© 2013 Schneider Electric 1
Metering Gateway Modbus REG-K
MTN6503-0201
Application Metering Gateway 7602/1.0
Metering Gateway Modbus REG-K MTN6503-0201© Me rten 200902/13
|
Many parameters and their settings are depend-
ent on the settings you have already made for oth-
er parameters. This means that some parameters
will appear or disappear and the values available
for selection will change according to settings you
have already made. These dependencies have
not been shown in the table for reasons of clarity.
All settings are always shown.
|
Configurable times are set via the base and factor
parameters. The actual time is given by the multi-
plication of the two values. Example:
Base = 1 second, Factor = 3
Actual time = 3 seconds
|
The bold values in a table are the values set dur-
ing factory configuration.
Table of contents
The KNX Metering Gateway is a device which connects
meters via the Modbus open standard to KNX. The
Modbus open standard allows you to receive a more in-
depth analysis of consumption in all areas of your build-
ing.
You can connect up to 10 of the following types of me-
ters based on Modbus remote terminal unit (RTU):
• Schneider Electric energy meters
• Schneider Electric power meters
• Schneider Electric Smart Interface Modules (SIM10M
module)
• Non-Schneider Electric Modbus RTU devices (offer-
ing you greater flexibility)
With the information which the KNX Metering Gateway
provides you can visualise energy or media consump-
tion. This can also be used to reduce consumption
through the use of control strategies within the KNX net-
work.
You can choose from 17 different pre-prepared tem-
plates for the meters and devices in order to quickly
connect to a KNX network. Each template contains the
20 most frequently needed Modbus values for simple
configuration.
From each connected Modbus RTU device the KNX
Metering Gateway can read up to an additional 40 Mod-
bus register values and transfer this data to the KNX
network.
You can read up to 10 meters using one KNX Metering
gateway. This makes the Gateway very cost-efficient.
Integrating a SIM10 module makes it possible to deter-
mine and visualise gas and water consumption.
The KNX Metering Gateway is also suitable for retrofit-
ting or for retroactive connection of existing Modbus
systems to KNX because it is fully compatible with me-
ters from other manufacturers.
The application is influenced by the following events:
• ETS download
• Bus voltage failure
• Bus voltage recovery
The behaviour differs according to function and can in-
fluence the measuring and monitoring function. There-
fore, you can set the behaviour using parameters at the
corresponding point. Refer to the chapter in question
for a precise description.
Application Metering Gateway 7602/1.0
• Function overview
1
• Behaviour of the application
1
• Modbus settings
2
• Metering device templates
3
– Metering device x
3
– Voltage and current monitor
4
– Power monitor
4
– Consumption monitor
5
– Template for SIM10M module
6
• Direct access to Modbus register
7
– Access to register X
7
– Modbus register X
7
• Diagnostic block
8
• Overview of parameters
9
• Overview of communication objects
11
Function overview
Behaviour of the application
