High Performance Triple 120mm All-In-One Liquid Cooler for AMD Socket sTR5/SP6
XE360-TR5
www.silverstonetek.com
User manual
Contents
BA
Fan Screw x12
C
4pin Peripheral
adapter cable x1
Case Screw x12
D
3 in 1 Fan cable x1
A
A
B
B
PSU
AIO_PUMP
CPU_FAN
C D
C
D
Remove the protection cover of thermal interface material (TIM) or thermal grease. The required amount of TIM has been
pre-applied on the bottom of the heat sink.
Place the heat sink directly on top of the CPU (Figure 1) so that the four heat sink mounting screws are aligned with and
seated on the four heat sink mounting studs or nut standoffs on the socket stiffener frame.
Use a screwdriver with Torx T20 bit and adjust the screwdriver torque setting to 12.5~15.0 kgf-cm (10.8~13.0 lbf-in). Before
turning on the screwdriver, make sure that the screwdriver bit is fully engaged in the cavity of the heat sink mounting screw
head. Keep heat sink mounting screw vertical during installations.
Tighten the two diagonal heat sink mounting screws, i.e. the #1 and #2 screws (Figure 2), Then do the same with the
remaining two diagonal heat sink mounting screws.
Follow the diagonal installation pattern on all four heat sink mounting screws to ensure that the bottom of the heat sink is
properly seated on the CPU and to prevent the heat sink from tilting.
Figure 1 Figure 2
NO.1 Screw
NO.2 Screw
NO.3 Screw
NO.4 Screw
1.
2.
3.
4.
5.
G11251440
