Side 1/2

With a lineup of award-winning televisions, audio products, mobile devices, and appliances, TCL delivers

meaningful experiences through thoughtful design and the latest technology, helping you enjoy more of

the things you love.

Series:

QM7K

4K QD-Mini LED Smart TV

Next Gen Technology That is Clearly

a Step Above

QM7K SERIES

TCL Halo Control System

An advanced Technology Suite that includes

the New Super High Energy LED Microchip,

Condensed Micro Lens, Micro-OD Reduced

Optical Distance, High Contrast HVA Panel,

Enhanced QLED, Zero Delay Transient

Response, Bi-direction 23-bit Backlight

Controller, and Dynamic Light Algorithm for

Stunning “Halo-Free” Images.

HDR 3000 Nits

The HDR 3000 nits peak brightness

provides a great picture in virtually any

room lighting environment. Together with

the new Halo control system, the result is

high contrast images with dazzling specular

highlights for amazing HDR impact.

CrystGlow HVA Panel

The CrystGlow HVA Panel blocks reﬂections

ensuring that image details always

remaincrisp and visible.

QD-Mini LED

This premium level of Mini LED TV,

now with the New TCL Halo Control

System, ensures a high-quality

viewing experience.

Up to LD2500 Precise

Dimming Series

Up to LD2500 Precise Dimming

Series provides pure black levels with

up to 2500precisely controlled local

dimming zones.

Audio by Bang & Olufsen

Sound experiences elevated by

Bang & Olufsen

PRODUCT HIGHLIGHTS

SIZES AVAILABLE:

65" 55" 85" 98" 115" 75"

*Available on 55"-98". Onkyo 4.2.2 Speaker System on 115"

Series

55QM7K 65QM7K

75QM7K 85QM7K

98QM7K 115QM7K

Screen Class

55" 65"

75" 85"

98" 115"

Viewable Display Size

54.6" 64.5"

74.5" 84.6"

97.5" 114.5"

UPC

55": 846042041935 65": 846042041942

75": 846042041959 85": 846042041966

98": 846042045308 115": 846042040839

CONNECTED TV

Smart Platform Google TV

Hands-Free Voice Control Far-Field Mic Array

Wi-Fi Wi-Fi 5 (802.11ac)

DISPLAY

Panel Type CrystGlow HVA Panel

Panel Refresh 144Hz

Panel Resolution 3840 x 2160

Display Colors 1.07 Billion

High Dynamic Range Format Dolby Vision IQ / HDR10+ / HDR10 / HLG

FEATURES

Auto Game Mode (ALLM) Yes

Control Buttons One Button

Multilingual On–Screen–Display English, Spanish, French

Closed Caption Yes

Parental Control (V–Chip) USA

Accessible Menu System (CVAA) Yes

AUDIO

Audio Power (Watts)

55"-98": 60W from 4 speakers

115": 100W from 8 speakers

Audio Passthrough

Dolby Atmos / Dolby Digital+ /

Dolby Digital / PCM

Dolby Processing Dolby Atmos / Dolby Digital+ / Dolby Digital

SIGNAL FORMAT CAPABILITY

Tuner Type ATSC / NTSC / Clear QAM

CONNECTIONS—INPUTS/OUTPUTS

RF Input NTSC / ATSC

Ethernet 1

USB One USB 3.0 + One USB 2.0

HDMI 4 HDMI (One with eARC)

SPDIF Digital Audio Optical 1

ENERGY INFORMATION

Energy Guide

55": TBD 65": TBD

75": TBD 85": TBD

98": TBD 115": $151

Power Consumption

55": 260 kWh 65": 270 kWh

75": 370 kWh 85": 385 kWh

98": 500 kWh 115": TBD

Standby Power <0.5W

ACCESSORIES (INCLUDED)

Warranty Info / Quick Start

Guide (QSG)

Yes (English)

Remote Control Type Backlit Voice Remote

Remote Control Battery Two “AAA”

WARRANTY

One Year Limited Warranty (English)

* All Product Speciﬁcations Are Subject to Change Without Notice.

PRODUCT & PACKAGE

INFORMATION

55 65 85 98 115" " 75" " " "

Product Size (WxHxD) with Stand

48.30" x 29.90" x 10.60" 56.80" x 34.20" x 14.50" 65.60" x 39.20" x 14.50" 74.40" x 44.30" x 14.90" 85.80" x 50.60" x 16.50" 101.02" x 59.37" x 17.52"

Product Size (WxHxD) w/o Stand

48.30" x 28.00" x 2.20" 56.80" x 32.70" x 2.20" 65.60" x 37.80" x 2.20" 74.40" x 42.70" x 2.30" 85.80" x 49.10" x 2.40" 101.02" x 57.91" x 2.24"

Product Weight with Stand (lbs)

32.00 43.80 58.60 121.9080.00 220.02

Product Weight w/o Stand (lbs)

29.30 39.60 54.20 75.20 216.71119.70

Package Size (WxHxD)

55.20" x 34.50" x 6.10" 63.30" x 39.40" x 6.50" 73.20" x 44.30" x 7.00" 81.1" x 49.6" x 8.2" 93.9" x 56.3" x 8.5" 114.0" x 42.4" x 14.0"

Total Package Weight (lbs)

42.90 62.30 113.3 192.2 505.580.00

VESA MOUNTING

SPECIFICATIONS
