Side 1/12
www.sven.fi
USER MANUAL
Portable Speaker System
with Bluetooth
PS-315
ENG
2
Portable Speaker System
with Bluetooth
Congratulations on your purchase of the Sven speaker system!
COPYRIGHT
© SVEN PTE. LTD. Version 2.0 (21.06.2023).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted eorts to make this Manual more exact, some discrepancies may occur.
Theinformation in this Manual is given on «as is» terms. The author and the publisher do notbear
any liability to a person or an organization for loss or damage which has arisen from the infor-
mation contained in this Manual.
CONTENTS
ENG ............................................................................................................................................... 2
RUS ................................................................................................................................................ 6
BUYER RECOMMENDATIONS
• Unpack the device carefully. Make sure there are no accessories left in the box. Check up thede-
vice for damage; if the product was damaged during transportation, address the rm which car-
ried out the delivery; if the product functions incorrectly, address the dealer at once.
• Shipping and transportation equipment is permitted only in the original container.
• Does not require special conditions for realization.
• Dispose of in accordance with regulations for the disposal of household and computer equipment.
• The date of manufacture of the product is indicated on the box.
APPLICATION
SVEN PS-315 portable multimedia speaker system with Bluetooth is designed foroperation with
PC, notebooks and other mobile devices by means of data transfer viaBluetooth protocol. It can
be also used in internet telephony, during video conferences, inmultimedia applications, in inter-
active games. There is a built player withUSB ash andwith micro SD memory card.
PACKAGE CONTENTS
• Speaker system ― 1 pc
• USB to USB Type-C power cable ― 1 pc
• Mini-jack to mini-jack signal cable ― 1 pc
• User Manual ― 1 pc
• Warranty card ― 1 pc
SPECIAL FEATURES
• Wireless signal transmission via Bluetooth
• Dynamic switchable RGB backlight
• Waterproof (IPx6)
• Wireless connection of two speakers to one source (TWS)
• USB-ash and microSD card playback support
• AUX input for connecting to an audio source
ENG
3
PS-315
User Manual
Speaker system description
a Turn on / o the speaker (long press); Play/
Pause (short press in Player and Bluetooth
modes); Disconnect from signal source (double
tap in Bluetooth modes).
b Volume increase button (short pressing); Next
track (long pressing in Player and Bluetooth mode).
c Microphone.
d Turn on/o TWS mode (long press); Switching
the operating modes of the speakers (short press).
e LED indicator of operating modes.
f Volume decrease button (short pressing); Pre-
vious track (long pressing in Player andBluetooth
mode).
g Button for switching the speaker backlight
modes (short press); turn on / o the backlight
(long press).
h Connector cover.
i USB-ash card slot.
j Micro SD card slot.
k 3.5 mm mini-jack for audio signal connecting
(phone, MP3 player, etc.).
l USB Type-C jack for charger connecting Speaker.
system to laptop/PC USB port.
CONNECTION AND OPERATION
Attention! The built-in battery must be charged
completely prior to the application.
Speaker system battery charging
• Connect speaker system to a USB port of PC
or USB charger using USB Type-C to USB cable
(included). During battery charging the indicator
lights red. Indicator goes out when the battery
is charged.
• The battery is used in the speaker system as an in-
tegral part of the device, therefore do nottry to extract or replace it, because this can result in the war-
ranty cancellation or the device damage.
OPERATION MODES
Bluetooth mode
• Wireless data transfer via the Bluetooth protocol enables to connect speaker system to compat-
ible devises. Maximum radius of action of data transfer is 10 m. Such obstacles as walls orother
electronic devices can interfere with the signal transfer.
• Turn on the speaker in Bluetooth mode.
• It is necessary to select the search mode of devices with Bluetooth on a signal source (tele-
phone, notebook, smartphone, etc.). «SVEN PS-315» message will be displayed on the screen
which is to be connected to*.
• When connection is successful, there will be a short beep and the speaker mode indicator will
light blue continuously.**.
Fig. 1.
a
b
c
d
e
f
g
j i
h
l k
