Side 1/96
Updated 9/24 41201.3
AR10410T, AR14410T, AR20410T
PowerSafe Receivers
PowerSafe-Empfänger AR10410T,
AR14410T, AR20410T
Récepteurs PowerSafe AR10410T,
AR14410T, AR20410T
Ricevitori PowerSafe AR10410T,
AR14410T, AR20410T
SPMAR10410T, SPMAR14410T,
SPMAR20410T
EN
2
NOTICE
All instructions, warranties and other collateral documents are subject to
change at the sole discretion of Horizon Hobby, LLC. For up-to-date product
literature, visit horizonhobby.com or towerhobbies.com and click on the support
or resources tab for this product.
Meaning of Special Language
The following terms are used throughout the product literature to indicate
various levels of potential harm when operating this product:
WARNING: Procedures, which if not properly followed, create the probability
of property damage, collateral damage, and serious injury OR create a high
probability of superficial injury.
CAUTION: Procedures, which if not properly followed, create the probability
of physical property damage AND a possibility of serious injury.
NOTICE: Procedures, which if not properly followed, create a possibility of
physical property damage AND a little or no possibility of injury.
WARNING: Read the ENTIRE instruction manual to become familiar
with the features of the product before operating. Failure to operate
the product correctly can result in damage to the product, personal
property and cause serious injury.
This is a sophisticated hobby product. It must be operated with caution
and common sense and requires some basic mechanical ability. Failure to
operate this Product in a safe and responsible manner could result in injury
or damage to the product or other property. This product is not intended for
use by children without direct adult supervision. Do not attempt disassembly,
use with incompatible components or alter product in any way without the
approval of Horizon Hobby, LLC. This manual contains instructions for safety,
operation and maintenance. It is essential to read and follow all the instruc-
tions and warnings in the manual, prior to assembly, setup or use, in order to
operate correctly and avoid damage or serious injury.
Age Recommendation: Not for children under 14 years. This is not a toy.
WARNING AGAINST COUNTERFEIT PRODUCTS
Always purchase from a Horizon Hobby, LLC authorized dealer to ensure
authentic high-quality Spektrum product. Horizon Hobby, LLC disclaims
all support and warranty with regards, but not limited to, compatibility and
performance of counterfeit products or products claiming compatibility with
DSM or Spektrum technology.
NOTICE: This product is only intended for use with unmanned, hobby-grade,
remote-controlled vehicles and aircraft. Horizon Hobby disclaims all liability outside
of the intended purpose and will not provide warranty service related thereto.
WARRANTY REGISTRATION
Visit www.spektrumrc.com/registration today to register your product.
EN
3
AR10410T, AR14410T, AR20410T PowerSafe Receivers
The Spektrum™ AR10410T, AR14410T and AR20410T Receivers are full
range with telemetry, and are compatible with all Spektrum™ DSM2
®
and
DSMX
®
technology transmitters.
Perform the setup for these receivers through a compatible Spektrum Transmitter
with Forward Programming. The Spektrum PC Programmer can be used for
firmware updates.
IMPORTANT: These receivers only use forward programming for the
configuration, do not use the AS3X menu in the main transmitter menu.
WARNING: For electric powered aircraft and if equipped, the
propeller should not be installed on the motor during the setup
procedure. Only install the propeller once the throttle has been confirmed to
operate correctly and the failsafe has been set.
As an additional safety feature, we recommend the throttle cut is enabled.
Throttle cut should be engaged any time the aircraft is powered on and not
in operation. The motor will not rotate when throttle cut is in the ON position.
Specications
Type PowerSafe DSMX Telemetry Receiver
Application Airplane
Channels 20
AS3X+ Available with optional Synapse sensor
Remote Receivers
(2–4) SRXL2
™
Remote Receivers
[3-SPM9747 and 1-SPM4651T Included]
Modulation DSMX
Telemetry Integrated
Bind Method Bind Button, Bind Plug
Failsafe Yes
Power Button On Receiver, Remote Switch
Band 2.4GHz
Input Connector (2) IC3 Input Connectors with Smart Technology
Input Voltage 4V–12.6V
Resolution 2048 (4096 for Stabilization)
AR10410T 10CH
2.56” x 2.44” x 0.71” (65mm x 62mm x 18mm)
1.77 oz (50g)
AR14410T 14CH
2.56” x 2.44” x 0.71” (65mm x 62mm x 18mm)
2.68 oz (76g)
AR20410T 20CH
2.4” x 2.72” x 0.75” (61mm x 69mm x 19mm)
2.82 oz (80g)
