Technical description and operating instructions

2.1 Soundbar with active subwoofer and THX certificate

Cinebar 52 THX

2• Cinebar 52 THX

Notice

The information in this document may change

without prior notice and in no way constitutes any

liability on the part of Lautsprecher Teufel GmbH.

No part of these instructions may be reproduced in

any form or be broadcasted in any way electronically,

mechanicall , by photocopy or recording without the y

written permission of Lautsprecher eufel GmbH.T

Version 1.1

November 2016

General notes and information

Contents

General notes and information ............................2

Notice ..................................................................2

Trademarks ........................................................2

Original packaging ..............................................3

Complaints ..........................................................3

Contact ................................................................3

Proper use ...........................................................3

For your safety ......................................................4

Signal terms ........................................................4

Safety notes ........................................................4

Explanation of symbols ........................................6

Overview ...............................................................7

Unpacking ...........................................................7

Product contents ................................................7

Checking the delivery .........................................7

Control elements and connections ......................8

Soundbar CB 52 SB ............................................8

Connector jacks ..................................................9

Remote control CB 52 RC ..................................9

Subwoofer CB 52 SW ...................................... 10

Setup/wall mounting ......................................... 11

Setup location .................................................. 11

Cinebar 52 THX ........................................ 11

Subwoofer CB 52 SW ............................... 11

Location tips ............................................. 11

Wall mounting .................................................. 11

Connection example ......................................... 12

Remote control .................................................. 14

Removing insulation strips .............................. 14

Changing the battery ....................................... 14

Use ..................................................................... 15

Cinebar 52 THX ................................................ 15

Activating and deactivating ..................... 15

Selecting a source.................................... 15

Setting the volume ................................... 15

Mute .......................................................... 15

Changing the subwoofer volume using the

remote control .......................................... 15

Setting the bass and treble tones ........... 15

Selecting sound effects ........................... 15

Lip Sync .................................................... 15

BGC ( oundary ain B G Compensation) ..... 15

Subwoofer CB 52 SW ...................................... 16

Turning the subwoofer on and off............ 16

Setting the subwoofer .............................. 16

Care and cleaning.............................................. 16

Troubleshooting ................................................. 17

Technical data ................................................... 18

Trademarks

® All trademarks are the property of their respective

owners.

THX and the THX logo are trade-

marks of THX Ltd., which are

registered in some jurisdictions.

Manufactured under license from

Dolby Laboratories. Dolby and the

double-D symbol are trademarks of

Dolby Laboratories.

3 • Cinebar 52 THX

You can view the DTS patents

at http://patents.dls.com.

Manufactured under license

from DTS Licensing Limited. DTS, the symbol as well

as DTS and the symbol collectively are registered

trademarks. DTS Digital Surround is a trademark of

The HDMI and High-Definition

Multimedia Interface symbols

as well as the HDMI logo are trademarks or regis-

tered trademarks of HDMI Licensing LLC in the USA

and other countries.

Original packaging

If you wish to exercise your eight-week right of re-

turn, we ask that you be absolutely sure to hold onto

the packaging. We can only accept the return of the

speakers WITH THE ORIGINAL PACKAGING.

Empty boxes are not available!

Complaints

In case of complaint we will need the following infor-

mation to process your enquiry:

1. Invoice number

Can be found on the sales slip (enclosed with the

product) or on the order confirmation received as a

PDF document, e.g. 4322543

2. Serial number or batch number

Located on the back of the device,

e.g. serial no.: KB20240129A-123.

Thank-you for your support!

Contact

Please contact our customer service with any ques-

tions, suggestions or criticism:

Lautsprecher Teufel GmbH

Gewerbehof Buelowbogen

Bülowstraße 66

10783 Berlin (Germany)

Phone 00800 - 200 300 40 (toll-free)

Fax: +49 (0)30 / 300 930 930

E-Mail: service@teufelaudio.com

www.teufelaudio.com

Proper use

Only use the speakers as described in these operat-

ing instructions. Any other use will be deemed as not

in accordance with the instructions and may lead to

damage of property or even persons.

The manufacturer accepts no liability for damage

caused by use not in accordance with the instruc-

tions.

The speakers are intended for domestic use.

Before operating the speakers please read

the safety notes and operating instructions

carefully. Only in this way, can you ensure

that all functions are used in a safe and reliable

manner. Store the operating instructions in a safe

place and also be sure to pass them on to any sub-

sequent owner.

Produkspesifikasjoner

Merke:	Teufel
Kategori:	Hi-fi system
Modell:	Cinebar 52
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Antall HDMI-porter:	4
FM-radio:	Nei
Audio Return Channel (ARC):	Ja
Bassrefleks:	Ja
AC-inngangsspenning:	230 V
Antall forsterkerkanaler:	2 kanaler
Strømforbruk (standby):	0.4 W
Produktfarge:	Sort
Strømforbruk (vanlig bruk):	400 W
Fjernkontroll medfølger:	Ja
AUX-inngang:	Ja
DC-inngangskontakt:	Ja
Kan monteres på vegg:	Ja
Subwoofer inkludert:	Ja
Subwoofer-vekt:	17200 g
Lyd-utgang kanaler:	2.0 kanaler
RMS-rangert strøm/utgangseffekt:	440 W
Innebygd lyddekoder:	Dolby Digital, Dolby Pro Logic, Dolby Pro Logic II, DTS
Frekvensrekkevidde:	120 - 22000 Hz
Subwoofer RMS-styrke:	320 W
Basshøyttalerens diameter:	250 mm
Diskant diameter:	25 mm
Magnetisk beskyttet:	Ja
Apple docking-kompabilitet:	Støttes ikke
Digital optisk lydinngang:	2
Subwooferens dimensjoner (BxDxH):	310 x 460 x 420 mm
Digital koaksialinngang for lyd:	2
Antall drivere til diskant:	2
Antall basshøyttalerdrivere:	1
Lydplankens RMS-effekt:	120 W
Subwoofer-type:	Aktiv subwoofer
Frekvensomgang subwoofer:	35 - 120 Hz
Lydplankevekt:	8600 g
Dokkingtilkoblingstype:	Støttes ikke
Lydplankens dimensjoner (BxDxH):	1020 x 100 x 140 mm
