PAGING MICROPHONE

GENERAL DESCRIPTION

The paging microphone is of desk-top type and designed to be used for paging and announcements. It is furnished

with an easy-to-use large talk switch and a convenient lock lever. In addition, it comes with a remote control function to

activate amplifier's power or chime unit. Refer to the amplifier's instruction manual for details of the remote function

and connection.

APPEARANCE

CIRCUIT DIAGRAM

Push to Talk

SPECIFICATIONS

Model

Type

Directivity

Rated Impedance

Rated Sensitivity

Frequency Response

Connection Cable

Cable Length

Terminal of Cable

Weight

Dimensions

Talk Switch

Remote Switch

Finish

PM-660U

Moving coil microphone

Unidirectional

600 , balanced

- 58 dB

kHz,

d B = 1 V/Pa)

100 Hz to 10 kHz

2-core shielded plus 2-core cable

2.5 m

None

440 g

100 (W) × 215 (H) × 150 (D) mm

Push-to-talk type (open-off circuit, with lock lever)

Leaf spring contact (interlocked with talk switch)

Head : Zinc plated steel wire, baked painting (Gray)

Body : ABS resin (Gray)

* Weight given in the above specifications does not include the connection cable.

* Specifications are subject to change without notice.

TOA Corporation

INSTRUCTION MANUAL

PM-660U

Produkspesifikasjoner

Merke:	Toa
Kategori:	Mikrofon
Modell:	PM-660U
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Impedans:	600 Ω
Driftsspenning:	30 V
Mikrofonfrekvens:	100 - 10000 Hz
Mikrofonvekt:	440 g
Kabellengde:	2.5 m
Produktfarge:	Grå
Kabler inkludert:	DC
Modell/Type:	Scene/opptreden
Av/på-bryter:	Ja
Mikrofonsensitivitet/mikrofonfølsomhet:	-58 dB
PC-bord:	Ja
Dimensjoner (B x D x H) med stativ:	100 x 150 x 215 mm
