Side 1/8
IR-801AFAUDIO INTERFACE UNIT
INSTRUCTION MANUAL
Thank you for purchasing TOA’s Audio Interface Unit.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
TABLE OF CONTENTS
1. IMPORTANT SAFETy INSTRUCTIONS
................................................................................ 2
2. SAFETy PRECAUTIONS ......................................................................................................... 2
3. GENERAL DESCRIPTION ...................................................................................................... 3
4. FEATURES ................................................................................................................................. 4
5. HANDLING PRECAUTIONS .................................................................................................... 4
6. NOMENCLATURE AND FUNCTIONS ................................................................................... 4
Front ............................................................................................................................................. 4
Rear ............................................................................................................................................. 5
Bottom .......................................................................................................................................... 5
7. SySTEM CONFIGURATION .................................................................................................... 6
8. CONNECTIONS ........................................................................................................................ 6
8.1. Removable Terminal Plug Connection ................................................................................. 6
8.2. Terminal Connections ........................................................................................................... 7
9. RACk MOUNTING .................................................................................................................... 8
10. SPECIFICATIONS ................................................................................................................... 8
Accessories ................................................................................................................................. 8
Optional product .......................................................................................................................... 8
2
When Installing the Unit
•Do not expose the unit to rain or an
environment where it may be splashed by
water or other liquids, as doing so may result
inreorelectricshock.
•Avoid installing or mounting the unit in
unstable locations, such as on a rickety table
oraslantedsurface.Doingsomayresult in
the unit falling down and causing personal
injury and/or property damage.
•
Since the unit is designed for indoor use, do
not install it outdoors. If installed outdoors, the
aging of parts causes the unit to fall off, resulting
in personal injury. Also, when it gets wet with
rain, there is a danger of electric shock.
When the Unit is in Use
•Donotplacecups,bowls,orothercontainers
of liquid or metallic objects on top of the unit.
If they accidentally spill into the unit, this may
causeareorelectricshock.
2. SAFETy PRECAUTIONS
•Beforeinstallationoruse,besuretocarefullyreadalltheinstructionsinthissectionforcorrect
and safe operation.
•Be sure to follow all the precautionary instructions in this section, which contain important
warnings and/or cautions regarding safety.
•Afterreading,keepthismanualhandyforfuturereference.
Indicates a potentially hazardous situation
which, if mishandled, could result in death or
serious personal injury.
WARNING
1. IMPORTANT SAFETy INSTRUCTIONS
•Readtheseinstructions.
•Keeptheseinstructions.
•Heedallwarnings.
•Followallinstructions.
•Donotusethisapparatusnearwater.
•Cleanonlywithdrycloth.
•Do not block any ventilation openings.
Install in accordance with the manufacture's
instructions.
•Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus(includingampliers)thatproduce
heat.
•Do not defeat the safety purpose of the
polarized or grounding-type plug.
A polarized plug has two blades with one
wider than the other. A grounding type plug
has two blades and a third grounding prong.
The wide blade or the third prong are provided
for your safety. If the provided plug does not
t into your outlet, consult an electrician for
replacement of the obsolete outlet.
•Protectthepowercordfrombeingwalkedon
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
•Only use attachments/accessories specied
by the manufacturer.
•Useonlywiththecart,stand,tripod,bracket,
ortablespeciedbythemanufacturer,orsold
with the apparatus.
When a cart is used, use caution when moving
the cart/apparatus combination to avoid injury
from tip-over.
•Unplugthisapparatusduringlightningstorms
or when unused for long periods of time.
•Refer all servicing to qualied service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed torainor moisture, does
not operate normally, or has been dropped.
