PEX4S950
4 Port PCI Express RS232 Serial Adapter
Card with 16950 UART
*actual product may vary from photos
Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and
Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.
Instruction Manual
i
Table of Contents
Introduction ............................................................................................1
Features ........................................................................................................................................................1
System Requirements .............................................................................................................................. 1
Package Contents .....................................................................................................................................1
Installation ..............................................................................................2
Hardware Installation .............................................................................................................................. 2
Software Installation ................................................................................................................................2
Specications ..........................................................................................4
Technical Support ..................................................................................5
Warranty Information ............................................................................5
Instruction Manual
1
Introduction
Thank you for purchasing a StarTech.com 4 port PCI Express 16C950 Serial Card.
Following simple installation, you will now be able to add four RS-232 ports for
connections to card readers, printers, scanners and more, while requiring only a single
PCI Express slot.
Features
• Fully compatible with 16C550 type devices
• High performance 16C950 UART channel
• Maximum data transfer rate of 115.2Kbps
System Requirements
• A PC with an available PCI Express slot
• Windows 2000 / 2003 32-bit or 64-bit / WindowXP 32-bit or 64-bit / Vista / Vista
64-bit, or Linux
Package Contents
• PCI Express Serial Card
• Four Port Breakout Cable
• Instruction Manual
• Driver CD
Instruction Manual
3
4. Select Include this location in the search, then click on Browse to specify the exact
le location (E:\IO\OXFORD\NT4 etc.) and click Next to continue. Please note that
if the exact le is not selected, an installation conict could occur. Please pay
particular attention to the folder name, when browsing to the destination le.
5. Click Next to continue and click Finish to complete the installation.
6. Right-click on the My Computer icon, and select Manage. Choose Device Manager
(in the left pane), and double-click on Ports (in the right pane).
7. Right-click on one of the newly added ports, and choose Properties. Click on the
Data rate tab, then click on Detect Crystal Frequency. Click OK to save this setting.
8. You will be required to complete steps 1-7 multiple times in order to install all
necessary components. Please do so. Once complete, a message balloon will appear
in the taskbar (normally the bottom right corner of the screen), indicating that
installation is complete:
9. To conrm that all of the necessary components have successfully been installed
browse to the Device Manager. To perform this step, right-click on My Computer
and select Manage. In the left pane of the Computer Management window that
appears, click on Device Manager. In the right pane, you should see the following:
10. Installation is now complete. You can now connect serial devices as desired, to the
ports provided by the card.
OX16PCI954 PCI UARTS
and bridge
PCI Communications Port
(x4)
