air conditioner compressor or solenoid valve to
prevent condensate overow.
Not for continuous operation.
Kit content
• Peristaltic pump Si-52
• Cable: 1.7 m, including 2 wires for power
supply (P & N)
• 2 safety switch wires (1.7 m)
• Easy 2-screw sliding plastic bracket
• Detection unit (SI2958, 1.5 m cable)
• Detection unit installation kit:
- Vent tube int. Ø 4 x L 75 mm
- Mounting rail
- Adhesive
• 90° connector Ø 15 mm - 45 x 152 mm
DATA SHEET
Benets
High performance
• Condensate discharge up to 12 m high
• Quiet, vibration-free operation
Easy installation
• Compact size: L105 x W108 x H122 mm
• IP55 protection for installation in
unventilated areas
Extended reliability
• Thick, reinforced tube for longer service life
• Resistance to contaminated condensate
(particles and chemicals)
Quick maintenance
• Easy-to-open front panel without tools
for tube replacement
• Glass fuse replaceable in one easy step
(standard cartridge 5 x 20)
For use with any air-conditioning
units up to 8 kW
Technical specications
Applications
Actual ow rate (l/h)
sauermanngroup.com
SI52CE12UN23_EN - 12/06/2025 – Non-contractual document. We reserve the right to modify the characteristics on our products without prior notice.
Max. ow rate 6 l/h
Max suction head 2 m
Max discharge head 12 m
Sound level in application at 1m
(Measured in Sauermann acoustic lab,
pump operating with water)
≤ 30 dBA
Mains supply 230 V~ 50 Hz - 11 W
Insulation class
(double insulation)
Detection type Detection unit oat
Detection levels On: 16 mm; Off: 11 mm; Safety: 19 mm
Safety switch NF 8A resistive – 250 V
Protection IP55
Pump dimensions L 105 x W 108 x H 122 mm
Detection unit dimensions L 55 x W 38 x H 37.5 mm
Safety standards CE & UKCA
RoHS directive Compliant
WEEE directive Compliant
Packaging 1.04 kg
Masterpack 24 pieces
Total tube length (int. Ø 6 mm; 1/4’’)
Max suction
head
Max discharge
head
The discharge ow is constant whatever the discharge or the
suction head
2 m 12 m 6
Accessories
• Wall mounted
• Computer room air
conditioning
• Ceiling suspended
• Ducted
Name #Part
Clear PVC hose
int. Ø 6 mm (1/4’’)
ACC00909 (5 m)
ACC00910 (50 m)
Replacement head
for Si-50, Si-51, Si-52
ACC00954
Multi diameter
reducing adaptor
to connect tubes of
Ø 15 mm (3/5’’),
Ø 6 mm (1/4’’)
ACC00927
Replacement hose
for Si-50, Si-51, Si-52
ACC00953
6 self-sealing ttings
for hose int. Ø 6 mm
(1/4’’)
ACC00919
Detection unit 1.5 m
power cable
SI2958
