Side 1/1
1
Choose a at mounting location ensuring there is adequate
space around and behind the mounting surface. Use the
template provided to mark the corners and drill center for
hole saw.
2
Use ø65mm hole saw to cut the hole, deburr and
thoroughly clean surface with an alcohol wipe.
3
Input voltage range : 10-30V DC (12/24V system)
Input current max: 2A
Output power: 10W (9V 1.1A)
Standby current draw: < 0.2W
Certications: Qi, CE, UKCA, FCC, ROHS,
UNECE R10 E24, RCM, PSE, IC
Waterproof rating: IPX6 front and back
Max phone size: 176mm (6.92”) x 94mm (3.70”)
(Including case)
4
Technical Information
READ THE IMPORTANT SAFETY INFORMATION
LEAFLET BEFORE INSTALLING
Scanstrut ROKK Wireless - Catch
Wireless charger (SC-CW-07F)
5
7
Peel o centre piece of self adhesive backing and remove
protective lm from the SC-CW-07F charger. Place the
SC-CW- 07F charger in recess.
Ensure there is no air trapped between charger and self
adhesive tape.
Peel o the remaining self adhesive
backing from the charging mat, as
well as the self adhesive backing on
the SC-CW-07F charger.
Connect wires to 12/24V supply,
ensuring a waterproof connection.
Fuse according to input voltage
and current.
6
Guide the wire of SC-CW-07F through
hole and align charging mat. Once
aligned rmly press down into place.
Tools Required
Powerdrill
Hole Saw
ø
65mm (2.56”)
x1
Parts List
Phone Charging
Mat
x1
SC-CW-07F
Sub Wireless Charger
x1
Alcohol Wipe
Installation Instructions
Scanstrut ROKK Wireless - Catch 10W (SC-CW-08F)
09-06-2022 Issue 2
