Instruction Manual

Bedienungsanleitung

Manuel d’utilisation

Manuale di Istruzioni

NX8+

8-Channel 2.4GHz

DSMX

Aircraft System

Scan the QR code and select the Support tab on

the product page for the most up-to-date manual

information.

Scannen Sie den QR-Code und wählen Sie auf der

Produktseite die Registerkarte „Support“, um die

aktuellsten Informationen zu Handbücher.

Scannez le code QR et sélectionnez l’onglet Support

sur la page du produit pour obtenir les informations

les plus récentes sur le manuel.

Scannerizzare il codice QR e selezionare la

scheda Supporto dalla pagina del prodotto per le

informazioni manuali più aggiornate.

871112 Updated 5/24

SPMR8210

2 SPEKTRUM NX8+ • TRANSMITTER INSTRUCTION MANUAL

WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating.

Failure to operate the product correctly can result in damage to the product, personal property and cause serious injury.

This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic mechanical

ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage to the product or other

property. This product is not intended for use by children without direct adult supervision. Do not attempt disassembly, use with

incompatible components or augment product in any way without the approval of Horizon Hobby, LLC. This manual contains

instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual,

prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury.

WARNING AGAINST COUNTERFEIT PRODUCTS: Always purchase from a Horizon Hobby, LLC authorized dealer to ensure

authentic high-quality Spektrum product. Horizon Hobby, LLC disclaims all support and warranty with regards, but not limited

to, compatibility and perform ance of counterfeit products or products claiming compatibility with DSM or Spektrum technology.

NOTICE: This product is only intended for use with unmanned, hobby-grade, remote-controlled vehicles and aircraft. Horizon Hobby

disclaims all liability outside of the intended purpose and will not provide warranty service related thereto.

General Notes

• Models are hazardous when operated and maintained

incorrectly.

• Always install and operate a radio control system correctly.

• Always pilot a model so the model is kept under control in all

conditions.

• Please seek help from an experienced pilot or your local hobby

store.

• Contact local or regional modeling organizations for guidance

and instructions about ﬂying in your area.

• When working with a model, always power on the transmitter

ﬁrst and power off the transmitter last.

• After a model is bound to a transmitter and the model is set

up in the transmitter, always bind the model to the transmitter

again to establish failsafe settings.

Pilot Safety

• Always make sure all batteries are fully charged before ﬂying.

• Time ﬂights so you can ﬂy safely within the time allotted by your

battery.

• Perform a range check of the transmitter and the model before

ﬂying the model.

• Make sure all control surfaces correctly respond to transmitter

controls before ﬂying.

• Do NOT ﬂy a model near spectators, parking areas or any other

area that could result in injury to people or damage to property.

• Do NOT ﬂy during adverse weather conditions. Poor visibility,

wind, moisture and ice can cause pilot disorientation and/or

loss of control of a model.

• When a ﬂying model does not respond correctly to controls,

land the model and correct the cause of the problem.

NOTICE

All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-

to-date product literature, visit horizonhobby.com or towerhobbies.com and click on the support or resources tab for this product.

Meaning of Special Language

The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product:

WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage and serious injury

OR create a high probability of superﬁcial injury.

CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility of serious injury.

NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND little or no possibility of injury.

Age Recommendation: Not for Children under 14 years. This is not a toy.

Warranty Registration

Visit www.spektrumrc.com today to register your product.

NOTICE: While DSMX technology allows you to use more than 40 transmitters simultaneously, when using DSM2 receivers, DSMX

receivers in DSM2 mode or transmitters in DSM2 mode, do not use more than 40 transmitters simultaneously.

BEFORE USING YOUR TRANSMITTER

Before going any further, visit the Spektrum Community website at www.spektrumrc.com to register your transmitter and

download the latest Spektrum AirWare

™

ﬁrmware updates. A registration reminder screen occasionally appears until you

The transmitter comes with a thin, clear plastic ﬁlm applied to some front panels for protection during shipping. Humidity and use may

cause this ﬁlm to come off. Carefully remove this ﬁlm as desired.

3SPEKTRUM NX8+ • TRANSMITTER INSTRUCTION MANUAL

BOX CONTENTS SPECIFICATIONS

For helpful videos on programming the NX8+ and other Spektrum

AirWare

™

equipped transmitters, go to www.spektrumrc.com.

*EU versions of the NX8+ are not compatible with DSM2

receivers.

