Side 1/104

Spektrum AR637T+ AS3X+ and SAFE

6 CH Receiver

SPM-1032

Created 04/24

804868.1

Age Recommendation: Not for children under 14 years. This is not a toy.

WARNING AGAINST COUNTERFEIT PRODUCTS: Always purchase

from a Horizon Hobby, LLC authorized dealer to ensure authentic

high-quality Spektrum product. Horizon Hobby, LLC disclaims all support and

warranty with regards, but not limited to, compatibility and performance of

counterfeit products or products claiming compatibility with DSM or

Spektrum technology.

NOTICE: This product is only intended for use with unmanned, hobby-grade,

remote-controlled vehicles and aircraft. Horizon Hobby disclaims all liability outside

of the intended purpose and will not provide warranty service related thereto.

WARRANTY REGISTRATION

Visit www.spektrumrc.com/registration today to register your product.

Meaning of Special Language

The following terms are used throughout the product literature to indicate

various levels of potential harm when operating this product:

WARNING: Procedures, which if not properly followed, create the probability

of property damage, collateral damage, and serious injury OR create a high

probability of superﬁcial injury.

CAUTION: Procedures, which if not properly followed, create the probability

of physical property damage AND a possibility of serious injury.

NOTICE: Procedures, which if not properly followed, create a possibility of

physical property damage AND a little or no possibility of injury.

NOTICE

All instructions, warranties and other collateral documents are subject to

change at the sole discretion of Horizon Hobby, LLC. For up-to-date product

literature, visit horizonhobby.com or towerhobbies.com and click on the support

or resources tab for this product.

WARNING: Read the ENTIRE instruction manual to become familiar

with the features of the product before operating. Failure to operate

the product correctly can result in damage to the product, personal property

and cause serious injury.

This is a sophisticated hobby product. It must be operated with caution

and common sense and requires some basic mechanical ability. Failure to

operate this Product in a safe and responsible manner could result in injury

or damage to the product or other property. This product is not intended for

use by children without direct adult supervision. Do not attempt disassembly,

use with incompatible components or alter product in any way without

the approval of Horizon Hobby, LLC. This manual contains instructions for

safety, operation and maintenance. It is essential to read and follow all the

instructions and warnings in the manual, prior to assembly, setup or use, in

order to operate correctly and avoid damage or serious injury.

AR637T+ AS3X+ and SAFE Telemetry Receiver

The Spektrum

™

AR637T+ receiver is full range with telemetry, and is

compatible with all Spektrum

™

DSM2

and DSMX

technology transmitters.

Perform the setup for the AR637T+ receiver through a compatible Spektrum

Transmitter with Forward Programming. The Spektrum PC Programmer can be

used for ﬁrmware updates.

IMPORTANT: The AR637T+ receiver only uses forward programming for

the conﬁguration, do not use the AS3X+ menu in the main transmitter menu.

WARNING: If equipped, the propeller should not be installed on the

motor during the setup procedure. Only install the propeller once the

throttle has been conﬁrmed to operate correctly and the failsafe has been set.

As an additional safety feature, we recommend the throttle cut is enabled.

Throttle cut should be engaged any time the aircraft is powered on and not in

operation. The motor will not rotate when throttle cut is in the ON position.

Speciﬁcations ..............................................................................................4

Smart Throttle ..............................................................................................4

Receiver Power System Requirements ...........................................................4

Installing the AR637T+ Receiver ...................................................................5

Telemetry ....................................................................................................6

Transmitter and Receiver Binding ..................................................................6

Failsafe .......................................................................................................7

Initial Setup .................................................................................................8

Basic AS3X+ Setup ......................................................................................8

Basic Tuning (AS3X+ Normal Gain, No Flight Modes) ......................................9

SAFE Setup ...............................................................................................10

Other Settings (Forward Programming) ........................................................11

SAFE (Self Leveling) Flying Tips ...................................................................12

Channel Limitations ....................................................................................13

Flight Log ..................................................................................................13

Range Testing ............................................................................................14

Hand Launch Assist (HLA) Setup .................................................................15

Glossary ....................................................................................................16

Troubleshooting Guide AS3X+.....................................................................18

Troubleshooting Guide ................................................................................19

Optional Accessories ..................................................................................20

1-Year Limited Warranty .............................................................................20

Warranty and Service Contact Information ...................................................23

FCC Information .........................................................................................23

Compliance Information for the European Union ...........................................24

IC Information ............................................................................................24

Table of Contents

Produkspesifikasjoner

Merke:	Spektrum
Kategori:	radiostyrt leke
Modell:	AR637T
Produkttype:	Mottaker
Vekt:	12 g
Bredde:	23.34 mm
Dybde:	49.8 mm
Høyde:	15.02 mm
Antall per pakke:	1 stykker
Merkekompatibilitet:	Spektrum
Antall kanaler:	6 kanaler
Spenning:	9 V
Produktfarge:	Flerfarget
Modell/Type:	Radio-Controlled (RC) Model Parts
Modulator:	DSM2, DSMX
Antennelengde:	186 mm
