INSTRUCTION MANUAL
HEADSET MICROPHONE -M5000H YP
Thank you for purchasing TOA’s Headset Microphone.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
This product is an expendable item. No warranty is provided for any trouble except incipient failure
1. GENERAL DESCRIPTION
The TOA YP-M5000H is headset microphone of an
omnidirectional pick-up pattern, featuring a light weight
design.
2. NOMENCLATURE
3. HOW TO USE
・By adjusting the gooseneck, position the
microphone slightly o the front of your mouth, and 3
–5 cm away from your mouth for the best sound
reproduction. When the microphone is too close to
your mouth or you speak too loud, speech clarity will
be impaired, making it hard for the audience to hear
announcements.
・The donut-shaped sweat stopper is to protect the
microphone's element from sweat and moisture.
Position the sweat stopper as close to the
microphone's element as possible to provide
maximum protection.
・Do not hold the microphone while adjusting the
gooseneck.
・Place the headset frame around the head so that
the frame is horizontal across the back of the head
and the ends of the frame fit over.
4. SPECIFICATIONS
Type
Electret condenser type
Directivity
Omnidirectional
Frequency Response
20 – 20,000 Hz
Sensitivity
-67 dB 3 dB ±
(0 dB=1V/0.1Pa, 1kHz)
Maximum Input Level
115 dBSPL, 1kHz at 1%
Cord Length
1.3 m (4.27 ft)
Terminal
φ3.5 mm (0.14 ) ”
Stereo plug
Finish
Beige color
Weight
21 74 oz or 0.g
(cable included)
Accessories
Windscreen 1 …
Cable clip …1
Microphone
Gooseneck
Frame
Frame
Plug lock
φ3.5 mm
(0.14 ) ”
133 00095- -07 -01
Sweat stopper
Sweat stopper
Microphone
TOA C
a
n
ada
Corpoion
