SPM4648 DSMX

ReMote ReceiveR uSeR guiDe

SPM4648 DSMX SatelliteneMPfängeR

BeDienungSanleitung

guiDe De l’utiliSateuR -

SPM4648 DSMX Satellite

guiDa Dell‘utente

SPM4648 DSMX Ricevente Satellite

NOTICE

All instructions, warranties and other collateral documents are subject to

change at the sole discretion of Horizon Hobby, LLC. For up-to-date product

literature, visit horizonhobby.com and click on the support tab for this product.

Meaning of Special Language

The following terms are used throughout the product literature to indicate

various levels of potential harm when operating this product:

NOTICE: Procedures, which if not properly followed, create a possibility of

physical property damage AND a little or no possibility of injury.

CAUTION: Procedures, which if not properly followed, create the probability

of physical property damage AND a possibility of serious injury.

WARNING: Procedures, which if not properly followed, create the probability

of property damage, collateral damage, and serious injury OR create a high

probability of superﬁcial injury.

WARNING: Read the ENTIRE instruction manual to become familiar

with the features of the product before operating. Failure to operate

the product correctly can result in damage to the product, personal

property and cause serious injury.

This is a sophisticated hobby product. It must be operated with caution and

common sense and requires some basic mechanical ability. Failure to oper-

ate this Product in a safe and responsible manner could result in injury or

damage to the product or other property. This product is not intended for use

by children without direct adult supervision. Do not attempt disassembly, use

with incompatible components or augment product in any way without the

approval of Horizon Hobby, LLC. This manual contains instructions for safety,

operation and maintenance. It is essential to read and follow all the instruc-

tions and warnings in the manual, prior to assembly, setup or use, in order to

operate correctly and avoid damage or serious injury.

Age Recommendation: Not for children under 14 years. This is not a toy.

WARNING AGAINST COUNTERFEIT PRODUCTS

Always purchase from a Horizon Hobby, LLC authorized dealer to ensure

authentic high-quality Spektrum product. Horizon Hobby, LLC disclaims

all support and warranty with regards, but not limited to, compatibility and

performance of counterfeit products or products claiming compatibility with

DSM or Spektrum technology.

NOTICE: This product is only intended for use with unmanned, hobby-grade,

remote-controlled vehicles and aircraft. Horizon Hobby disclaims all liability outside

of the intended purpose and will not provide warranty service related thereto.

WARRANTY REGISTRATION

Visit www.spektrumrc.com/registration today to register your product.

SPM4648 Instruction Manual

The SPM4648 remote receiver features DSM

technology and is compatible

with all Spektrum

™

aircraft radios that support DSM2

and DSMX

technology.

Speciﬁcations

Type: DSM Remote Receiver

Modulation: DSM2, DSMX

Band: 2.4GHz

Dimension (WxLxH): 0.8 x 1.02 x 0.28 in (20 x 26 x 7mm)

Weight: 0.11 oz (3.2 g)

Input Voltag: 3.3V only

Compatibility: All DSM2 and DSMX Aircraft Transmitters and Module Systems.

11ms and 18 channel support (limited to transmitter capabilities)

Diversity Antennas

The SPM4648 incorporates two diversity antennas. Each antenna includes

acoaxial portion (which can be thought of as an extension) and an exposed

31mm tip antenna. The last 31mm is the active portion of the antenna. Do not

allow the antennas to kink and never cut the antennas.

Installation

Mount the antennas 90° off from each other so one is vertically polarized and

the other horizontally polarized. Chose a location so that at least one antenna

will always be in the RF visual line of sight of the transmitter (e.g. not blocked

by carbon ﬁber, aluminum, etc.) in all attitudes.

Autobind

1. With the transmitter off, power on the receiver.

2. The receiver will attempt to connect to the last transmitter it was bound to.

3. If no transmitter is found it will enter Bind mode, as indicated by a ﬂashing

orange LED.

4. Turn on your transmitter and allow the remote receiver to autobind.

5. When the receiver binds the orange LED turns solid.

IMPORTANT: Once the receiver is bound to your transmitter, always

power your transmitter on ﬁrst so the receiver will not enter bind mode. If

the model enters bind mode unintentionally, shut off power to the model,

ensure the transmitter is powered on with the correct model selected, and

then power the model on again. The receiver will not lose its previous bind

information if it enters bind mode and does not bind.

Failsafe

The SPM4648 does not have failsafe capabilities, failsafe should be detected at

the ﬂight controller. Always ensure your ﬂight controller is properly conﬁgured to

power off the motors in the event of an RF loss.

Produkspesifikasjoner

Merke:	Spektrum
Kategori:	radiostyrt leke
Modell:	SPM4648
Produkttype:	Mottaker
Vekt:	3.6 g
Bredde:	21 mm
Dybde:	26 mm
Høyde:	8 mm
Merkekompatibilitet:	Spektrum
Antall kanaler:	18 kanaler
Spenning:	3.3 V
Produktfarge:	Sort
Modell/Type:	Radio-Controlled (RC) Model Parts
RF senderfrekvens:	2400 MHz
