* Depending on model
EN
1800129364 - 08/13 - GTO
www.tefal.com
1*
10*
19c
19a
19f
19d
19e
18
19
19b
2
3
4
5
6
7
8
9
11*
12
13
14
15
16
17
1/4
fig.1 fig.2
fig.3
fig.7
fig.6fig.5
fig.13
fig.10
fig.14
fig.11
fig.15
fig.9
fig. 4
fig.8
fig.12
1/4
fig.19
fig.18fig.17fig.16
fig.20
Locking system for retaining the iron on the
base - Lock-system
(according to model)
Your steam station is fitted with a retaining hoop to hold the
iron onto the base with a locked position for easy transport
and storage :- fig.1
• Locking - fig.2.
• Unlocking - fig.3.
To transport your steam station using the handle of the iron:
- Place the iron in position on the housing plate on the
steam station and fold the hoop over the iron until it locks
into position (you will hear a “click”) .- fig.2
- Hold the iron by the handle to transport your steam
station .- fig.1
Preparation
What water may be used?
• Tap water:
Your appliance has been designed to function using untreated tap water. If your
water is very hard, we recommend you use a mix of 50% untreated tap water
and 50% distilled water available in most shops.
• Types of water not to use:
Heat concentrates the elements contained in water during evaporation. The
types of water listed below may contain organic waste, mineral or chemical
elements that can cause spitting, brown staining or premature wear of the
appliance: water from clothes dryers, scented or softened water, water from
refrigerators, batteries, air conditioners, rain water, boiled, filtered or bottled
water. These types of water should not be used in your TEFAL iron. Also only use
distilled water as advised above.
• Always remember:
Never use rainwater or water containing additives (like starch, fragrance or
water from domestic appliances). Such additives can affect the steam
properties and at high temperature, form deposits in the steam station
chamber which are likely to stain your washing.
Filling the water tank
• Place the steam station on a stable, horizontal and heat-resistant surface.
• Ensure that your steam station is unplugged and that the soleplate and the
iron rest have cooled down.
• Open the water tank filler cover .- fig.4
• Pour in untreated tap water up to the max mark (1,7 l) .- fig.4
• Close the water tank filler cover.
Switch on the steam station
• Completely unwind the power cord and the steam
cord from its storage space.
• Lower the retaining hoop (depending on model) to
unlock the safety catch . - fig.3
• Plug your steam station into a mains socket.
• Press on the on / off switch. The green light (located
on the control panel) flashes and the boiler heats up -
fig.5.
When the green “steam ready” light stops flashing
(after 2 minutes approximately), the appliance is
ready.
• When starting, and regularly while it is being used, your steam station's electric
pump injects water into the boiler. It makes a noise but this is quite normal. You
may also hear a clicking noise which is the steam valve opening. Again this is
normal.
Operating the control panel
• Green light flashes: the boiler heats up .- fig.5
• Green light on: the steam is ready.
•
"Water tank empty" red warning light is flashing
: the water tank is empty . - fig.10
• The orange “anti-calc” indicator flashes : you need to rinse the scale- fig.13
collector.
Use
Steam ironing
• Place the iron's temperature control dial according to
the type of fabric to be ironed (see table below).
• The thermostat light comes on.
Important: whenever you start using your iron and
whenever you reduce the temperature during use, the
iron is ready for use when its indicator light goes out
and when the green light located on the control panel
comes on and remains on. During use, whenyou
increase the temperature of the iron, you can start
ironing immediately, but make sure you only increase
your steam flow once the iron’s light has gone out.
• Adjust the steam output control dial (located on the
control panel).
•
When the iron is in use, the iron thermostat light on
the iron comes on and goes off according to the
soleplate temperature requirement without this
having any effect on the use of the appliance.
• To obtain steam, press on the steam control button
under the iron handle and keep it pressed . The- fig.6
steam will stop when you release the button.
• Always spray starch onto the reverse side of the fabric
to be ironed.
Setting the temperature
1. Comfort handle*
2. Steam control button
3. Iron temperature adjustment dial
4. Iron thermostat light / Settings for
the iron temperature button
5. Easycord system
6. Iron rest
7. Illuminated on / off switch
8. Power cord storage space
9. Power cord
10. Power Zone button*
11. Lock-System hoop*
12. Water tank filler cover
13. Water tank 1,7 l
14. Steam station boiler (in the base unit)
15. Iron-base steam cord
16. Slide storage place for the steam cord
17. Scale collector cover
18. Scale collector
19. Control panel
a - “Anti-calc” indicator
b - “Water tank empty” light
c - OK button
d - “Steam ready” light
e - ECO Zone
f - Steam output control dial
Description
Ironing Boards:
Due to the powerful
steam output, a mesh
type ironing board
must be used to allow
any excess steam to
escape sideways and
to avoid steam
venting sideways.
