Side 1/24

5.25" device bay to 3.5" SAS/SATA 6.0 Gbit/s

trayless hot-swap cage

Front Panel Storage

FS303 / FS304 / FS305

5 25" d i b t 3 5"

bit

FS304

FS305

The following manual and guides were carefully prepared by the SilverStone engineering team to

help you maximize the potential of your SilverStone product. Please keep this manual for future

reference when upgrading or performing maintenance on your system. A copy of this manual can also

be downloaded from our website at:

Installation and system optimization guide:

Product Overview

Installation Chart

Indicator Status

Warranty

P.1

P.6

P.10

P.21

Product Overview

Front Panel Storage

Specifications

To accommodate PC user’s need for more storage flexibility and convenience, SilverStone created a line of front bay storage products

called the FS series. These are 5.25” bay chassis designed to fit 3.5” or 2.5” SAS/SATA drives. Equipped with release handle made out

of finely brushed aluminum, hot-swapping drives is extremely quick and comfortable. Built-in cooling fan behind the chassis ensures

drive and run cool for extended life while individual LED indicators let user easily monitor drive status in one glance. For security, each

drive tray also has metal key lock. For those that need to upgrade their current PC with more drives, SilverStone’s FS series is a great

choice.

FS303 FS304 FS305

Model

Color

Material

Form factor

Drive support

Transfer rate

Host interface

Power connector

Drive door security

Number of Key

LED indicator

Cooling fan

Switch button

Net weight

Dimension

SST-FS303B, SST-FS304B, SST-FS305B

Black

Aluminum and front bezel with plastic clip button

5.25” drive bay

3.5” SAS/SATA HDD or SSD

Up to 6 Gbit/s (dependent on drive speed)

7-Pin SATA connector X3 or SAS primary channel connection (FS303)

7-Pin SATA connector X4 or SAS primary channel connection (FS304)

7-Pin SATA connector X5 or SAS primary channel connection (FS305)

SATA 15-Pin X2

Triangle metal key lock design

Power ON : Blue

Accessing : Purple blinking

70mm fan x 1, 3000rpm (FS303)

80mm fan x 1, 3000rpm (FS304, FS305)

Fan speed

HDD LED

1.02kg (FS303)

1.45kg (FS304)

1.40kg (FS305)

High/Low

ON/OFF

Introduction

Fits 3.5” SAS/SATA 6Gbit/s drives in 5.25” device bay

Adjustable drive status LED and fan control system

Trayless & screwless design

Individual metal key lock for each drive for extra security

All aluminum body with beautiful hairline brushed finish

Independent drive status LED

Built-in cooling fan for excellent heat dissipation

Fully supports SATA Hot-Swap function

Special Features

r those that need to up

rade their current P

FS3

ice

FS30

ecial Features

erStone created a line of front ba

sto

ATA drives.

uip

ped

with release ha

ble. Built-in coolin

fan behind the ch

onitor drive status in one

lance. For

drives, SilverStone’s FS se

FS305

with mor

146

mm (W) 84.5 mm (H)

195mm (D) , FS303

146

mm (W) 126mm (H)

199mm (D) , FS305

146

mm (W) 125mm (H)

98mm (D) , FS304

Produkspesifikasjoner

Merke:	SilverStone
Kategori:	Uenighet
Modell:	FS303
Vekt:	1020 g
Bredde:	146 mm
Dybde:	195 mm
Høyde:	84.5 mm
LED-indikatorer:	Ja
Maksimal støttet lagringskapasitet:	- TB
Enhetsklasse:	Hjem og hjemmekontor
Dataoverføringshastighet:	6 Gbit/s
Produktfarge:	Sort
Harmonisert system (HS)-kode:	84717020
Antall lagringsdrivere som støttes:	3
Intern:	Ja
Antall vifter:	1 vifter
Fullstendig installert lagringskapasitet:	- TB
Installert lagringsdrivertype:	Nei
Støttet lagrings drive type:	HDD & SSD
Grensesnitt for lagringsdriver:	SATA
Lagringsstasjonens størrelse:	3.5 "
Hot-swap drive bays:	Ja
Lagerdrivere installert:	Nei
SATA-vertsport:	Ja
