Side 1/7

www.sven.ﬁ

OPERATION

MANUAL

SVEN 247

2.0 USB Multimedia

Speaker System

Congratulations on your purchase of the Sven speaker system!

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eﬀorts to make this Manual more exact, some discrepancies may occur. The

information in this Manual is given on “as is” terms. The author and the publisher do not bear any

liability to a person or an organization for loss or damage which has arisen from the information

contained in this Manual.

CONTENTS

1. BUYER RECOMMENDATIONS ..................................................

.............

2. PACKAGE CONTENTS............................................... .... ... .......

............

3. SAFETY PRECAUTIONS ..................................................

...................

4. TECHNICAL DESCRIPTION ....................................................

................

5. PREPARATION AND OPERATION ..........................................

......................

6. TROUBLESHOOTING.................................

...............................................

7. TECHNICAL SPECIFICATIONS ....................................................

...........

1. BUYER RECOMMENDATIONS

• Unpack the device carefully. Make sure there are no accessories left in the box. Check up the

device for damage; if the product was damaged during transportation, address the ﬁrm which

carried out the delivery; if the product functions incorrectly, address the dealer at once.

• Check up the package contents and availability of the warranty card. Make sure the warranty card

has a shop stamp, a legible signature or the seller’s stamp and purchase date, and the goods

number corresponds to that in the warranty card. Remember: in case of warranty card loss or

discrepancy of numbers you forfeit the right for warranty repairs.

• Do not switch on the speaker system immediately after you bring it into a room from environment

with negative temperature! After unpacking, the speaker system should be kept in conditions of

room temperature for at least 4 hours.

• Before installing and using the speaker system, read this Manual carefully and keep it for future

reference.

Technical support is on www.sven. . ﬁ

ENG

Operation Manual

sVEN 247

2. PACKAGE CONTENTS

• Speaker system — 1 pc

• Operation manual — 1 pc

• Warranty card — 1 pc

3. SAFETY PRECAUTIONS

• Do not open the MSS and do not perform repairs by yourself. Service and repairs should be

performed only by quali ed specialists at authorized service centers. The list of authorized service ﬁ

centers is on www.sven.ﬁ.

• Do not allow the circuit of wires (including the grounded ones) between the speakers, on the

power ampliﬁ ﬁer or the ground, for it causes damage to the power ampli er output stage.

• Make sure that foreign objects do not get inside the holes of the MSS.

• Protect the MSS from high humidity, water and dust.

• Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not expose

it to direct sunlight.

• Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.

• If the MSS does not operate, unplug it and address your dealer.

4. TECHNICAL DESCRIPTION

SVEN 247 2.0 USB Multimedia Speaker System (MSS) is designed to play music and sound games,

movies, etc. The MSS has a built-in audio and signal cables enabling to connect it to a PC, laptop,

CD/MP3 player and other audio devices. The MSS is powered via a PC or laptop USB port, or via

a 5V DC power supply with the built-in USB power cable. The speaker with an audio input and

a control panel is named the active one.

MSS special features

• Speaker system is compatible with PCs, DVD/Media-players, mobile devices

and other sound sources

• U.S.S. (Ultra Sound System) – built-in bridge ampliﬁer

• Powered via a USB port

• Volume control

• Headphone and microphone jacks

• Plastic speaker cabinets

ENG

2.0 USB Multimedia

Speaker System

Produkspesifikasjoner

Merke:	Sven
Kategori:	Høyttaler
Modell:	247
Vekt:	480 g
Bredde:	85 mm
Dybde:	81 mm
Høyde:	115 mm
LED-indikatorer:	Kraft indikator
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Strømkildetype:	DC, USB
Volumkontroll:	Rotasjon
Hodetelefonutganger:	1
Anbefalt bruk:	PC
Impedans:	- Ω
USB-tilkobling:	Ja
Høyttalerplassering:	Bord bokhylle
Basshøyttaler:	Nei
Forsterker:	Nei
Diskanthøyttaler:	Nei
Produktfarge:	Sort
Hodetelefontilkobling:	3,5 mm
Mikrofon, linje-inn-støpsel:	Ja
Kroppsmateriale:	Plast
Av/på-bryter:	Ja
Lyd-utgang kanaler:	2.0 kanaler
RMS-rangert strøm/utgangseffekt:	4 W
DC inngående spenning:	5 V
Utjevner/frekvenskorrigerer:	Nei
Antall drivere:	2
Frekvensrekkevidde:	90 - 20000 Hz
Magnetisk beskyttet:	Ja
Driverdiameter:	76 mm
