INSTRUCTION MANUAL

TIE-CLIP MICROPHONE YP-M101

Thank you for purchasing TOA’s Tie-Clip Microphone.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

URL: http://www.toa.jp/

133-05-307-8A

1. GENERAL DESCRIPTION

The YP-M101 is a tie-clip type microphone designed

to be exclusively used with an optional WM-1100

Portable Transmitter.

2. NOMENCLATURE

3. CLIP ATTACHMENT

Attach the supplied clip as shown in the gure.

4. HOW TO USE

• Keep the microphone 15 – 20 cm away from the

mouth when using.

• Take care not to speak loud or position the

microphone too close (within 5 cm) to the mouth,

because this could mufe sounds and make them

inaudible.

5. SPECIFICATIONS

Type Electret condenser type

Directivity Unidirectional

Sensitivity –46 dB (0 dB=1 V/Pa,

1 kHz, load: 2 kΩ)

Maximum Input Sound

Pressure

115 dB SPL

Terminal ø3.5 mm monaural plug

Cord Length 80 cm

Finish Dark gray

Weight 20 g (cable included)

Note: The design and specications are subject to

change without notice for improvement.

• Accessory

Clip ............................................................ 1

Clip

3.5 mm-diameter monaural plug

Microphone

This portion rotates 360º.

Produkspesifikasjoner

Merke:	Toa
Kategori:	Mikrofon
Modell:	YP-M101
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Mikrofonretningstype:	Énveis
Mikrofonholder:	Ja
Mikrofonvekt:	20 g
Produktfarge:	Grå
Enhetsgrensesnitt:	3.5 mm (1/8")
Modell/Type:	Mikrofon med klemme
Mikrofonsensitivitet/mikrofonfølsomhet:	-46 dB
Stemmespole type:	Kondensator
