Side 1/27

Code: 0120504554

Instruccions para el montaje

y recomendaciones para el mantenimiento

Product name (SPANISH) and Model

Einbauanleitung und Pflegehinweise

Product name (GERMAN) and Model

Instruction Manual

Product name (ENGLISH) and Model

Instructions pour le montage

et Recommandations pour I'entretien

Product name (FRENCH) and Model

Manual de Instruções

Product name (PORTUGUESE) and Model

TLVI 75

Teka Industrial, S.A:

Cajo, 17

39011 Santander

Cantabria - ESPAÑA

Tel.: 34-942 35 50 50

Fax: 34-942 34 76 94

Teka Chile, S.A.:

La Forja 8600, Parque

Industrial La Reina

Casilla 482 V -Correo 21

Santiago de Chile

Tel: +56 2 438 6000

Fax: +56 2 438 6099

Teka Portugal, S.A:

Estrada da Mota Ap. 533

3834-909 Ilhavo

PORTUGAL

Tel.: 351-234-32 95 00

Fax: 351-234-32 54 57

Cód.: 61401083/607

Downloaded from www.Manualslib.com manuals search engine

BCEF

Close-up View (Interior)

Close-up View (control panel)

"HALF LOAD" indicator light

Low rinse aid indicator light

Low salt indicator light

Cycle select button

Cycle indicator lightON-OFF button

ON-OFF light

Delay select button

Delay indicator light

"HALF LOAD" button

Safety Is a Good Habit to Get Into

B Upper Rack

D Top Spray Arm

C Rack Height Adjustor

E Lower Rack

G Washing Filter

I Detergent and Rinse Aid Dispenser

M Third Sprayer

J Salt Container Cap

F Bottom Spray Arm

Technical characteristics

60 cm

85 cm

12 standard place settings

0.03-0.6MPa

220-240V~ 50Hz

1950W

Width

Depth

Height

Capacity

Mains water pressure

Power voltage

Total absorber power

A Cup Rack

K Silverware basket

L Knife rack

- If the appliance malfunctions, turn off water supply to the appli-

ance and disconnect the plug from the wall socket. Then, con-

sult the section entitled, "Troubleshooting". If you cannot solve

the problem, contact a service centre.

- Only specialised personnel are authorised to make repairs.

- Appliances which are no longer being used must be made

inoperable by cutting the power supply cord and removing

the door lock.

- If the supply cord is damaged, it must be replaced by the

manufacture, its service agent of similarly qualified persons in

order to avoid a hazard.

- After installation, the power plug must be accessible.

- Fundamental rules to follow when using the appliance:

* Never touch the dishwasher when barefoot or with wet hands

or feet;

* We discourage the use of extension cords and multiple

sockets;

* During installation, the power supply cord must not be exces-

sively or dangerously bent or flattened;

* If the appliance is not operating properly or maintenance must

be performed, disconnect the appliance from the power

supply.

To maintain the EFFICIENCY and SAFETY of this appliance,we

recommend:

- call only the Service Centers authorized by the manufacturer.

- always use original Spare Parts

NOTICE

Carefully read the instructions contained in this manual, as they

provide important information which is essential to safe and proper

installation, use and maintenance of the appliance.

This appliance complies with the following EEC

directives:

- 73/23/EEC of 19 February 1973 (Low Voltage) and subse

quent modifications;

- 89/336/EEC of 3 May 1989 (Electromagnetic Compatibility)

and subsequent modifications.

- Carefully dispose of the packing material.

- After removing the packing, check to make sure that the appli-

ance is not damaged. If in doubt, contact a qualified professional.

- The dishwasher must only be used by adults for the washing of

household dishes and cooking utensils.

- The appliance is not intended for use by young children or

inform persons without supervision.

- Young children should be supervised to ensure that they do

not play with the appliance.

- Keep detergents out of the reach of children, who must also

be kept away from the dishwasher when it is open.

- This appliance cannot be installed outdoors, not even if the

area in which it is installed is covered by a roof; it is also very

dangerous to leave it exposed to the rain and elements.

- Do not touch the heating element during or after a wash cycle.

- Do not lean or sit on the door when it is open as this could

over turn the dishwasher.

.2..1.

Downloaded from www.Manualslib.com manuals search engine

Salt





Detergent and Rinse Aid





Salt

The hardness of the water varies from place to place. If hard

water is used in the dishwasher, deposits will form on the dishes

and utensils.

The appliance is equipped with a special softener that uses a salt

specifically designed to eliminate lime and minerals from the water.

Loading the Salt into the Softener

Always use salt intended for use with dishwashers.

The salt container is located beneath the lower rack and should

be filled as follows:

- Remove the lower rack and then unscrew and remove the cap

from the salt container;

- If you are filling the container for the first time, fill it with water;

- Place the end of the funnel (supplied) into the hole and intro-

duce about 2 kg of salt. It is normal for a small amount of water

to come out of the salt container.

- Carefully screw the cap back on.

The salt container must be filled when the "low salt" indicator

light (located on the control panel), comes on.

To prevent the formation of rust, load the salt just be-

fore beginning a wash cycle.

Adjusting Salt Consumption

The dishwasher is designed to allow for adjusting the amount of

salt consumed based on the hardness of the water used. This is

intended to optimize and customize the level of salt consumption

so that it remains at a minimum.

To adjust salt consumption, proceed as follows:

- Unscrew the cap from the salt container;

- There is a ring on the container with an arrow on it (see figure to

the side),

- If necessary, rotate the ring in an anticlockwise direction from

the "-" setting towards the "+" sign, based on the hardness of

the water being used.

It is recommended that adjustments be made in accordance

with the following schema:

Detergent

Detergent specifically intended for use with dishwashers must

be used. The dispenser must be refilled before the start of each

wash cycle following the instructions provided in the "Wash Cycle

Table". The detergent dispenser is located on the inside panel

the door.

Loading the detergent

To open the "A" cover on the dispenser, press the "B" button.

The detergent for the wash cycle should be poured into the "C"

compartment.

After the detergent has been placed in the dispenser, close the

cover and press down until it clicks in place.

Notice: To facilitate closing the cover, remove any ex-

cess detergent on the edges of the dispenser.

Rinse Aid

This product makes dishes sparkle and helps them to dry with-

out spotting. The dispenser is located on the inside panel of the

door and should be filled after every 80 wash cycles (or when

the "low rinse aid" indicator light comes on for those models

with this feature).

Loading the Rinse Aid

Regardless of the type of detergent dispenser installed on your

appliance, you must proceed as indicated below when loading

the rinse aid.

To open the dispenser, turn the "C" cap in an anti-clockwise

direction and then pour in the rinse aid, making sure not to overfill.

The amount of rinse aid used for each cycle can be regulated by

turning the "F" dose adjustor, located beneath the "C" cap, with

a screwdriver. There are 6 different settings; the normal dosage

setting is 3.

Important

Proper dosage of the rinse aid improves drying.

If drops of water remain on the dishes or spotting occurs,

the dosage adjustor should be turned to a higher setting.

If the dishes have white streaks, turn the dosage adjustor

to a lower setting.

Water Hardness

Clarke

degrees

ºdH

mmol/l

Selector

position

Salt

consumption

(Grams/cycle)

Autonomy

(cycles/2kg)

014 MNT MNIT

NIUQIQNUQQNQPS

PSTN QRUV QIRUIV

[UV[TN [UIV

=?J?

jba

SM?H?

Level

.4..3.

C A

Downloaded from www.Manualslib.com manuals search engine
