www.sven.ﬁ

USER’S MANUAL

Stereo Headphones

with Microphone

ap-545MV

ENG

User l’s Manua

Congratulations on your purchase of the SVEN headphones!

APPLICATION

Sven АР-545MV stereo headphones with a microphone are designed for

operation with PC sound cards and other compatible systems. They can be

also used in VoIP telephony, video conferencing, multimedia applications,

interactive games, for speech recognition and learning foreign languages.

SAFETY PRECAUTIONS

• Don’t e the stereo headphones while driving.us

• Don’t use the stereo headphones at high volume for a long time (more

than 15 minutes), as this may cause hearing impairment.

SPECIAL FEATURES

• 2*3.5 mm (3 pin) connector for PC

• Unilateral connection of the cable

• Volume control on the left headphone

• Adjustable headband

• Heavy-duty non-tangling cable with fabric braid

• Extra cable attachment support

CONNECTION AND OPERATION

• Connect the headphones connector to the audio output jack of your audio

source (PC, laptop, MP3 player), as shown in Fig. 1.

• Insert the microphone connector into the microphone input jack of your

audio source.

• Ad st ju the hea ph ned o s v ume l as ol evel desired wi th the vo me lu control wheel

on the left headphone.

ap-545MV

Sound card

Volume control

on left earcup

Microphone

Headphones

connector

Microphone

connector

Phone out

Mic in

Fig. 1. Connection diagram

TECHNICAL SPECIFICATIONS

Parameter, measurement unit

Sensitivity, dB

Frequency range, Hz

Membrane, mm

Connector type

Cable length, m

Weight, g

Value

headphones: 106 ± 2

microphone: -48 ± 3

headphones: 20 – 20,000

microphone: 50 – 16,000

Ø 40

Ø 3.5 mm (3 pin) stereo mini-jack

2.2

160

Notes:

• Technical speci cations given in this table are supplemental information ﬁ

and cannot give occasion to claims.

• Technical speci cations are subject to change without notice due to the ﬁ

improvement of SVEN production.

Technical support is on www.sven. .ﬁ

ENG

Stereo Headphones

with Microphone

Produkspesifikasjoner

Merke:	Sven
Kategori:	hodetelefon
Modell:	AP-545MV
Produkttype:	Hodesett
Vekt:	160 g
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Garantikort:	Ja
Volumkontroll:	Rotasjon
Impedans:	32 Ω
3,5 mm-kontakt:	Nei
Mikrofontype:	Bom/Innebygd mikrofon
2x 3,5 mm-kontakter:	Ja
Mikrofonfrekvens:	50 - 16000 Hz
Kabellengde:	2.2 m
Produktfarge:	Black, Red
Bæremåte:	Hodebånd
Hodetelefonsfrekvens:	20 - 20000 Hz
Hodetelefonssensitivitet/hodetelefonsfølsomhet:	106 dB
Mikrofonsensitivitet/mikrofonfølsomhet:	-48 dB
Justerbart hodebånd:	Ja
Øresammenkobling:	Circumaural
Avtagbar kabel:	Nei
Membrandiameter:	40 mm