Do not place the iron
on a metal support.
When taking a break
from ironing, always
place the iron on the
iron rest plate of the
unit. It is equipped
with non-slip pads
and has been
designed to withstand
high temperatures.
Always use a vented/
mesh ironing board
and be careful of hot
steam when ironing
close to the edges of
the board
SETTING THE TEMPERATURE AND STEAM OUTPUT ACCORDING TO TYPE OF FABRIC TO BE IRONED:
• Iron temperature setting - fig.9:
- Start with the fabrics to be ironed at a low temperature
(•) and finish with those which need higher
temperatures (••• or Max).
- Mixed fibre fabric: set the ironing temperature to the
setting for the most delicate fabric.
- Woollen garments: press repeatedly on the steam
control button - fig.6 to obtain short bursts of steam,
without placing the iron on the garment itself.
• Steam output setting:
- Thick fabric: increase the steam setting.
- At a low temperature : set the steam output control dial
to the low position.
If you put your thermostat in the “min” position, the iron does not become hot.
MODE ECO:
Your steam station iron has an ECO mode function which uses less power whilst still
guaranteeing a sufficient steam flow for you to iron your garments properly. In
order to use this function, once the thermostat of your iron has been correctly set
(see table above), position the steam flow setting on the ECO segment - fig.12. The ECO
mode can be used on all types of fabrics, however, for very thick or very creased fabrics, we
recommend that you use the maximum steam flow for best results.
Dry ironing
• Do not press the steam control button under the iron handle.
Vertical steam ironing
• Set the iron temperature control slide and the steam output
control dial (located on the control panel) to the MAX
position.
• Hang the garment on a coat hanger and hold the fabric
slightly taut with one hand.
As steam is very hot: never attempt to remove creases
from a garment while it is being worn, always hang
garments on a coat hanger.
• Holding the iron in a vertical position - fig.6, tilted slightly forwards, press repeatedly on
the steam control button (underneath the iron handle) moving the iron from top to
bottom - fig.8.
Refilling the water tank
• When the “tank empty” red warning light flashes it means that you have- ,fig.10
no more steam. The water tank is empty.
• Unplug the steam station. Open the tank filler flap - fig.4.
Fill the water tank up without exceeding the MAX level - fig.4.
• Close the water tank filler cover.
• Plug in the steam station. Press the “OK” button - fig.11, on the control panel to
continue ironing. When the green indicator remains lit, the steam is ready.
Power Zone Function (according to model)
• Your appliance includes the Power Zone function: concentrated steam shot at the
tip of the soleplate, to be used in particular to target stubborn creases, detailing
and zones that are difficult to access.
• To use this function, press the Power Zone function on top of the iron as often as
necessary
- fig.7
.
* (depending on model)
The first time the
appliance is used,
there may be some
fumes and smell but
this is not harmful.
They will not affect
use and will
disappear rapidly.
Recommendations:
for fabrics other than
linen or cotton, hold
the iron a few
centimetres from the
garment to avoid
burning the fabric.
EXPRESS ANTI-CALC
EXPRESS
POWER ZONE
ANTI-CALC
TYPE OF FABRICS
SETTING TEMPERATURE
CONTROL
SETTING STEAM OUTPUT CONTROL DIAL
Silk, Synthetics
(polyester, acetate, acrylic,
polyamide)
•
Silk, Wool
••
Linen, cotton
•••
and maintenance must not be carried out by
children unless they are aged 8 or over and are
supervised. Keep the appliance and power cord
out of the reach of children under 8 years of age.
• The surfaces of your appliance can reach very
high temperatures when functioning, which may
cause burns. Do not touch the hot surfaces of the
appliance (accessible metal parts and plastic
parts adjacent to the metallic parts).
• Never leave the appliance unattended :
- when it is connected to the mains,
- until it has cooled down (around 1 hour).
• Before rinsing the boiler/rinsing the anti-scale
valve (depending on the model), wait until the
appliance is completely cold and has been
unplugged for at least 2 hours before unscrewing
the boiler rinse cap/ the scale collector cover.
• Be careful: if the boiler cap or the boiler rince cap
(depending on the model), is dropped or severely
knocked, have it replaced by an Approved Service
Centre, as it may be damaged.
