© 2016 Suncast Corporation, Batavia, IL 0361402
PARTS
To learn about other Suncast products, please call
1-800-846-2345 or 1-630-879-2050.
Product Feedback? Go To: Suncastcommercial.com/feedback
OR email us at: feedback@suncastcommercial.com
9/16"
5/16"
or
A
TOOLS NEEDED
B
P
E
F
H
G
ITEM NUMBER: PDPTSD2436 / PDPTSD2448 / PDPTSD3060 STANDARD DUTY
PDPTHD2436 / PDPTHD2448 / PDPTHD3060 HEAVY DUTY
FRONT
FRONT
BACK
BACK
2
BEFORE YOU BEGIN
• Read instructions thoroughly prior to assembly.
This kit contains parts that can be damaged if assembled incorrectly or in the wrong sequence.
• Please follow instructions.
Suncast is not responsible for replacing parts lost or damaged due to incorrect assembly.
• Check for all parts before you begin assembly.
Using the provided parts check list, verify that you have all the parts required to construct your cabinets.
• Assistance is required during parts of the assembly.
CAUTION
• This product is not a toy and is not intended for use by children.
• Exercise caution when moving fully loaded product.
• Do not sit or stand on top.
• This contains parts that can be damaged if assembled incorrectly or in the wrong sequence. Repair or replace
broken parts immediately.
• Standard Duty Max load 1000 lbs. • Heavy Duty Max Load 2000 lbs.
CAUTION
• We recommend cleaning your product with soap and water. Rinse and dry well before using.
HARDWARE
K
M
I
L
P
x16
x16
x1
x5
N
x1
O
x1
J
x16
Q
x2
3
2
K
I
J
G
G
H
H
E
BACK
FRONT
x4
x4
x4
Lower frame (E) into plastic bed (B).
ASSEMBLY
Attach each caster (G/H) to the frame (E). Attach each using four
bolts (K) four lock washers (I) and four washers (J). Do not tighten
completely. Repeat other casters. Now tighten all (K) bolts.
Note: Lockout pin needs to face inward on (G) casters.
1
B
E
Thread lanyard (Q) onto Hooks connected to (P).
Thread lanyard (Q) onto key ring. Repeat other side.
Note: Ring should already be attached to caster.
3
Q
Q
P
4
Q
Ring
