ThermaSol TFXA-390 Bruksanvisning
Les nedenfor 📖 manual på norsk for ThermaSol TFXA-390 (1 sider) i kategorien Generator. Denne guiden var nyttig for 11 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/1

92026-390_A 7/17
TFXA-390
TFXA-390
TFXA-390
TFXA-390 TFXA-390
FX SERIES Auto Flus
FX SERIES Auto Flus
FX SERIES Auto Flus
FX SERIES Auto FlusFX SERIES Auto Flush Steam Generator
h Steam Generator
h Steam Generator
h Steam Generator h Steam Generator
Rough-In Guide
Rough-In Guide
Rough-In Guide
Rough-In Guide Rough-In Guide
Shipping Informaon:
Weight……… ……… … 28 lbs.
Length……… …..……… 21 in.
Width……………....….10.5 in.
Height……… ……. ..…..14 in.
FX Series Auto Flush Steam Generator
SPECIFICATIONS
Input Voltage………… ……. ......208-240VAC Single Phase
Kilowatt Rating………………………………… ……..…… 11.0
Maximum Amperage……………………………..….55 AMPS
Breaker Size 60AMPS ………………………………………..….
Water Inlet Compression …………………………… 3/8” .…...
Steam Outlet…………………………………….……. ” NPT1/2
Drain Pan………………………………….… ………3/4” NPT...
Safety Valve………………………………………..….3/4” NPT
Electrical C . ...........Hardwired onnection………………… ..
Maximum Room Size (Cubic Feet) 395 ………..………..…...
For any further assistance please contact ThermaSol at
800.776.0711 or sales@thermasol.com
• Can be plumbed up to 50 . from the steam room without
upsizing the generator
• Stainless steel construcon throughout
• Temp Sensor is built into controller
Installaon Notes:
Generator must be installed by a licensed electrician.
Install this generator according to the installaon guide supplied. Follow all local plumbing and electrical codes. Unit must be accessible for
service and maintenance. Generator is factory sized: L x W x H = Steam Room Cubic Feet Cu. Ft. max. Choose the appropriate generator. = 395
For every addional foot of ceiling height over 8 , use the next larger generator. Always round up when calculang the total cubic feet.
Product Specicaon Basics:
The steam generator unit dimensions are approximately -3/418 ”L x
18-1/8 12-”W x 3/4”H in dimension. The generator shall be made
from stainless steel.
FX Series Auto Flush Series Standard Equipment:
• Auto PowerFlush Pressurized inner tank cleaning system –
• Includes Fast Start Steam in s – econds… not minutes
• Constant Steam at a constant rate
• Unit has 208-240 volt power connecons to be installed by your
licensed electrician
• Superior heang element low wa density –
• Includes Stainless Steel drain p an
Produkspesifikasjoner
Merke: | ThermaSol |
Kategori: | Generator |
Modell: | TFXA-390 |
