INTEGRATED REFRIGERATION
USE & CARE GUIDE
GUÍA DE USO Y MANTENIMIENTO
GUIDE D’UTILISATION ET D’ENTRETIEN
GUIDA ALL’USO E ALLA MANUTENZIONE
BEDIENUNGS-UND PFLEGEANLEITUNG
2
|
English subzero.com
|
3
INTEGRATED REFRIGERATION
Customer Care
The model and serial number are listed on the product
rating plate. Refer to page 3 for rating plate location. For
warranty purposes, you will also need the date of installation
and name of your authorized Sub-Zero dealer. Record this
information below for future reference.
SERVICE INFORMATION
Model Number
Serial Number
Date of Installation
Certied Service Name
Certied Service Number
Authorized Dealer
Dealer Number
Important Note
To ensure this product is installed and operated as safely
and efciently as possible, take note of the following types
of highlighted information throughout this guide:
IMPORTANT NOTE highlights information that is especially
important.
CAUTION indicates a situation where minor injury or product
damage may occur if instructions are not followed.
WARNING states a hazard that may cause serious injury or
death if precautions are not followed.
Contents
3 Integrated Features
3 Interactive Controls
4 Storage
6 Operation
7 Care Recommendations
7 Troubleshooting
8 Sub-Zero Warranty
subzero.com
|
3
Integrated Features
FEATURE
PG
1
Product Rating Plate
2
2
Interactive Control Panel
3
3
Freshness Cards
4
4
Door Shelves
4
5
Dairy Compartment
4
6
Glass Shelves
4
7
Refrigerator Drawers
4
8
Ice Container
5
9
Storage Drawers
5
10
Air Purication System
6
11
Automatic Ice Maker
6
12
Water Dispenser (dispenser models)
6
13
Condenser (behind grille)
7
INTEGRATED FEATURES
Column all refrigerator.
6
3
12
7
10
Tall combination.
2
1
5
4
Drawer all refrigerator.
13
6
3
1
10
2
9
5
4
13
8
11
7
13
9
1
12
10
2
Interactive Control Panel
For initial start up, touch and hold on the control panel
for 2 seconds.
Temperature can be adjusted in one-degree increments on
the home screen. Combination units have separate tem-
perature controls for refrigerator and freezer. Temperatures
are preset at 3°C and -18°C. To change temperature, touch
the temperature being adjusted, then press ‘+’ or ‘-’ until
desired temperature is displayed. Refer to the illustration
below.
Once temperature has been adjusted, additional features
can be activated or deactivated from the options screen.
Touch
to view the options screen. Refer to the illustration
below.
OPTIONS SCREEN
PG
Touch to activate or deactivate ice maker system
and max ice feature.
6
Touch to activate or deactivate door/drawer alarm.
3
Touch to activate or deactivate water dispenser.
6
Touch to activate or deactivate air purication
system.
6
Touch to view settings screen.
3
SETTINGS SCREEN
Touch to view model information.
Touch to select temperature unit, Fahrenheit or Celsius.
Touch to adjust control panel brightness and contrast.
Touch to adjust door/drawer alarm volume and pitch.
Touch to adjust door/drawer alarm duration.
Touch to enter Sabbath mode.
Touch to view troubleshooting and service information.
Touch to set clock.
Touch to select smart home options.
Touch to select language options.
Touch to adjust soft on lighting.
INTERACTIVE CONTROLS
Home screen.
Options screen.
