HEATED COUNTERTOP
FRY DUMP STATION
RETAIN THIS MANUAL FOR FUTURE REFERENCE. UNIT MUST BE KEPT CLEAR
OF COMBUSTIBLES AT ALL TIMES.
Models: 423FFDS17, 423FFDS22, 423FFDS26
1/24
www.servitproducts.com
PARTS MANUAL
www.servitproducts.com
HEATED COUNERTOP FRY DUMP STATION- PARTS MANUAL
REV 12/23
2
27
20
2
3
6
21
5
1
22
23
8
11
10
9
28
14
19
16
24
18
17
30
12
4
7
15
13
26
29
KEY PART # DESCRIPTION
QUANTITY
17 22 26
1 --- Cover, Top 1 1 1
2 --- Support plate 1 1 1
3 --- Base 1 1 1
4 --- Side sealing plate 111
5 --- Inner protective wire board 1 1 1
6 --- Outer protective wire board 111
7
423FDSP171
Fry Box Ribbon for FFDS17 1 --- ---
423FDSP221
Fry Box Ribbon for FFDS22
---
1 ---
423FDSP261
Fry Box Ribbon for FFDS26
---
--- 1
8
423FDSP172
Fry Pan Divider for FFDS17 1 --- ---
423FDSP222
Fry Pan Divider for FFDS22 ---
1
---
423FDSP262
Fry Pan Divider for FFDS26 ---
---
1
9
423FDSPSH
Scoop Holder 111
10
423FDSPFH
Tong Holder
1
1 1
11 --- Trivet 111
12 --- Support
1
2 2
13 --- Heat Reflector Plate 1 2 2
KEY PART # DESCRIPTION
QUANTITY
17 22 26
14 --- Cover, Bottom
1
1 1
15 --- Wire Guard 1 2 2
16 --- Control Guard
1
1 1
17 --- Decal, Control 1 1 1
18 --- Upper Insulation Cotton
1
1 1
19 --- Lower Insulation Cotton 1 1 1
20 --- Wiring base
1
2 2
21 --- Protective coil 2 2 2
22 423FDSPPWR Cord and Plug
1
1 1
23 --- Cord Grip 1 1 1
24 423FDSPSWCH Power Switch
1
1 1
25 Upper Heating Element423FDSPELEM 1 2 2
26 --- Light Bulbs
2
2 2
27 --- Light Socket with Leads 111
28 Rubber Feet423FDSPFEET
4
4 4
29 --- Pan 1 1 1
30 --- Blanket Element
1
1 1
PARTS LIST & DIAGRAM
25
