YP-M5300

YP-M5310

LAVALIER MICROPHONES

INSTRUCTION MANUAL

4. SPECIFICATIONS

D33-07-023-70

URL: http://www.toa.jp/

Traceability Information for Europe (EMC directive 2004/108/EC)

Manufacturer:

TOA Corporation

7-2-1, Minatojima Nakamachi, Chuo-ku, Kobe, Hyogo, Japan

Authorized representative:

TOA Electronics Europe GmbH

Suederstrasse 282, 20537 Hamburg, Germany

Model No. YP-M5300 YP-M5310

Type Electret condenser type

Directivity Unidirectional Omnidirectional

Sensitivity

–

63 dB ±3 dB

–

64 dB ±3 dB

(0 dB = 1 V/0.1 Pa, 1 kHz) (0 dB = 1 V/0.1 Pa, 1 kHz)

Frequency Response 100 Hz – 12 kHz 100 Hz – 15 kHz

Maximum Input Level 120 dB SPL 110 dB SPL

Cord Length 1.3 m (4.27 ft)

Connector ø3.5 mm (ø0.14") mini plug

Finish Dark black

Weight 20 g (0.71 oz) (cable included)

[YP-M5300 (Unidirectional)]

[YP-M5310 (Omnidirectional)]

Clip

Plug lock

ø3.5 mm

(ø0.14")

1.3 m (4.27 ft)

in length

Tie-clip attachment

Set the Microphone's

narrow portion in the

tie-clip's holder.

Rotatable

Tie-clip attachment

Clip

Plug lock

1.3 m (4.27 ft)

in length

ø3.5 mm

(ø0.14")

3. OPERATION

Confirm the Wireless transmitter's power is off, then connect the microphone's mini-plug to the microphone

input jack.

Clip the microphone to your clothing, preferably 15 – 20 cm (5.91" – 7.87") away from your mouth. Rotate the

tie-clip's microphone holder so that the microphone points to your mouth. (YP-M5300 only)

If microphone volume cannot be increased due to acoustic feedback, position the microphone as close as

possible to your mouth.

Note: When connecting or disconnecting the microphone, be sure to turn off the transmitter’s power.

Otherwise, excessive noise may be generated, possibly damaging the speaker and/or amplifier.

1. GENERAL DESCRIPTION

The YP-M5300 and YP-M5310 Lavalier microphones are designed for use with TOA wireless transmitter.

The YP-M5300 features rotation mechanism on the tie clip, allowing the microphone direction to be adjusted

for the best sound pickup.

2. NOMENCLATURE

Note: The design and specifications are subject to change without notice for improvement.

Produkspesifikasjoner

Merke:	Toa
Kategori:	Mikrofon
Modell:	YP-M5300
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Mikrofonretningstype:	Énveis
Mikrofonholder:	Ja
Mikrofonfrekvens:	100 - 12000 Hz
Mikrofonvekt:	20 g
Produktfarge:	Sort
Driftstemperatur (T-T):	0 - 40 °C
Enhetsgrensesnitt:	3.5 mm (1/8")
Modell/Type:	Mikrofon med klemme
Relativ luftfuktighet under drift (H-H):	0 - 90
Mikrofonsensitivitet/mikrofonfølsomhet:	-63 dB
Stemmespole type:	Kondensator
