Technical Description and Operating Instructions

MM/MC Preampliﬁ er for Record Players

PhonoStation 1

• PhonoStation 1

Contents

General notes and information ................................................................................3

Notice ........................................................................................................3

Original packaging ......................................................................................3

Complaints ..................................................................................................3

Contact ......................................................................................................3

Proper use ...................................................................................................3

Safety notes ............................................................................................................4

Product contents ......................................................................................................6

Control elements and connections ............................................................................7

Setup and connection ..............................................................................................8

Setup location .............................................................................................8

Record player ..............................................................................................8

Ampliﬁ er/receiver .......................................................................................9

Connecting to a power supply .......................................................................9

Operation .............................................................................................................10

Activating and deactivating ........................................................................ 10

Care and cleaning .................................................................................................10

Technical data ....................................................................................................... 11

Protecting the environment .................................................................................... 11

Disposal of the unit..................................................................................... 11

• PhonoStation 1

Notice

The information in this document may

change without prior notice and in no

way constitutes any liability on the part

of Lautsprecher Teufel GmbH.

No part of these instructions may be re-

produced in any form or be broadcast-

ed in any way electronically, mechanical-

ly, by photocopy or recording without the

written permission of Lautsprecher Teufel

GmbH.

Version 1.0

October 2011

Original packaging

If you wish to exercise your eight-week

right of return, we ask that you be abso-

lutely sure to hold onto the packaging.

We can only accept the return of the

speakers WITH THE ORIGINAL PACK-

AGING.

Empty boxes are not available!

Complaints

In case of complaint we will need the fol-

lowing information to process your en-

quiry:

1. Invoice number

Can be found on the sales slip (enclosed

with the product) or on the order con-

ﬁ rmation received as a PDF document,

e.g. 4322543

2. Serial number or batch number

Located on the bottom side of the unit,

e.g. serial number: IT04....

Many thanks for your support!

Contact

For questions, suggestions or criticism

please contact our customer service de-

partment:

Lautsprecher Teufel GmbH

Gewerbehof Buelowbogen

Buelowstrasse 66

10783 Berlin (Germany)

Phone: 00800 - 200 300 40 (free of

charge)

Fax +49 (0)30 / 300 930 930

E-mail: service@teufelaudio.com

www.teufelaudio.com

Proper use

Only use the product as described in these

operating instructions. Any other use will

be deemed as not in accordance with the

instructions and may lead to damage to

property or even persons.

The manufacturer accepts no liability for

damage caused by use not in accordance

with the instructions.

The product is intended for private use.

Before operating the unit for the

ﬁ rst time please read the safety

notes and operating instructions

carefully. This is the only way to use all

functions safely and reliably.

Keep the operating instructions safe and

pass them on to anyone who may own

the unit after you.

General notes and information

Produkspesifikasjoner

Merke:	Teufel
Kategori:	Mottaker
Modell:	PhonoStation 1
Vekt:	290 g
Bredde:	132 mm
Dybde:	77 mm
Høyde:	40 mm
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
AC-inngangsspenning:	230 V
AC-inngangsfrekvens:	50 Hz
Produktfarge:	Sort
Lydinngang (V/H) inn:	2
Signal-til-støy-forhold (SNR):	- dB
DC-inngangskontakt:	Ja
Av/på-bryter:	Ja
Lyd-utgang kanaler:	- kanaler
Lydutgang (venstre/høyre):	1
Formål:	Hjem
Tilkoblingstype høyttalere:	RCA
Peak effekt per kanal:	- W
