The Evolution of Intelligent Design®
Mar 2018
The Evolution of Intelligent Design®
Model # Description
2171-6 Full Size Server
2172-6/30 Mini Round Server
2172-6/37 Round Server
2173-6/12 Mini Square Server
2174-6 Square Server
Before You Begin
To ensure safe operation, read the following instructions in their
entirety.
Warning is used to indicate the presence of a hazard that can cause
severe personal injury, death, or substantial property damage if the
warning is ignored.
Caution is used to indicate the presence of a hazard that will or can
cause minor personal injury or property damage if the caution is
ignored.
NOTICE
Notice is used to note information that is important but not
hazard-related.
To reduce risk of injury or damage to the equipment:
• Equipment should only be used in a flat, level position.
• Do not obstruct or cover the equipment in any way when in use.
• Do not store or place any materials below the equipment when in
use.
• Always turn off and unplug electric heating elements when not in
use.
• Always allow equipment to cool before handling.
• Do not operate without water in the water pan.
• Do not operate unattended.
• Closely supervise equipment operating in public areas and/or around
children.
• Do not operate if equipment has been damaged or is malfunctioning
in any way.
2 11
This page intentionally left blank.
Installation
Inspect all parts of the Reflection Induction Buffet Server prior to
installation and use. If the server is damaged, do not use. Contact a
supplier for a replacement.
To install the server, place the unit on an induction range or hidden
induction surface that is in a flat, level position. The support stabilizer
Function
Spring USA’s Reflection Induction Buffet Servers are induction ready
vessels with a water-based system intended for serving prepared food.
Food must be at or above serving temperature before being placed in
the servers. Adapter frames enable use of electric heating elements
with the full size, round or square server. All servers can also be used
with an optional stand and canned fuel (not included).
Dimensions
For dimensions of each Reflection Induction Buffet Server refer to the
corresponding specification sheet found on the Spring USA website.
Figure 1. Support Stabilizer Bar and Bumper
3
bar with bumper located
in the back of the vessel
is used to keep the
vessel in place. See
Figure 1 for reference.
Be sure the bumper is in
contact with the top
surface of the range or
induction surface so that
the bumper creates a
seal.
Support
Stabilizer
Bar
Bumper
For use with induction:
Maintenance Cont’d.
If axles begin to squeak when opening the cover, apply cooking spray or
vegetable oil directly on the axle to lubricate the components. Wipe off
an excess oil. Never use WD-40 to lubricate the axle.
10
Troubleshooting
When using the Reflection Induction Buffet Servers with Spring USA
induction, ensure the server is centered on the induction range. If the
red indicator light on the control panel is blinking, the range is not
detecting the server. Adjust the server on the range until the light on the
control panel goes solid red.
For further induction range troubleshooting refer to the corresponding
induction range manual.
Warranty
Spring USA’s Reflection Induction Buffet Servers carry a ten-year warranty
against manufacturing defects on welds and metal castings. Warranty
does not cover abuse or normal wear and tear.
Service & Repair
To repair or replace Reflection Induction Buffet Server axles, refer to the
‘How To’ sheet found on the Spring USA website.
For questions or further help, contact Spring USA. For service forms, visit
the Spring USA website.
NOTICE: Reflection Induction Buffet Servers only
maintain temperature – they are not intended for
cooking food.
