Side 1/16
Swift Group
Dunswell Road
Cottingham
East Yorkshire HU16 4JX
Tel 01482 847332
Fax 01482 841042
email enquiry@swiftgroup.co.uk
For more information visit
www. .co.ukswiftgroup
Issued July 2012
1099732
Challenger Sport -
Eccles Sport
Technical Handbook
1
Contents
Specifications 2 .............................................................................
Wiring Diagrams 4 .........................................................................
Bulb Chart 11 .................................................................................
Bulb Replacement 12 ......................................................................
3
2
Specification
Challenger Sport 442 514 524 544 554 564 584 585 586 636
Eccles Sport 442 514 524 544 554 564 584 585 586 636
Berths
2 4 4 4 4 4 4 6 6 6
Axles
1 1 1 1 1 1 1 1 1 2
Internal Length (bed box height)
4.40m/14'5" 5.23m/17'2" 5.29m/17'4" 5.60m/18'4" 5.60m/18'4" 5.60m/18'4" 5.83m/19'2" 5.60m/18'4" 5.83m/19'2" 6.27m/20'7"
Overall Width
2.25m/7'5" 2.25m/7'5" 2.25m/7'5" 2.25m/7'5" 2.25m/7'5" 2.25m/7'5" 2.25m/7'5" 2.25m/7'5" 2.25m/7'5" 2.25m/7'5"
Overall Height (inc. TV Aerial)*
2.64m/8'8" 2.65m/8'8" 2.65m/8'8" 2.65m/8'8" 2.65m/8'8" 2.65m/8'8" 2.65m/8'8" 2.65m/8'8" 2.65m/8'8" 2.62m/8'7"
Maximum Internal Headroom
1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5"
Overall Length
6.06m/19'11" 6.88m/22'7" 6.94m/22'9" 7.25m/23'9" 7.25m/23'9" 7.25m/23'9" 7.48m/24'6" 7.25m/23'9" 7.48m/24'6" 7.93m/26'0"
Awning A/A dimension†
8.79m/28'10" 9.62m/31'7" 9.68m/31'9" 9.99m/32'9" 9.99m/32'9" 9.99m/32'9" 10.22m/33'6" 9.99m/32'9" 10.22m/33'6" 10.66m/35'0"
Mass in Running Order (inc. tolerance)
1114kg/21.9cwt 1230kg/24.2cwt 1265kg/24.9cwt 1282kg/25.2cwt 1277kg/25.1cwt 1290kg/25.4cwt 1308kg/25.7cwt 1312kg/25.8cwt 1381kg/27.2cwt 1470kg/28.9cwt
Maximum Technical Permissible Laden
Mass (Lower limit)
1235kg/24.3cwt 1380kg/27.2cwt 1415kg/27.9cwt 1435kg/28.2cwt 1430kg/28.1cwt 1443kg/28.4cwt 1464kg/28.8cwt 1485kg/29.2cwt 1557kg/30.6cwt 1650kg/32.5cwt
Maximum Technical Permissible Laden
Mass (Upper limit)
1350kg/26.6cwt 1500kg/29.5cwt 1500kg/29.5cwt 1500kg/29.5cwt 1500kg/29.5cwt 1500kg/29.5cwt 1500kg/29.5cwt 1500kg/29.5cwt 1600kg/31.5cwt 1800kg/35.4cwt
Total user Payload
121kg/2.4cwt 150kg/3.0cwt 150kg/3.0cwt 153kg/3.0cwt 153kg/3.0cwt 153kg/3.0cwt 156kg/3.1cwt 173kg/3.4cwt 176kg/3.5cwt 180kg/3.5cwt
Personal Effects
121kg/2.4cwt 150kg/3.0cwt 150kg/3.0cwt 153kg/3.0cwt 153kg/3.0cwt 153kg/3.0cwt 156kg/3.1cwt 173kg/3.4cwt 176kg/3.5cwt 180kg/3.5cwt
Options
0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt
Tyre Size
185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 195/70 R15C 104R 185/70 R14 88T
Tyre pressure at Lower limit MTPLM
3.4 bar / 49 psi 4.0 bar / 58 psi 4.1 bar / 59 psi 4.1 bar / 59 psi 4.1 bar / 59 psi 4.2 bar / 61 psi 4.2 bar / 61 psi 4.3 bar / 62 psi 4.3 bar / 62 psi 2.0 bar / 29 psi
Tyre pressure at Upper limit MTPLM
3.8 bar / 55 psi 4.4 bar / 64 psi 4.4 bar / 64 psi 4.4 bar / 64 psi 4.4 bar / 64 psi 4.4 bar / 64 psi 4.4 bar / 64 psi 4.4 bar / 64 psi 4.4 bar / 64 psi 2.2 bar / 32 psi
Static Load on Coupling Head
100kg 100kg 100kg 100kg 100kg 100kg 100kg 100kg 100kg 100kg
Thermal Insulation Grade
THREE THREE THREE THREE THREE THREE THREE THREE THREE THREE
