Side 1/6

WCO100 Camera

WCO100 Camera MAC ID

Twelve (12) characters

Lens

PowerLED

PIRSensor

Microphone

_________________ (not used)

Light

S e n s o r

P o w e r

P o r t

Reset Button

Antenna

MAC ID

E t h e r n e t

P o r t

Final position,

upright

Package Contents:

Outdoor Camera

External Antenna

6-foot Power Adapter

Swivel Connector

Mounting Stand

Mounting Base

Mounting Screws (3)

Ethernet Cable (with water sealing cap)

6-foot Power Extension Cable (with water sealing cap)

1Attach antenna to the camera

Turn the antenna clockwise on the antenna mount.

The antenna should be in an upright position for

best signal reception.

2Locate MAC ID, Ethernet and Power.

Write the MAC ID in the box at the top of this page for later reference.

DO NOT plug in Ethernet or power before enrolling!

3Log into your account at www.mynexia.com

Camera can be used only with Nexia Home Intelligence system.

Account must be active before continuing. See nexiahome.com for more information.

Enroll the Camera

a. Make sure Ethernet and power are NOT plugged into camera before you begin.

b. On www.mynexia.com, click the Cameras tab.

c. Click the Add Camera button.

d. Follow the on-screen instructions.

e. Click on Edit Camera Settings to complete wireless setup.

Verify and Prepare Camera Mounting Location

! Installation in a covered area is recommended.

! Consult the NEC and local electrical codes for information

on electrical requirements.

a. Attach the base to the wall with three (3) screws and

wall anchors (included).

b. Attach the power cable to AC power outlet. Make sure

the water seal is secure on the wall.

Attach Camera to Stand

Turn Camera clockwise to attach threaded mount on back of

camera to the swivel connector.

Base

Wall anchors (3)

Test the camera view using your Nexia Account.

If necessary, loosen the knob on the swivel connector and adjust the camera angle.

Product Specications

Lens: Board Mount Type, Fixed-Focal, Aperture F2.0

Night Vision: IR LED x 8, Light Sensor x 1, Auto IR CUT Switcher, Range: Above 5 meters

Minimum Illumination: 0 Lux (with IR LED)

Connectors: RJ45 for Ethernet, DC Power Jack

Power Consumption: 12V DC, Max 4.8W

Compliance: CE, FCC, Power supply: UL

Dimensions (H x W x D): 103 x 94 x 37 mm (4.1”x 3.7”x 1.5”)

Weight: 900g (2 lbs)

Operating Temperature: -10°–45°C (14°–113°F); Humidity: 10%–80% (non-condensing)

Storage Temperature: -20°–70°C (-4°–158°F); Humidity: 10%–90% (non-condensing)

Ethernet: 10/100 Base-T, Auto MDIX

Wireless: IEEE802.11b/g/n, WEP64/128 bit, WPA/WPA2 Personal, WPS

FCC Statement

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this
