Repair instruction
PRODUCT GROUP [COOKING APPLIANCES]
PRODUCT CATEGORY [HOBS]
PRODUCT CODE : VARIOUS
WARNING! Before commencing work, disconnect the electricity and turn off the gas.
A
These instructions are for Thetford
cookers with electric hotplates. For
surface-mounted hobs please refer to
page 3. Electric hotplates should only
be removed and replaced by a
qualified competent person.
B
Remove the pan-rest(s) and all the
control knobs. Behind the knobs
locate and remove the 16/17mm
hexagonal nuts from the controls and
2 screws (where appliacable).
C
On the back edge of the control
fascia, remove the 2 screws.
D
The control fascia and profile can now
be removed. Lift up and forward, and
carefully remove the spade
connections for the ignition button
and oven light switch, where fitted.
17-02-2017 1/3
Repair instruction
PRODUCT GROUP [COOKING APPLIANCES]
PRODUCT CATEGORY [HOBS]
PRODUCT CODE : VARIOUS
WARNING! Before commencing work, disconnect the electricity and turn off the gas.
E
Remove any screws fitted to the rear
trim and loosen the 2 screws in each
hinge, but do not remove.
F
In each black enamel burner cap
remove the retaining screw(s).
G
The enamel burner caps and cast
burner rings can now be removed.
Next remove the screws/retaining
studs found beneath the burner rings.
H
Finally, if applicable, remove the 2
screws found in the pan-
rest clips that
are holding the hob pressing in place.
17-02-2017 2/3
