ST121HDBTE

HDMI® over Cat 5e/6 Extender - 70m

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment

o and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation. Changes or modications not

expressly approved by StarTech.com could void the user’s authority to operate the equipment.

Industry Canada Statement

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [A] est conforme à la norme NMB-003 du Canada. CAN ICES-3

(A)/NMB-3(A).

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to

the following two conditions:

(1) This device may not cause interference, and (2) This device must accept any interference,

including interference that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio

exempts de licence. L’exploitation est autorisée aux deux conditions suivantes:

(1) L’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter

tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le

fonctionnement.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names

and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected names

and/or symbols contained in this manual and related documents are the property of their respective

holders.

Instruction Manual

Table of Contents

Product Diagram ....................................................................................1

Front View – Transmitter/Receiver Unit ............................................................................................. 1

Rear View – Transmitter/Receiver Unit .............................................................................................. 1

LED Indicator .............................................................................................................................................. 1

Introduction ............................................................................................ 2

Packaging Contents ................................................................................................................................. 2

System Requirements ..............................................................................................................................2

Installation ..............................................................................................3

Preparing Your Site ................................................................................................................................... 3

Hardware Installation ..............................................................................................................................3

Video resolution performance ............................................................. 5

Specications .......................................................................................... 5

Technical Support ..................................................................................6

Warranty Information ............................................................................ 6

Produkspesifikasjoner

Merke:	StarTech.com
Kategori:	AV ekstender
Modell:	Cat 5e/6, 70 m
Vekt:	428 g
Bredde:	67 mm
Dybde:	80 mm
Høyde:	25 mm
LED-indikatorer:	Status
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	4096 x 2160 piksler
Pakkevekt:	1100 g
Sertifisering:	CE, FCC, HDBT, TAA
Maksimal oppdateringshastighet:	60 Hz
Materiale:	Aluminium
Utgangsstrøm:	1.5 A
HDMI inn:	1
Antall HDMI-utganger:	1
Driftsspenning:	12 V
AC-inngangsspenning:	110 - 240 V
Lydstøtte:	Ja
Kabellengde:	0.1 m
Produktfarge:	Sort
Pakkedybde:	156 mm
Pakkehøyde:	65 mm
Pakkebredde:	235 mm
Støttede grafikkoppløsninger:	1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA), 4096 x 2160
Kabler inkludert:	LAN (RJ-45)
Strømforbruk (vanlig bruk):	3 W
Støttede videofunksjoner:	720p, 1080p
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 60 °C
Bærekraftsertifikater:	RoHS
Modell/Type:	AV-sender og -mottaker
RJ-45-inngangsporter:	1
DC-inngangskontakt:	Ja
Lydsystem:	Flerkanal
Inkluderte kraftpluggtyper:	AU, EU, NA, UK
Relativ luftfuktighet under drift (H-H):	0 - 80
Lyd-utgang kanaler:	7.1 kanaler
Monteringsbeslag inkludert:	Ja
Gjennomsnittstid mellom feil (MTBF):	52000 timer
AC-adapter bunt:	Ja
Strømpluggtype:	Type M
Masterkassens (ytterkassens) lengde:	411 mm
Produkter per masterkasse (ytterkasse):	12 stykker
Masterkassens (ytterkassens) bredde:	325 mm
Masterkassens (ytterkassens) høyde:	257 mm
Innput-strøm:	0.5 A
Maksimal overføring avstand:	70 m
Kabeltyper som støttes:	Cat5e, Cat6
RJ-45-utgangsporter:	1
Seriekobling:	Nei
Jord-ledning:	Ja
