Side 1/20

24 - PRECAUTIONS 91477A872/A

PRECAUTIONS 24

General safety instructions 24

Installation 26

Appliance purpose 28

This user manual 28

Manufacturer’s liability 28

Identification plate 29

Disposal 29

Energy efficiency information 29

To save energy 29

How to read the user manual 29

DESCRIPTION 30

General description 30

USE 31

Precautions 31

Using the hob 31

CLEANING AND MAINTENANCE 33

Cleaning the hob 33

Cleaning the surfaces 33

What to do if... 33

INSTALLATION 34

Gas connection 34

Gas types and Countries 37

Burner and nozzle specifications tables 38

Electrical connection 40

Section cut from the countertop 40

Mounting 41

Fixing to the built-in cabinet 42

Instructions for the installer 43

These instructions apply only to the destination countries listed on the appliance's data plate.

This is a class 3 built-in hob.

PRECAUTIONS

General safety instructions

Risk of personal injury

• WARNING: During use the

appliance and its accessible

parts become very hot. Keep

children well away from the

appliance.

• Protect hands with heat resistant

gloves during use.

• Never try to put out a fire or

flames with water: Turn off the

appliance and smother the

flames with a fire blanket or

other appropriate cover.

• This appliance may only be

used by children aged 8 years

and over, and by people of

reduced physical, sensory or

mental capacity, or lacking in

experience in the use of

electrical appliances, provided

that they are supervised or

have been given instructions on

the safe use of the appliance

and of the hazards associated

with it.

• Children must not play with the

appliance.

• Keep children under the age of

eight at a safe distance unless

they are constantly supervised.

• Keep children under the age of

8 away from the appliance

when it is in use.

• Cleaning and maintenance

must not be carried out by

unsupervised children.

• Make sure that the flame-

spreader crowns are correctly

positioned in their housings with

their respective burner caps.

• The cooking process must

PRECAUTIONS - 2591477A872/A

always kept under control. A

short cooking process must be

continuously monitored.

• WARNING: Cooking foods

containing fat and/or oil

without monitoring them can be

dangerous and can cause a

fire.

• Fats and oils can catch fire if

they overheat. Do not leave the

appliance unattended while

preparing foods containing oils

or fats. If fats or oils catch fire,

never put water on them. Place

the lid on the saucepan and

turn off the burner.

• Do not place metal objects,

such as dishes or cutlery, on the

surface of the hob during

cooking as they may overheat.

• WARNING: leaving food

unattended when cooking

using fat or oil can be

dangerous and can cause a

fire. DO NOT attempt to

extinguish a fire with water. Turn

off the appliance and smother

the flames, for example with a

lid or a blanket.

• Do not cook foods in closed

tins or containers or plastic

containers.

• Do not insert pointed metal

objects (cutlery or utensils) into

the slots in the appliance.

• Do not use or store flammable

materials near the appliance or

directly underneath the hob.

• Switch off the appliance

immediately after use.

• Do not pull the cable to unplug

the appliance (if present).

• DO NOT USE AEROSOLS IN

THE VICINITY OF THIS

APPLIANCE WHILST IT IS IN

USE.

• DO NOT MODIFY THIS

APPLIANCE.

• Always wear personal

protective equipment (PPE)

before carrying out any work

on the appliance (installation,

maintenance, positioning or

moving).

• Do not clean the appliance if it

is still hot or in operation.

• Before performing any work on

the appliance, switch off the

power supply.

• Do not try to repair the

appliance yourself or without

the assistance of a qualified

technician.

• If the power cable becomes

damaged, contact technical

support immediately to arrange

for it to be replaced in order to

avoid possible hazards.

• WARNING: A gas cooking

appliance produces heat,

humidity and combustion

products in the room where it is

installed. Make sure there is

good ventilation, especially

when the appliance is in use:

keep the natural ventilation

openings open or install a

mechanical ventilation device.

26 - PRECAUTIONS 91477A872/A

• Intensive and prolonged use of

the appliance may require

additional ventilation, for

example opening a window or

more effective ventilation; for

example by increasing the

power of any mechanical

suction devices.

Risk of damaging the appliance

• Do not sit on the appliance.

• Do not use the appliance as a

support surface.

• Do not obstruct ventilation

openings and heat dispersal

slots.

• Do not use the hob if the

pyrolytic cycle is taking place

inside any oven installed

below.