• When rinsing the boiler, never fill it directly from
the tap.
• The boiler cap musn’t be opened during use.
• The appliance must not be used if it has been
dropped, if it has any visible damage, if it leaks, or
if it functions abnormally in any way. Do not
attempt to dismantle your appliance: have it
examined at an Approved Service Centre to avoid
any danger.
• Check the electrical power and steam cords for
signs of wear or damage prior to use. If the
electrical power cord or the steam cord is
damaged, it must be replaced at an Approved
Service Centre to avoid any danger.
• For your safety, this appliance conforms to all applicable regulations (Low Voltage Directive,
Electromagnetic Compatibility, Environment, etc).
• Your steam station iron is an electrical appliance: it must be used under normal conditions of
use. It is designed for domestic use only.
• It is equipped with 2 safety systems:
- a pressure release valve designed to avoid excessive pressure. In the event of malfunction,
the valve releases excess steam.
- a thermal fuse to avoid overheating.
• Always plug your steam station iron:
- into a mains circuit with voltage between 220 V and 240 V,
- into an earthed electrical socket.
Connecting to the wrong voltage may cause irreparable damage to the appliance and will
EN
Important
recommendations
Safety instructions
• Please read these instructions carefully before
first use. This product has been designed for
domestic use only. Any commercial use,
inappropriate use or failure to comply with the
instructions, the manufacturer accepts no
responsibility and the guarantee will not apply.
• Never unplug the appliance by pulling the
power cord. Always unplug your appliance:
- before filling the water tank or rinsing the
boiler,
- before cleaning the appliance,
- after each use,
• The appliance must be used and placed on a
flat, stable, heat-resistant surface. When you
place the iron on the iron rest, make sure that
the surface on which you place it is stable.
• This appliance is not intended to be used by
persons (including children) with reduced or
impaired physical, sensory or mental
capacities or persons lacking appropriate
knowledge or experience, unless a person
responsible for their safety provides either
supervision or appropriate instructions
concerning use of the appliance prior to its use.
• Children should be supervised to ensure they
do not play with the appliance.
• This appliance may be used by children aged 8
or over and persons lacking appropriate
knowledge or experience or persons with
reduced or impaired physical, sensory or
mental capacities provided that they have
been thoroughly instructed regarding use of
the appliance, are supervised, and understand
the risks involved. Children must not be
allowed to play with the appliance. Cleaning
invalidate your guarantee.
If you are using a mains extension lead, ensure that it is correctly rated (16A) with an
earth, and is fully extended
• Completely unwind the power cord before plugging into an earthed socket.
• The sole plate of your iron and the iron rest on the base unit can reach extremely high
temperatures, and can cause burns: do not touch them. Never touch the electrical
power cords with the sole plate of the iron.
• Always use a vented/mesh ironing board and be careful of hot steam when ironing
close to the edges of the board.
• Your appliance emits steam, which can cause burns. Always handle the iron with care,
especially when ironing vertically. Never direct the steam towards people or animals.
• Never immerse your steam station iron in water or any other liquid. Never place it
under a running tap.
Environment protection first !
iYour appliance contains valuable materials which can be recovered or recycled.
‹Leave it at a local civic waste collection point.
PLEASE RETAIN THIS
INSTRUCTION BOOKLET FOR
FUTURE REFERENCE
To prime the steam circuit,
either before using the iron
for the first time, or if you
have not used the steam
function for a few minutes,
press the steam control
button several times in a
row, holding the iron away
from your clothes
- fig.6. This will enable any
cold water to be ejected
from the steam circuit.
Produkspesifikasjoner
| Merke: | Tefal |
| Kategori: | Ikke kategorisert |
| Modell: | Express Anti-scale GV7466 |
Trenger du hjelp?
Hvis du trenger hjelp med Tefal Express Anti-scale GV7466 still et spørsmål nedenfor, og andre brukere vil svare deg
Ikke kategorisert Tefal Manualer
17 Oktober 2025
30 August 2025
30 August 2025
29 August 2025
29 August 2025
29 August 2025
29 August 2025
28 August 2025
28 August 2025
16 August 2025
Ikke kategorisert Manualer
- EMeet
- Butler
- NEO Tools
- Cadel
- Universal Audio
- Sonnet
- Dragonshock
- Physa
- Kodak
- Indiana Line
- Sensei
- Kenwood
- Lund
- Perel
- Gamma
Nyeste Ikke kategorisert Manualer
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
