SKS Air-X-Plorer Digi 10.0 Bruksanvisning
Les nedenfor 📖 manual på norsk for SKS Air-X-Plorer Digi 10.0 (6 sider) i kategorien pumpe. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/6
AUTO
SCHRADER
SCLAVERAND
PRESTA
DUNLOP
➋➋
➊➊
➊➊ ➋➋
MV-EASY-Info
AUTO
SCHRADER
SCLAVERAND
PRESTA
DUNLOP
➋➋
➊➊
➊➊ ➋➋
MV-EASY-Info
MAX
BAR
10
MAX
PSI
14 4
GERMANY
PRO
ECO
COMFORT
MANUAL ¬ AIR-X-PLORER DIGI 10.0 ¬ 11664
ALLROAD ROAD MOUNTAIN
Steel barrel
Digital pressure gauge
Steel base
Valve
disconnected
Valve connected
= pump
Ergonomic two-component handle
Valve head
GERMANY
Inbus 10
18
18
MANUAL ¬ AIR-X-PLORER DIGI 10.0 ¬ 11664
ALLROAD ROAD MOUNTAIN
Exchange gauge oor pumps
1. Loosen the union nut on the pressure gauge cap. 2. Pull up the pressure gauge cap.
3.
Unscrew the pressure gauge at the bottom with
an Allen key (size 10).
4.
Insert a new pressure gauge into the pressure gauge holder.
5.
Screw on the pressure gauge with a
maximum torque of 2 Nm.
6.
Push the pressure gauge cap down again
and secure it with the union nut.
GERMANY
MANUAL ¬ AIR-X-PLORER DIGI 10.0 ¬ 11664
ALLROAD ROAD MOUNTAIN
Exchange rubber sealing cuff oor pumps
1. Remove the two Torx screws (T25)
of the hose holder. Pull the cylinder
rod out of the tube with a strong jerk.
3. Place the new cup over the cylinder rod until it is
positioned in the designated joint.
CAUTION: Make sure that it is on the correct side!
2. Remove the old cup seal. If necessary,
use a tool to do this (e.g. screwdriver).
4. Grease the rubber cup seal,
re-insert the cylinder rod and screw it in.
Produkspesifikasjoner
| Merke: | SKS |
| Kategori: | pumpe |
| Modell: | Air-X-Plorer Digi 10.0 |
