Side 1/92
HTA 150.0, 160.0
WARNING
Read Instruction Manual thoroughly before use and
follow all safety precautions – improper use can cause
serious or fatal injury.
ADVERTENCIA
Antes de usar la máquina lea y siga todas las precauciones
de seguridad dadas en el manual de instrucciones – el uso
incorrecto puede causar lesiones graves o mortales.
2 - 43 Instruction Manual
43 - 91 Manual de instrucciones
Contents
1 Introduction................................................. 2
2 Guide to Using this Manual.........................2
3 Main Parts...................................................3
4 Safety Symbols on the Products.................5
5 General Power Tool Safety Warnings.........6
6 IMPORTANT SAFETY INSTRUCTIONS....7
7 Kickback and Other Reactive Forces........15
8 Battery Safety........................................... 16
9 Maintenance, Repair and Storage............ 18
10 Before Starting Work.................................18
11 Charging the Battery................................. 19
12 LED Diagnostics and Acoustic Signals..... 20
13 STIHL AR Backpack Battery.....................22
14 Assembling the Pole Pruner..................... 23
15 Inserting and Removing the Battery..........28
16 Switching the Pole Pruner On and Off...... 28
17 Checking the Pole Pruner......................... 29
18 During Operation.......................................30
19 After Finishing Work..................................32
20 Transporting the Pole Pruner and Battery 32
21 Storing the Pole Pruner and Battery......... 33
22 Cleaning....................................................34
23 Inspection and Maintenance..................... 35
24 Troubleshooting Guide..............................38
25 Specifications............................................39
26 Combinations of Guide Bars and Saw
Chains.......................................................41
27 Approved Harness Combinations............. 41
28 Replacement Parts and Equipment.......... 42
29 Disposal.................................................... 42
30 Limited Warranty.......................................42
31 Trademarks...............................................42
32 Addresses................................................. 43
1 Introduction
Thank you for your purchase. The information
contained in this manual will help you receive
maximum performance and satisfaction from
your STIHL pole pruner and, if followed, reduce
the risk of injury from its use.
SAVE THIS MANUAL!
Because a pole pruner is a high-
speed wood-cutting tool with an
extended reach, special safety
precautions must be observed to
reduce the risk of personal injury.
Read this instruction manual thor‐
oughly before use and periodically
thereafter. Follow all safety pre‐
cautions. Careless or improper
use of the pole pruner can cause
serious or fatal injury.
Observe all applicable federal, state and local
safety regulations, standards and ordinances.
Do not lend or rent your pole pruner without this
instruction manual. Allow only persons who have
the proper training and fully understand the infor‐
mation in this manual to operate the pole pruner.
For further information, or if you do not under‐
stand any of the instructions in this manual,
please go to www.stihlusa.com or contact your
authorized STIHL servicing dealer.
2 Guide to Using this Manual
2.1 Signal Words
This manual contains safety information that
requires your special attention. Such information
is introduced with the following symbols and sig‐
nal words:
DANGER
■ Indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING
■ Indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
NOTICE
■ Indicates a risk of property damage, including
damage to the machine or its individual com‐
ponents.
2.2 Symbols in Text
The following symbol is included to assist you
with the use of the manual:
Refers to a designated chapter or sub-
chapter in this instruction manual.
English
2 0458-038-8601-A
© ANDREAS STIHL AG & Co. KG 2023
0458-038-8601-A. VA0.G23.
Printed on chlorine-free paper
Paper is recyclable.
Original Instruction Manual
0000010709_003_GB
3 Main Parts
3.1 STIHL HTA 150.0 Pole Pruner
and Battery
#
18
17
16
15
28
27
26
#
1
19
20
22
21
23
24
25
5
6
7
2
12
11
8
9
13
14
3
4
10
0000099158_001
1 Front Handle
Handle for the operator's front hand.
2 Drive Tube
Pole pruner shaft.
3 Loop Handle (only forest variant)
Handle for the operator's front hand.
4 Carrying Ring
For connecting a harness to the pole pruner.
5 Chain Sprocket
Drives the saw chain.
6 Side Chain Tensioner
Permits precise adjustment of saw chain ten‐
sion.
7 Oil Filler Cap
For closing the oil tank.
8 Guide Bar
Supports and guides the saw chain.
9 Saw Chain
Toothed cutting tool consisting of cutters, tie
straps and drive links.
10 Hook
Helps hold the pole pruner steady against the
branch during cutting.
11 Extended Hook (only forest variant)
Helps hold the pole pruner steady against the
branch during cutting and helps to remove the
branches.
12 Chain Sprocket Cover
Covers the chain sprocket.
13 Nut
Tightens the chain sprocket cover.
14 Limbing Sight
Helps the operator position the bar and chain
for the cut.
15 Chain Scabbard
Covers the guide bar and saw chain to
reduce the risk of injury from inadvertent con‐
tact during transportation and storage.
16 Battery
Supplies electrical power to the motor.
17 Battery LEDs
Indicate the battery's state of charge and dis‐
play error messages regarding potential mal‐
functions in the battery or power tool.
18 Push Button
Activates the battery's LEDs.
19 Locking Levers
Secure the battery in the battery compart‐
ment.
20 Battery Compartment
Holds the battery.
21
Mounting Recess Cover
1
Covers the mounting area for a Smart Con‐
nector 2 A.
22 Control Handle
Handle for the operator's rear hand.
23 Trigger Switch Lockout
Must be depressed to allow activation of the
trigger switch.
24 Retaining Latch
For switching the pole pruner on.
25 LED
Indicate the unit's power level.
1
Remove the mounting recess cover only to install a Smart Connector 2 A. Store it safely for later rein‐
stallation. Always use the power tool with the mounting recess cover in place or with the Smart Con‐
nector 2 A mounted.
3 Main Parts English
0458-038-8601-A 3