• Do not use steam jets to clean

the appliance.

• Never leave the appliance

unattended during cooking

operations where fats or oils

could be released, as these

could then heat up and catch

fire. Be very careful.

• Fire hazard: Never leave

objects on the cooking

surfaces.

• DO NOT FOR ANY REASON

USE THE APPLIANCE AS A

SPACE HEATER.

• Cooking vessels or griddle

plates should be placed inside

the perimeter of the hob.

• All pans must have smooth, flat

bottoms.

• If any liquid does boil over or

spill, remove the excess from

the hob.

• Take care not to spill acid

substances such as lemon juice

or vinegar on the hob.

• Do not spill sugar or sweet

mixtures on the hob during

cooking.

• Do not place materials or

substances that could melt or

catch fire (paper, plastic or

aluminium foil) on the

appliance while it is in use.

• Place the cookware directly

onto the grids above the

burners.

• Do not put empty pans or frying

pans on burners that are lit.

• Do not use rough or abrasive

materials or sharp metal

scrapers.

• Do not use cleaning products

containing chlorine, ammonia

or bleach on parts made of

steel or that have metallic

surface finishes (e.g. anodizing,

nickel- or chromium-plating).

• Do not wash removable parts

such as the hob pan support

grids, flame-spreader crowns

and burner caps in the

dishwasher.

• This appliance is not designed

to operate with external timers

or with remote-control systems.

Installation

• THIS APPLIANCE MUST NOT

BE INSTALLED IN BOATS OR

Produkspesifikasjoner

Merke:	Smeg
Kategori:	Komfyr
Modell:	PX364L
Innebygd skjerm:	Nei
Vekt:	12500 g
Bredde:	600 mm
Dybde:	510 mm
Høyde:	40 mm
Antall brennere/kokesoner:	4
Elektronisk tenning:	Ja
Antall gassbrennere:	4
Kontrollposisjon:	Front
Bluetooth:	Nei
Opprinnelsesland:	Italia
Pakkevekt:	16000 g
Rammetype:	Ramme-løs
Innebygd hette:	Nei
AC-inngangsspenning:	220 - 240 V
AC-inngangsfrekvens:	50 / 90 Hz
Grill:	Nei
Produktfarge:	Black, Stainless steel
Pakkedybde:	520 mm
Pakkehøyde:	145 mm
Pakkebredde:	650 mm
Kontrolltype:	Rotasjon
Wok-brenner:	Ja
Wi-Fi kontrollert:	Nei
Plassering av innretning:	Innebygget
Benke type:	Gass
Brenner / kokeområde 1 posisjon:	Venstre
Brenner / kokeområde 1 strømkilde:	Gass
Brenner / kokeområde 1 type:	Ekstra stor
Brenner / kokeområde 1 strøm:	3500 W
Brenner / kokeområde 2 posisjon:	Bak i midten
Brenner / kokeområde 2 strømkilde:	Gass
Brenner / kokeområde 2 type:	Normal
Brenner / kokeområde 2 strøm:	1800 W
Brenner / kokeområde 3 posisjon:	Foran i midten
Brenner / kokeområde 3 strømkilde:	Gass
Brenner / kokeområde 3 type:	Småkoking
Brenner / kokeområde 3 strøm:	1100 W
Tilkoplingsverdi (gass):	9000 W
Lett å rengjøre:	Ja
Type med topp overflate:	Rustfritt stål
Høyde installasjonsrom:	40 mm
Dybde installasjonskammer:	482 mm
Bredde installasjonskammer:	560 mm
Brenner / kokeområde 4 strømkilde:	Gass
Brenner / kokeområde 4 type:	Stor
Brenner / kokeområde 4 strøm:	2600 W
Tilkoplingsverdi (elektrisk):	- W
Form på stekesone 4:	Rund
Brenner / kokeområde 4 posisjon:	Riktig/Høyre
Komfyrbredde:	60 cm
Form på stekesone 1:	Rund
Form på stekesone 2:	Rund
Form på stekesone 3:	Rund
Kokeområde for småkoking:	1100 W
Vanlig kokeområde:	1800 W
Stort kokeområde:	2600 W
Ekstra stort høyhastighets kokeområde:	3500 W
Wok-brennerposisjon:	Venstre
Installasjonskammerdybde (min):	478 mm
Installasjonskammerdybde (maks):	482 mm