Bed Sizes
Front Double
202cm x 180cm
6'8" x 5'11"
202cm x 153cm/
6'8" x 5'0"
202cm x 180cm/
6'8" x 5'11"
202cm x 159cm/
6'8" x 5'3"
202cm x 159cm/
6'8" x 5'3"
202cm x 159cm/
6'8" x 5'3"
202cm x 159cm/
6'8" x 5'3"
202cm x 180cm/
6'8" x 5'11"
202cm x 180cm/
6'8" x 5'11"
202cm x 180cm/
6'8" x 5'11"
or Front Nearside Single
190cm x 72cm/6'3" x 2'4" 153cm x 72cm/5'0" x 2'4" 180cm x 72cm/5'11" x 2'4" 160cm x 72cm/5'3" x 2'4" 160cm x 72cm/5'3" x 2'4" 160cm x 72cm/5'3" x 2'4" 160cm x 72cm/5'3" x 2'4" 180cm x 72cm/5'11" x 2'4" 190cm x 72cm/6'3" x 2'4" 180cm x 72cm/5'11" x 2'4"
and Front Offside Single
180cm x 72cm/5'11" x 2'4" 160cm x 72cm/5'3" x 2'4" 190cm x 72cm/6'3" x 2'4" 160cm x 72cm/5'3" x 2'4" 160cm x 72cm/5'3" x 2'4" 160cm x 72cm/5'3" x 2'4" 160cm x 72cm/5'3" x 2'4" 180cm x 72cm/5'11" x 2'4" 180cm x 72cm/5'11" x 2'4" 190cm x 72cm/6'3" x 2'4"
Rear Double
198cm x 133cm/6'6" x 4'4" 191cm x 133cm/6'3" x 4'4" 191cm x 133cm/6'3" x 4'4" 185cm x 133cm/6'1" x 4'4"
Rear Bunk
Side Single (offside)
180cm x 62cm/5'11" x 2'0" 192cm x 71cm/6'4" x 2'4" 180cm x 82cm/5'11" x 2'8"
Side Single (nearside)
183cm x 75cm/6'0" x 2'6" 180cm x 62cm/5'11" x 2'0" 180cm x 67cm/5'11" x 2'2"
Side Bunk (offside)
176cm x 59cm/5'9" x 1'11" 176cm x 59cm/5'9" x 1'11"
Side Bunk (nearside)
176cm x 59cm/5'9" x 1'11" 176cm x 59cm/5'9" x 1'11"
Rear Fixed Lower Bunk
Rear Fixed Mid Bunk
Rear Fixed Upper Bunk
Side Fixed Lower Bunk
183cm x 57cm/6'0" x 1'10" 183cm x 57cm/6'0" x 1'10" 181cm x 57cm/5'11" x 1'10"
Side Fixed Mid Bunk
Side Fixed Upper Bunk
183cm x 57cm/6'0" x 1'10" 183cm x 57cm/6'0" x 1'10" 181cm x 57cm/5'11" x 1'10"
Weights: The method of calculating the Mass in
Running Order (MRO) and user payload figures has
changed in order to bring it in line with European
Vehicle Directives.
Allowances for essential equipment (e.g. gas
cylinders) previously allowed for in the user payload
are now contained within the MRO. A provision for a
leisure battery which used to be within the essential
equipment payload has now been included within the
personal effects payload allowance.
Although the method of calculation has changed, the
overall effect is that the amount of payload available
to the customer has remained the same, it is just
calculated in a different manner
Bed Sizes : Please note that the front double bed
sizes quoted are for seating configurations without
chest of drawers. The front double bed width for a
layout with a chest of drawers fitted will be reduced
by 0.4m(1'4") from that stated.
Awning sizes: Due to varying awning designs and
sizes the awning sizes given are approximate only.
Specific awning sizes must be confirmed by your
dealer or awning manufacturer prior to purchase.
* The dimensions given are approximate due to slight
variations in suspension ride heights, loading
conditions and tyre pressures.
Customers should verify the actual dimensions of
their touring caravan before committing to anything
that could be impacted by theses dimensions
Please note: Any dealer fit options will reduce the
overall payload available to the user of the caravan.
If you require additional payload it is possible to
upgrade the MTPLM to the upper limit. Pleas contact
your Swift caravan dealer for more information.