Table of Contents ........................................................................ 3

Basic Operation .......................................................................... 5

Transmitter Functions ................................................................ 6

Powering the NX8+ On and Off .................................................. 7

Charging the Lithium Ion Battery Pack ...................................... 8

Navigation ................................................................................... 9

Main Screen ................................................................................ 9

Keyboard Style .......................................................................... 10

Auto Switch Select ................................................................... 10

OTF (On The FLy) Trim Functions.............................................. 10

Pre-installed BNF model les................................................... 11

USB and Internal Memory ........................................................ 11

External Memory card .............................................................. 11

Memory card Functions ........................................................... 12

Update Spektrum AirWare

™

Software ........................................ 12

Model Type Programming Guide .............................................. 13

System Setup ............................................................................ 14

Model Select ............................................................................. 14

Model Type ............................................................................... 14

Model Name ............................................................................. 15

Flight Mode Examples ............................................................... 15

Flight Mode Setup ..................................................................... 16

Spoken Flight Mode .................................................................. 16

Channel Assign ......................................................................... 17

Channel Input Conﬁguration ....................................................... 17

Receiver (Rx) Port Assignments .................................................. 17

Trim Setup ................................................................................ 17

Model Utilities ........................................................................... 18

Create New Model .................................................................... 18

Delete Model ............................................................................ 18

Copy Model .............................................................................. 19

Model Reset ............................................................................. 19

Sort Model List ......................................................................... 19

Validate All Models .................................................................... 19

Delete All Models ...................................................................... 19

Warnings .................................................................................. 19

Telemetry ................................................................................. 20

Telemetry Data.......................................................................... 20

Telemetry Auto-Conﬁguration ..................................................... 20

Settings .................................................................................... 21

File Settings .............................................................................. 21

Preﬂight Setup .......................................................................... 22

Frame Rate, RF Mode, and Failsafe ........................................... 22

Bind .......................................................................................... 23

Serial Port Setup ....................................................................... 23

Trainer ...................................................................................... 24

Wired Trainer ........................................................................... 24

Wireless Trainer ........................................................................ 24

Instructor Transmitter Conﬁguration ............................................ 25

Binding Wireless Trainer ............................................................ 25

Head Tracking FPV Setup ........................................................... 25

Center Tone .............................................................................. 26

Sound Utilities ........................................................................... 26

Palette Utilities .......................................................................... 26

System Settings ........................................................................ 26

User Name ............................................................................... 26

Mode* ...................................................................................... 26

Battery Alarm ............................................................................ 27

Selecting a Language ................................................................ 27

Inactive Alarm ........................................................................... 27

Set Date/Time ........................................................................... 27

Factory Reset............................................................................ 27

Calibrate ................................................................................... 27

Visual Preferences .................................................................... 28

Roller Menu .............................................................................. 28

Brightness ................................................................................ 28

Keyboard .................................................................................. 28

Trim Style ................................................................................. 28

Channel Monitor ....................................................................... 28

Default Palette .......................................................................... 28

Power-Off Conf ......................................................................... 29

Flight Mode Table ...................................................................... 29

Audio Preferences ..................................................................... 29

System Sounds ......................................................................... 29

Vibrator Intensity Adjustment...................................................... 29

Volume Controls ........................................................................ 29

Power Sounds .......................................................................... 29

WiFi Utilities .............................................................................. 29

USB Settings ............................................................................. 29

Transfer SD Card....................................................................... 30

Category .................................................................................. 30

Model Import/Export .................................................................. 30

Memory Location ...................................................................... 30

File/Folder Management ............................................................ 31

TABLE OF CONTENTS

Type DSM2/DSMX 20 CH Telemetry Transmitter

Application Airplanes, Helicopters, Sailplanes, Multirotors

Channels 20

Wireless Trainer DSM2*/DSMX Compatible

Switches

2 - 2 Position, 6 - 3 Position, 1 Momentary

Button, 2 - Trimmers

Modulation DSM2*/DSMX

Telemetry Integrated

Bind Method Bind Button or From Within Menu

Frame Rate

22ms Default,

11ms Selectable (Digital Servos Required)

Resolution 2048

Battery 3.7V 2000 mAh LiIon

Band 2.4GHz

Feedback Tone, Vibration, Voice

• NX8+ Transmitter (SPMR8210)

• Manual

• USB A to USB Micro Cable

• Decal Set

• Neck Strap

Produkspesifikasjoner

Merke:	Spektrum
Kategori:	radiostyrt leke
Modell:	NX8
Produkttype:	Fjernkontroll
Innebygd skjerm:	Ja
Batterikapasitet:	2000 mAh
Wi-Fi:	Ja
Tilkoblingsteknologi:	Ledning & Trådløs
Antall kanaler:	8 kanaler
Skjermoppløsning:	320 x 240 piksler
Telemetrimottaker:	Ja
Produktfarge:	Sort
Skjermdiagonal:	3.2 "
Kontrolltype:	Knapper
Modulator:	DSM2, DSMX
Korrekt bruk:	Airplane, Helicopter, Multirotor, Aircraft
Frekvensbånd og driftskanaler:	2.5 GHz
Fargevisning:	Ja
Antall minneoppføringer:	250
