IR-310MINFRARED WIRELESS MICROPHONE

INSTRUCTION MANUAL

Thank you for purchasing TOA’s Infrared Wireless Microphone.

Please carefully follow the instructions in this manual to ensure long,

trouble-free use of your equipment.

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS

......................................................................................................... 2

2. GENERAL DESCRIPTION ....................................................................................................... 3

3. FEATURES ................................................................................................................................. 3

4. HANDLING PRECAUTIONS .................................................................................................... 4

5. NOMENCLATURE AND FUNCTIONS ................................................................................... 4

6. BATTERY INSERTION ............................................................................................................. 5

7. WHEN OPERATING ON RECHARGEABLE BATTERIES ................................................... 6

7.1. How to Charge ....................................................................................................................... 6

7.2. Charging Timing .................................................................................................................... 7

8. OPERATION .............................................................................................................................. 7

9. INFRARED WIRELESS MICROPHONE USAGE TIPS ........................................................ 8

9.1. When Holding the Microphone By Hand or Hanging It Around the Neck ............................ 8

9.2. Setting the Microphone Sensitivity Selector Switch ............................................................ 8

9.3. Microphone-to-Mouth Distance ............................................................................................ 9

9.4. When Using the Clip ............................................................................................................. 9

10. CHANNEL SETTING ............................................................................................................ 10

11. TROUBLESHOOTING .......................................................................................................... 10

12. SPECIFICATIONS ................................................................................................................. 11

Accessory ................................................................................................................................ 11

Optional products .................................................................................................................... 11

ON/ OFF

1. SAFETY PRECAUTIONS

• Before installation or use, be sure to carefully read all the instructions in this section for correct

and safe operation.

• Be sure to follow all the precautionary instructions in this section, which contain important

warnings and/or cautions regarding safety.

• After reading, keep this manual handy for future reference.

Indicates a potentially hazardous situation which, if mishandled, could

result in death or serious personal injury.

WARNING

Indicates a potentially hazardous situation which, if mishandled, could

result in moderate or minor personal injury, and/or property damage.

CAUTION

WARNING

When the Unit is in Use

• Use TOA’s IR-310BC Battery Charger when

recharging.

The infrared wireless microphone can be

hydride (NiMH) batteries. The use of any

other than the specied charger could result

in re, personal injury or environmental

contamination due to battery rupture or

leakage.

• Stop charging if the batteries are not fully

charged within 3 hours. Failure to do so may

cause the batteries to re, explode, leak, or

heat.

• Never short-circuit the charging terminals

on the bottom of the microphone with metal

objects.

Doing so could result in electric shocks or

burns.

• To prevent the electromagnetic wave from

badly inuencing medical equipment, make

sure to switch off the unit’s power when

placing it in close proximity to the medical

equipment.

When the Unit is in Use

• When the unit is not in use for 14 days or

more, be sure to take the batteries out of

the unit because battery leakage may cause

a re, personal injury, or environmental

contamination.

• Make sure to observe the following handling

precautions so that a re or personal injury

does not result from leakage or explosion of

the battery.

· Be sure to use only the IR-210BT/200BT

Rechargeable Battery designed for use with

the infrared wireless microphone.

· Do not short, disassemble, heat nor put the

battery into a re.

· Do not solder a battery directly.

· Note correct polarity (positive and negative

orientation) when inserting a battery in the

unit.

· Avoid locations exposed to the direct

sunlight, high temperature and high humidity

when storing batteries.

• When you discard batteries, please contact

the local dealer from whom you bought.

CAUTION

Produkspesifikasjoner

Merke:	Toa
Kategori:	Mikrofon
Modell:	IR-310M
Bredde:	54.2 mm
Dybde:	27 mm
Høyde:	109 mm
Tilkoblingsteknologi:	Trådløs
Strømforbruk:	215 mA
Mikrofonfrekvens:	100 - 12000 Hz
Mikrofonvekt:	95 g
Produktfarge:	Black, White
Batteriliv (maks.):	8 timer
Driftstemperatur (T-T):	0 - 40 °C
Kroppsmateriale:	Harpiks
Antall medfølgende produkter:	1 stykker
Arbeidsfrekvens:	100 - 350 MHz
Maksimal opereringsrekkevidde:	15 m
