Side 1/16

Instruction manual

Betriebsanleitung

Betjeningsvejledning

Mode d’emploi

Gebruiksaanwijzing

Manual de instrucciones

Spectrum

XSW-8

active subwoofer

Active Subwoofer Spectrum

Carefully unpack the Tangent Active subwoofer and check for any damages. If possible, keep the carton

box in case future transportation is needed.

You should immediately contact your dealer if the active subwoofer is damaged.

Installation

There are two ways to install Your new subwoofer ; below we will describe how:

1. From ampliﬁer with pre out to subwoofer:

Connect the power cord from the ampliﬁer pre out to Line In on Your active subwoofer. Hereby the

sound signal runs from ampliﬁer subwoofer pre out to Your active subwoofer. (See Fig 1 on page 12)

2. From ampliﬁer speaker out to subwoofer:

Connect the speaker cords from the ampliﬁer speaker terminations to INPUT In on Your active subwoo-

fer. Make sure that the right channel on the ampliﬁer is connected to the right channel on the subwoofer.

Repeat the same check for the left channels. Next, connect the front speakers from OUTPUT on Your

active subwoofer. Make sure that the right channel on the subwoofer is connected to the right speaker.

Repeat the same check for the left channel.(See Fig 2 on page 13)

Functions (See Fig. 3 on page 11)

Volume

The sound level of the active subwoofer can be adjusted. Use the volume control carefully, remember

that programme material may contain very high energy.

Phase

The phase is adjustable to 0 or 180 degrees. Try both settings for preferred sound.

Crossover

It is possible to reduce the bass - adjustment from 40-150 Hz. Try different settings for preferred sound.

Placement

Your active subwoofer is designed to re-produce music information in the frequency range below 150Hz.

The human ear is not able to localize sound for these low frequencies, this is why the placement of the

subwoofer is not critical.However you can use the nature of the acoustic laws in the following ways:

a. To get the most ampliﬁcation of the room itself, place the active subwoofer close to a corner at a

distance of about 10 cm from the walls. If you get to much bass please move the subwoofer out from the

corner. (See drawing A on page 8)

b. By experimenting with the placement of the subwoofer you can optimize the sound quality. One good

rule is to place the subwoofer near the satellite speakers. (See drawing B on page 8)

c. Never cover the built-in ampliﬁer.

Warning!

To reduce the risk of electric shock, do not open or remove cover or back. Do not expose this appliance to

rain or moisture. In case of malfunction consult qualiﬁed service personel

Produkspesifikasjoner

Merke:	Tangent
Kategori:	Subwoofer
Modell:	Spectrum XSW-8
Strømkildetype:	AC
Pakkevekt:	12000 g
AC-inngangsspenning:	220 V
AC-inngangsfrekvens:	50 - 60 Hz
Produktfarge:	Sort
Subwoofer-vekt:	10000 g
Subwoofer RMS-styrke:	90 W
Subwoofer-driverdiameter (imperisk):	8 "
Subwoofer-type:	Passiv
Frekvensomgang subwoofer:	31 - 250 Hz
Bredde subwoofer:	270 mm
Dybde subwoofer:	275 mm
Høyde subwoofer:	280 mm
Overgangsfrekvens subwoofer:	40 - 150 Hz
Pakningsstørrelse (BxDxH):	335 x 365 x 400 mm
