INSTALLATION INSTRUCTIONS

1. Center and place wire guard er device or product to be protectedov

and mark all 4 hole locations with pencil or marker.

2. Drill all 4 holes using 1/4” diameter drill 1-1/2” deep.

3. Insert anchors into drilled holes.

4. Place wire guard in position, insert screws and tighten.

7 in.

(178mm)

7 in.

(178mm)

8.78 in.

(223mm)

10.83 in.

(275mm)

9.36 in.

(238mm)

10.84 in.

(275mm)

9.36 in.

(238mm)

8.78 in.

(223mm)

7.49 in.

(190mm)

SECTION B-B

SECTION AA-

Three year warranty or a one year limited warranty (from

date of purchase) on most products. See website for details.

Electronic warranty form at www.sti-usa.com/wc14.

Toll Free: 800-888-4784 • E-mail: info@sti-usa.com

Web: www.sti-usa.com

USA - Headquarters

2306 Airport Road • Waterford, Michigan 48327-1209

Phone: 248-673-9898 • Fax: 248-673-1246

Tel: 44 (0) 1527 520 999 Fax: 44 (0) 1527 501 999

E-mail: info@sti-emea.com • Web: www.sti-emea.com

European Ofﬁce

Taylor House • • 34 Sherwood Road Bromsgrove

Worcestershire • B60 3DR • England

INSTALLATION OF STI-9729 WIRE GUARD DAMAGE STOPPER

All speciﬁcations and information shown were current as of publication and are subject to change without notice.

9729 MAY2017

External Dimensions

Internal Dimensions

7 in.

(178mm)

Produkspesifikasjoner

Merke:	STI
Kategori:	Detektor
Modell:	-9729
Bredde:	178 mm
Dybde:	178 mm
Høyde:	178 mm
Materiale:	Stål
Kompatible produkter:	External Lighting & CCTV
Produktfarge:	Hvit
Enkel installering:	Ja
