Side 1/1
P/N:
DATE:
DRAWN:
CHECKED:
APPROVED:
098-020632-45 Rev.1
09-01-23
TED
JRM 09-01-23
JHB 09-01-23
SINGLE LEVER,
SINGLE HOLE AND
ESCUTCHEON
BP-2704, BP-2704-BN
BP-2712, BP-2712-BN
Installation and
Maintenance
Instructions
Limited One Year Warranty
(Commercial Applications)
T&S warrants to the original purchaser (other than for purposes of resale) that such product is
free from defects in material and workmanship for a period of one (1) year from the date of purchase.
During this one-year warranty period, if the product is found to be defective, T&S shall, at its options,
repair and/or replace it. To obtain warranty service, products must be returned to...
T&S Brass and Bronze Works, Inc.
Attn: Warranty Repair Department
2 Saddleback Cove
Travelers Rest, SC 29690
Shipping, freight, insurance, and other transportation charges of the product to T&S and the return
of repaired or replaced product to the purchaser are the responsibility of the purchaser. Repair and/
or replacement shall be made within a reasonable time after receipt by T&S of the returned product.
This warranty does not cover Items which have received secondary nishing or have been altered
or modied after purchase, or for defects caused by physical abuse to or misuse of the product, or
shipment of the products.
Any express warranty not provided herein, and any remedy for Breach of Contract which might
arise, is hereby excluded and disclaimed. Any implied warranties of merchantability or tness for a
particular purpose are limited to one year in duration. Under no circumstances shall T&S be liable for
loss of use or any special consequential costs, expenses or damages.
Some states do not allow limitations on how long and implied warranty lasts or the exclusion or
limitation of incidental or consequential damages, so the above limitations or exclusions may not apply
to you. Specic rights under this warranty and other rights vary from state to state.
Attention California Residents:
WARNING This product can expose you to chemicals including Lead, Chromium (hexavalent
compounds) and Phthalates (DEHP) which are known to the State of California to cause cancer
and birth defects or other reproductive harm.
For more information go to
www.P65Warnings.ca.gov.
Installation Without Escutcheon:
1. Shut off water supply and drain lines. Clean sink surface
thoroughly.
2. Remove no.8 and no.9 from shank.
3. Place both no.10’s through hole.
4. Place no.8 and no.9 on the shank and tighten fully.
5. Connect supply lines and check for leaks.
1
4
6
11
12
2 3
5
7
8
9
10
Single Lever Assembly
1 Single Lever Handle
Polished Chrome 020515-40
Brushed Nickel 020515-60
2 Index, Temperature 014173-45
3 Set Screw, Cone Point 021098-45
4 Trim Ring
Polished Chrome 020516-40
Brushed Nickel 020516-60
5 Ceramic Cartridge 020518-45
6 0.5 GPM HIdden Spray Device, M21.5 x 1 B-0199-M21-V05
7 M21.5 x 1 Red Cache Key 020674-45
8 Washer, Stainless Steel 020656-20
9 Lock Nut 020655-20
10 19” Flexible Supply Hose (2) 019969-45
11 6” Deck Gasket 020797-45
12 Kit, Side Mounting Post with Lock Nut 014162-45
Installation With Escutcheon:
1. Shut off water supply and drain lines. Clean sink surface
thoroughly.
2. Remove both no.12’s and place both no.10’s through hole.
3. Ensure no.11 deck gasket is seated between faucet and deck.
4. Replace no.12’s and tighten fully.
5. Connect supply lines and check for leaks.
11
12
10
9
8
10
